5566-04B3-210

Description
4 CONTACT(S), MALE, POWER CONNECTOR, SOLDER
CategoryThe connector
File Size269KB,3 Pages
ManufacturerMolex
Websitehttps://www.molex.com/molex/home
Download Datasheet Parametric View All

5566-04B3-210 Overview

4 CONTACT(S), MALE, POWER CONNECTOR, SOLDER

5566-04B3-210 Parametric

Parameter NameAttribute value
Contact materialsNOT SPECIFIED
Total number of contacts4
Lead-freeYes
EU RoHS regulationsYes
stateDISCONTINUED
OptionsGENERAL PURPOSE
Manufacturer Series5566
Contact surface matchingNOT SPECIFIED
Contact coated terminalsNOT SPECIFIED
Connection Typepower connector
Connector male and femalePin
collocation informationMULTIPLE MATING PARTS AVAILABLE
Installation typeBOARD
Shell materialPolyamide 66
Terminal typewelding
UL flammability code94V-0
This document was generated on 05/21/2010
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMA
Part Number:
Status:
Overview:
Description:
0039302046
Active
minifit_jr
4.20mm (.165") Pitch Mini-Fit Jr.™ Header, Single Row, Vertical, with Snap-in Plastic
Peg PCB Lock, 4 Circuits, PA Polyamide Nylon 6/6, UL 94V-0, Tin (Sn) Plating, with
Drain Holes
Documents:
3D Model
Drawing (PDF)
Product Specification PS-5556-001 (PDF)
RoHS Certificate of Compliance (PDF)
Agency Certification
CSA
TUV
UL
LR19980
R72081037
E29179
General
Product Family
Series
Application
Comments
PCB Headers
5566
Wire-to-Board
Current = 13A max. per circuit when header is mated
to a receptacle loaded with 45750 Mini-Fit Plus HCS™
Crimp Terminal Crimpted to to 16 AWG wire. . See
Molex product specification PS-45750-001 for additional
current de-rating information.. High Temperature,
Square Pin, Solder Type
minifit_jr
Mini-Fit Jr.™
EU RoHS
ELV and
Complia
REACH S
Not Revie
Halogen
Status
Halogen
Need mo
environm
Email pro
For a mu
Complian
Overview
Product Name
Please vi
non-prod
Physical
Breakaway
Circuits (Loaded)
Circuits (maximum)
Color - Resin
Durability (mating cycles max)
First Mate / Last Break
Flammability
Glow-Wire Compliant
Guide to Mating Part
Keying to Mating Part
Lock to Mating Part
Material - Metal
Material - Plating Mating
Material - Plating Termination
Material - Resin
Number of Rows
Orientation
PC Tail Length (in)
PC Tail Length (mm)
PCB Locator
PCB Retention
PCB Thickness Recommended (in)
PCB Thickness Recommended (mm)
Packaging Type
Pitch - Mating Interface (in)
Pitch - Mating Interface (mm)
No
4
4
Natural
30
No
94V-0
No
No
None
Yes
Brass
Tin
Tin
Nylon
1
Vertical
0.138 In
3.50 mm
Yes
Yes
0.062 In
1.60 mm
Tray
0.165 In
4.20 mm
