RL-2515
SURFACE MOUNT
CHIP INDUCTORS
DESCRIPTION
• Chip Inductors
FEATURES & APPLICATIONS
• Offers over a hundred standard values of miniature inductors
that are designed specifically for compact assemblies requiring
surface mount components
• Available on reels for automated assemblies or in
bulk packaging
• Standard 1210 package
ENVIRONMENTAL DATA
•
•
Storage temperature range:
-40°C to +125°C
Operating temperature range:
-40°C to +130°C
PACKAGING INFORMATION
• Packaging information: pg. 489, 494
Verify operation with sample in actual circuit. Order samples at www.rencousa.com.
MECHANICAL DIMENSIONS
U.S. Standard (mm)
PART NUMBER
RL-2515
A (MAX.)
0.138 (3.50)
B (MAX.)
0.087 (2.40)
C (REF.)
0.24 (0.60)
D (MIN.)
0.008 (0.20)
E (MAX.)
0.106 (2.70)
F ±0.004 (0.1)
0.075 (1.90)
PART NUMBER
RL-2515
PART WEIGHT
0.12g (0.004oz)
G (REF.)
0.079 (2.00)
H (REF.)
0.047 (1.20)
I (REF.)
0.079 (2.00)
A
FRONT VIEW
A
SIDE VIEW
RECOMMENDED LAND PATTERN
1
SCHEMATIC
E
E
H
B
C
D
D
B
C
G
I
F
2
F
SURFACE MOUNTS
RENCO ELECTRONICS INC.
220
595 International Place, Rockledge, FL 32955-4200 USA • www.rencousa.com • ISO 9001 Certified
Toll Free Engineering Hot Line: 800.645.5828 • P: 321.637.1000 • F: 321.637.1600
RL-2515
Renco Part No.
RL-2515
RL-2515-0.15
RL-2515-0.18
RL-2515-0.22
RL-2515-0.27
RL-2515-0.33
RL-2515-0.39
RL-2515-0.47
RL-2515-0.56
RL-2515-0.68
RL-2515-0.82
RL-2515-1.0
RL-2515-1.2
RL-2515-1.5
RL-2515-1.8
RL-2515-2.2
RL-2515-2.7
RL-2515-3.3
RL-2515-3.9
RL-2515-4.7
RL-2515-5.6
RL-2515-6.8
RL-2515-8.2
RL-2515-10
RL-2515-12
RL-2515-15
RL-2515-18
RL-2515-22
RL-2515-27
RL-2515-33
RL-2515-39
RL-2515-47
RL-2515-56
RL-2515-68
RL-2515-82
RL-2515-100
Inductance
(µH)
0.15
±
20%
0.18
±
20%
0.22
±
20%
0.27
±
20%
0.33
±
20%
0.38
±
20%
0.47
±
20%
0.56
±
20%
0.68
±
20%
0.82
±
20%
1.00
±
20%
1.20
±
20%
1.50
±
20%
1.80
±
20%
2.20
±
20%
2.70
±
20%
3.30
±
10%
3.90
±
10%
4.70
±
10%
5.60
±
10%
6.80
±
10%
8.20
±
10%
10.00
±
10%
12.00
±
10%
15.00
±
10%
18.00
±
10%
22.00
±
10%
27.00
±
10%
33.00
±
10%
39.00
±
10%
47.00
±
10%
56.00
±
10%
68.00
±
10%
82.00
±
10%
100.00
±
10%
DCR Max.
(Ohms)
0.16
0.18
0.20
0.22
0.24
0.26
0.29
0.33
0.35
0.39
0.44
0.48
0.54
0.58
0.67
0.72
0.80
0.88
0.95
1.10
1.20
1.30
1.40
1.60
1.80
1.90
3.10
3.50
3.90
4.30
6.00
6.50
7.30
10.20
11.30
SRF
(MHz) Min.
290.0
260.0
230.0
210.0
190.0
170.0
150.0
130.0
120.0
100.0
90.0
85.0
70.0
60.0
50.0
45.0
40.0
37.0
32.0
30.0
28.0
25.0
23.0
20.0
19.0
17.0
18.0
14.0
13.0
12.0
10.0
9.0
9.0
8.0
7.0
Q Typical
Min.
30.0
30.0
30.0
30.0
30.0
30.0
30.0
30.0
30.0
30.0
30.0
30.0
30.0
30.0
30.0
30.0
30.0
30.0
30.0
30.0
30.0
30.0
30.0
30.0
30.0
30.0
30.0
30.0
30.0
30.0
30.0
30.0
30.0
30.0
20.0
Irms
(mA)
610.0
580.0
550.0
520.0
500.0
480.0
460.0
430.0
410.0
390.0
370.0
350.0
330.0
320.0
300.0
290.0
270.0
260.0
250.0
230.0
220.0
215.0
200.0
190.0
180.0
175.0
140.0
130.0
125.0
120.0
100.0
95.0
90.0
75.0
70.0
Measuring
Frequency (MHz)
25.200
25.200
25.200
25.200
25.200
25.200
25.200
25.200
25.200
25.200
7.960
7.960
7.960
7.960
7.960
7.960
7.960
7.960
7.960
7.960
7.960
7.960
2.520
2.520
2.520
2.520
2.520
2.520
2.520
2.520
2.520
2.520
2.520
2.520
0.796
NOTES:
1. ELECTRICAL SPECIFICATIONS MEASURED AT 25ºC
2. Irms - CURRENT THAT CAUSES THE TEMPERATURE
TO RISE APPROX. 20ºC ABOVE AMBIENT OF 25ºC
ORDERING INFORMATION:
PART NUMBER SYSTEM
RL-2505-XXX-XX
“T” OR “B” FOR TAPE
OR BULK PACKAGING
ORDER QUANTITY: 2,000 PIECES FOR TAPE AND
REEL, ANY QUANTITY FOR BULK PACKAGING
RENCO ELECTRONICS INC.
595 International Place, Rockledge, FL 32955-4200 USA • www.rencousa.com • ISO 9001 Certified
Toll Free
Engineering Hot Line: 800.645.5828 • P: 321.637.1000 • F: 321.637.1600
221
SURFACE MOUNTS
INDUCTANCE VALUE
