Document 186-1
SMT Power Inductors - DS1608 Series
These shielded, ultraminiature inductors can help achieve
significantly longer battery life in handheld communication
devices and other portable products.
They offer the highest efficiency, smallest size and lowest
cost of any comparable part. DCR is 10 to 60% lower
than other inductors, with greatest improvements seen
at values from 100 to 10,000 µH. Their flat top and heat
resistant materials ensure trouble-free assembly and reflow
operations.
Coilcraft
Designer’s Kit C115
contains samples of each of
the standard parts shown. To order, contact Coilcraft or visit
http://order.coilcraft.com.
Part
number
1
DS1608C-102
DS1608C-152
DS1608C-222
DS1608C-332
DS1608C-472
DS1608C-682
DS1608C-103
DS1608C-153
DS1608C-223
DS1608C-333
DS1608C-473
DS1608C-683
DS1608C-104
DS1608C-154
DS1608C-224
DS1608C-334
DS1608C-474
DS1608C-684
DS1608C-105
DS1608C-155
DS1608C-225
DS1608C-335
DS1608C-475
DS1608C-685
DS1608C-106
L ±20%
2
(µH)
1.0
1.5
2.2
3.3
4.7
6.8
10
15
22
33
47
68
100
150
220
330
470
680
1000
1500
2200
3300
4700
6800
10000
Q min
30 @ 200 kHz
30 @ 200 kHz
40 @ 200 kHz
40 @ 200 kHz
40 @ 200 kHz
40 @ 200 kHz
40 @ 200 kHz
40 @ 100 kHz
40 @ 100 kHz
40 @ 100 kHz
40 @ 100 kHz
40 @ 100 kHz
40 @ 100 kHz
40 @ 100 kHz
40 @ 100 kHz
40 @ 100 kHz
40 @ 100 kHz
40 @ 100 kHz
40 @ 100 kHz
50 @ 100 kHz
50 @ 100 kHz
50 @ 100 kHz
50 @ 100 kHz
50 @ 100 kHz
50 @ 100 kHz
DCR
max
(Ohms)
0.040
0.045
0.050
0.055
0.060
0.065
0.075
0.090
0.11
0.19
0.23
0.29
0.48
0.59
0.77
1.4
1.8
2.2
3.4
4.2
8.5
11.0
13.9
25.0
32.8
SRF
typ
(MHz)
250
125
120
120
105
50
38
33
25
20
20
15
10
9
6
5
4
3
2
2
2
1
1
1
0.8
Isat
3
(A)
1.4
0.93
0.92
0.75
0.58
0.58
0.37
0.31
0.30
0.30
0.24
0.17
0.13
0.10
0.10
0.07
0.06
0.055
0.045
0.035
0.028
0.024
0.021
0.019
0.017
0.115
max
2,92
0.260 max
6,60
0.050
1,27
0.175 max
4,45
0.090
2,29
0.055
1,40
Recommended
Land Pattern
0.160
4,06
0.140
3,56
0.170 min
4,32
0.040
1,02
0.270
6,86
Part Markings
Dash
number
1st
significant
digit
2nd
significant
digit
1. Part number on reel label will have a suffix to indicate packaging:
C = machine ready 7″ reel, B = partial reel, D = machine-ready 13″ reel.
2. Inductance tested at 0.1 Vrms, 100 kHz, 0 Adc.
3. DC current at which the inductance drops 30% (typ.) from its value
without current.
4. Operating temperature -40°C to +85°C.
5. Electrical specifications at 25°C.
See Qualification Standards section for environmental and test data.
See Color Coding section for part marking data.
Weight:
144 – 167 mg
Terminations:
Nickel/gold over moly-manganese
Tape and reel:
750/7″ reel; 2500/13″ reel 12 mm tape width
For packaging data see Tape and Reel Specifications section.
Specifications subject to change without notice.
Please check our website for latest information. Document 186-1
XXX
Multiplier
Revised 12/22/04
