CRD13003BC
(9AC) (Tin Finish Part)
LEAD FREE
TO-126
Plastic Package
NPN SILICON POWER TRANSISTOR
EC
B
Applications
Suitable for Lighting, Switching Regulator and Motor Control
ABSOLUTE MAXIMUM RATINGS
DESCRIPTION
Collector Base Voltage
Collector Emitter (sus) Voltage
Emitter Base Voltage
Collector Current Continuous
Peak
Base Current Continuous
Peak
Emitter Current Continuous
Peak
Power Dissipation at T
a
=25ºC
Derate Above 25ºC
Power Dissipation at T
c
=25ºC
Derate Above 25ºC
Operating And Storage Junction
Temperature Range
THERMAL RESISTANCE
Junction to Case
Junction to Ambient
Maximum Lead Temperature for
Soldering
Purpose: 1/8" from Case for 5 Seconds
SYMBOL
V
CBO
V
CEO
V
EBO
I
C
*I
CM
I
B
*I
BM
I
E
*I
EM
P
D
P
D
T
j,
T
stg
VALUE
700
400
9.0
1.5
3.0
0.75
1.5
2.25
4.5
1.4
11.2
45
360
- 65 to+150
UNIT
V
V
V
A
A
A
A
A
A
W
mW/ ºC
W
mW/ ºC
ºC
R
th (j-c)
R
th (j-a)
T
L
2.77
89
275
ºC/W
ºC/W
ºC
*Pulse Test: Pulse Width=5ms, Duty Cycle=10%
Web Site:
WWW.PS-PFS.COM
CRD13003BC
(9AC) (Tin Finish Part)
LEAD FREE
ELECTRICAL CHARACTERISTICS (T
a
=25ºC unless specified otherwise)
DESCRIPTION
SYMBOL
TEST CONDITION
I
C
=1mA, I
E
=0
V
CBO
Collector Base Voltage
**V
CEO (sus)
I
C
=10mA, I
B
=0
Collector Emitter (sus) Voltage
I
CBO
V
CB
=700V
,
I
E
=0
Collector Cut Off Current
V
CB
=700V
,
I
E
=0, T
c
=100ºC
I
EBO
V
EB
=9V, I
C
=0
Emitter Cut Off Current
**h
FE
I
C
=0.5A, V
CE
=5V
DC Current Gain
I
C
=2A, V
CE
=5V
Collector Emitter Saturation Voltage
**V
CE (sat)
I
C
=0.5A, I
B
=0.1A
I
C
=1A, I
B
=0.25A
I
C
=1.5A, I
B
=0.5A
I
C
=1A, I
B
=0.25A,T
c
=100ºC
Base Emitter Saturation Voltage
**V
BE (sat)
I
C
=0.5A, I
B
=0.1A
I
C
=1A, I
B
=0.25A
I
C
=1A, I
B
=0.25A, T
c
=100ºC
DYNAMIC CHARACTERISTICS
DESCRIPTION
Current Gain Bandwidth Product
Output Capacitance
SWITCHING TIME
DESCRIPTION
Turn on Time
Fall Time
Storage Time
SYMBOL
t
on
t
f
t
stg
TEST CONDITION
V
CC
=125V
I
B1
=0.2A, I
B2
=0.2A
I
C
=1A
MIN
700
400
-
-
15
4.0
-
-
-
-
-
-
-
TYP
-
-
-
-
-
-
-
-
-
-
-
-
-
MAX
-
-
1.0
5.0
1.0
22
25
0.5
1.0
2.5
1.0
1.0
1.2
1.1
UNIT
V
V
mA
mA
mA
V
V
V
V
V
V
V
SYMBOL
f
T
C
ob
TEST CONDITION
I
C
=100mA, V
CE
=10V,
f=1MHz
V
CB
=10V, f=0.1MHz
MIN
4.0
-
TYP
-
21
MAX
-
-
UNIT
MHz
pF
MIN
-
-
-
TYP
-
-
-
MAX
1.1
0.7
4.0
UNIT
µs
µs
µs
MARKING
For Lead Free Lead Finish
CRD1
3003
BC
PXYY
'T' stands for Tin finish leads
C = CDIL Logo
P = Plant Code, N for Delhi
X = Year of Manufacturer
YY = Week Code
**Pulse Test:- PW=300µs, Duty Cycle=2%
µ
Web Site:
WWW.PS-PFS.COM
CRD13003BC
(9AC) (Tin Finish Part)
LEAD FREE
CRD13003BC
Transient Thermal Resistance
20V*1.5A
20.00
Rth j-c K/W
10.00
0.00
1
10
Pt (mS)
100
1000
Web Site:
WWW.PS-PFS.COM
CRD13003BC
(9AC) (Tin Finish Part)
LEAD FREE
A
N
P
B
C
DIM
A
B
C
D
E
MIN
7.4
10.5
2.4
0.7
0.49
MAX
7.8
10.8
2.7
0.9
0.75
2.25 TYP.
4.5 TYP.
15.7 TYP.
1.27 TYP.
3.75 TYP.
3.0
3.2
1
2
3
S
F
G
1
2
3
L
L
Pin Configuration
1. Emitter
2. Collector
3. Base
M
N
P
D
E
G
F
M
2.5 TYP.
S
All dimensions in mm.
TO-126 TUBE PACKING
±0.50
532.00
±0.10
ø5.90 THRU (2 NOS)
MARKING SIDE
+0
-1.00
390.00
±0.05
ø3.10 THRU (2 NOS)
0.65
71.00
3.70
MARKING SIDE
A
R 0.50
12.00
AMMO PACK SIZE
±0.20
33.00
1.30
1.00
1.20
92.0
Label
5 38
.0 0
10.0
1.0
A
SECTION AA
75.
0
20 Tubes/Ammo Pack
1000 Pcs./Ammo Pack
3.0
3.5
1.2
3.0
PRINTING AREA
±0.1
ø5.50
3.0
3CP 66382 ANTISTATICz
6.0 2
9.0
4
20.0
03
7.0 3 7.0 3.5 7.0
PVC
6.0
ARROW
GENERAL TOLERANCE
0 mm 0.01 mm 30.01 mm 120.01 mm ABOVE
5 mm 30 mm
3.0
±0.1
±0.2
120 mm
±0.3
315 mm
±0.5
315 mm
±0.8
ANGULAR
+0
-0.1
3.0
6.5
11.0
+0
-0.1
1.0
3.0
3.35
MATL:- PVC BLACK WITH
ANTISTATIC DIPPING
END PIN (2 PCS/TUBE)
1.0
±0' 30"
DIN SYMBOL
All dimensions in mm
Notes:
1. All print in black.
2. All text in Helvetia medium font.
Packing Detail
PACKAGE
Details
TO-126 Bulk
TO-126 Tube
50 pcs/
tube
STANDARD PACK
Net Weight/
Qty
73 gm/ pcs
50
Size
3" x 7.5" x 7.5"
3" x 3.7" x 21.5"
500 pcs/
polybag 340 gm/
500 pcs
INNER CARTON BOX
Qty
2K
1K
Size
17" x 15" x 13.5"
19" x 19" x 19"
OUTER CARTON BOX
Qty
32K
10K
Gr Wt
31 kgs
15 kgs
Web Site:
WWW.PS-PFS.COM
+0
-0.1
3.3
±0.10
11.95
+0.1
R2.5
-0
7.6
