LT1505G-T: DescriptionRectifier Diode, 1 Phase, 1 Element, 1.5A, 600V V(RRM), Silicon, DO-15, PLASTIC PACKAGE-2; CategoryDiscrete semiconductor diode; File Size63KB，2 Pages; ManufacturerDiodes; Websitehttp://www.diodes.com/

Download Datasheet Parametric Compare View All

LT1505G-T Overview

Rectifier Diode, 1 Phase, 1 Element, 1.5A, 600V V(RRM), Silicon, DO-15, PLASTIC PACKAGE-2

LT1505G-T Parametric

Parameter Name	Attribute value
Maker	Diodes
Parts packaging code	DO-15
package instruction	PLASTIC PACKAGE-2
Contacts	2
Reach Compliance Code	unknown
ECCN code	EAR99
application	GENERAL PURPOSE
Shell connection	ISOLATED
Configuration	SINGLE
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
JEDEC-95 code	DO-15
JESD-30 code	O-PALF-W2
Maximum non-repetitive peak forward current	50 A
Number of components	1
Phase	1
Number of terminals	2
Maximum output current	1.5 A
Package body material	PLASTIC/EPOXY
Package shape	ROUND
Package form	LONG FORM
Certification status	Not Qualified
Maximum repetitive peak reverse voltage	600 V
surface mount	NO
Terminal form	WIRE
Terminal location	AXIAL

Preview

Download Datasheet

View All

LT1501G - LT1507G

1.5A GLASS PASSIVATED RECTIFIER

Features

·

Glass Passivated Die Construction

Diffused Junction

High Current Capability and Low Forward

Voltage Drop

Surge Overload Rating to 50A Peak

Low Reverse Leakage Current

Plastic Material - UL Flammability

Classification 94V-0

INACTIVE, NOT

FOR NEW DESIGN,

USE 1N5391G - 1N5399G

A

B

A

C

D

Mechanical Data

·

Case: Molded Plastic

Terminals: Plated Leads Solderable per

MIL-STD-202, Method 208

Polarity: Cathode Band

Weight: 0.4 grams (approx)

Mounting Position: Any

Marking: Type Number

Dim

A

B

C

D

DO-15

Min

25.40

5.50

0.686

2.60

Max

—

7.62

0.889

3.6

All Dimensions in mm

Maximum Ratings and Electrical Characteristics

Single phase, half wave, 60Hz, resistive or inductive load.

For capacitive load, derate current by 20%.

Characteristic

Peak Repetitive Reverse Voltage

Working Peak Reverse Voltage

DC Blocking Voltage

RMS Reverse Voltage

Average Rectified Output Current

(Note 1)

@ T

A

= 55°C

Non-Repetitive Peak Forward Surge Current 8.3ms

single half sine-wave superimposed on rated load

(JEDEC Method)

Forward Voltage

Peak Reverse Current

at Rated DC Blocking Voltage

I

2

t Rating for Fusing (t < 8.3ms)

Typical Junction Capacitance (Note 2)

Typical Thermal Resistance Junction to Ambient

Operating and Storage Temperature Range

Notes:

@ I

F

= 1.5A

@T

A

= 25°C

@ T

A

= 100°C

Symbol

V

RRM

V

RWM

V

R

V

R(RMS)

I

O

I

FSM

V

FM

I

RM

I

2

t

C

j

R

qJA

T

j,

T

STG

LT15

01G

50

35

@ T

A

= 25°C unless otherwise specified

LT15

02G

100

70

LT15

03G

200

140

LT15

04G

400

280

1.5

50

1.1

5.0

200

10.4

15

80

-65 to +175

LT15

05G

600

420

LT15

06G

800

560

LT15

07G

1000

700

Unit

V

A

V

µA

A

2

s

pF

K/W

°C

1. Valid provided that leads are kept at ambient temperature at a distance of 9.5mm from the case.

2. Measured at 1.0 MHz and applied reverse voltage of 4.0V DC.

DS29005 Rev. B-3

1 of 2

www.diodes.com

LT1501G-LT1507G

ã

Diodes Incorporated
