SINGLE PHASE BRIDGE RECTIFIER
RS201 THRU RS207
KBP005 THRUKBP10
FEATURES
•
•
•
•
•
VOLTAGE RANGE
CURRENT
50 to 1000 Volts
2.0 Ampere
Low cost
This series in UL recognized under component
index, file number E127707
High forward surge current capacity
Ideal for printed circuit board
High temperature soldering guaranteed:
260
O
C / 10 seconds, 0.375”(9.5mm) lead length
at 5 lbs. (2.3kg) tension.
0.20(5.1)
0.18(4.6)
0.039(1.0)
0.055(1.4)
0.600(15.2)
0.726(14.2)
0.460(11.7)
0.420(10.7)
+
AC -
0
.
5
( 2.
7
)MIN
MECHANICAL DATA
•
•
•
•
•
Case: Transfer molded plastic
Terminal: Lead solderable per MIL-STD-202E
method 208C
Polarity: Polarity symbols marked on case
Mounting position: Any.
Weight: 0.069 ounce, 1.95gram
0.60(15.2)MIN
0.160(4.1)
0.140(3.6)
0.034(0.86)DIA.
0.028(0.71)TYP.
Dimensions in inches and (millimeters)
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
•
•
•
Ratings at 25
O
C ambient temperature unless otherwise specified
Single Phase, half wave, 60Hz, resistive or inductive load
For capacitive load derate current by 20%
SYMBOLS
V
RRM
V
RMS
V
DC
I
(AV)
I
FSM
I
2
t
V
F
I
R
C
j
R
θJA
T
STG
.T
J
RS201
KBP005
50
35
50
RS202
KBP01
100
70
100
Maximum Repetitive Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Output
Current, at T
A
=50℃(Note2)
Peak Forward Surge Current
8.3mS single half sine wave superimposed on
rated load (JEDEC method)
Rating for Fusing (t<8.3mS)
Maximum Instantaneous Forward Voltage Drop
per Bridge element at 1.0 A
T
A
= 25
℃
Maximum DC Reverse Current
at Rated
DC Blocking Voltage per element T
A
= 100
℃
Typical Junction Resistance per element(Note1)
Typical Thermal Resistance per element (Note2)
Operating and Storage Temperature Rang
RS203
KBP02
200
140
200
RS204
KBP04
400
280
400
2.0
50
10
1.0
10
0.5
20
28
-55 to +150
RS205
KBP06
600
420
600
RS206
KBP08
800
560
800
RS207
KBP10
1000
700
1000
UNIT
Volts
Volts
Volts
Amps
Amps
A
2
s
Volts
µA
mA
Volts
℃/W
℃
Notes:
1.
2.
Measured at 1.0 MHz and applied reverse voltage of 4.0 Volts.
Unit mounted on P.C.board with 0.47”x0.47”(12x12cm) copper pads.0.375”(9.5mm) lead length.
Web Site:
WWW.PS-PFS.COM
