CT-39S86O-TD Overview

RF Coaxial Relay

CT-39S86O-TD Parametric

Parameter Name	Attribute value
Maker	Teledyne Technologies Incorporated
Reach Compliance Code	compliant
ECCN code	EAR99
Relay type	RF COAXIAL RELAY

Preview

Download Datasheet

View All

Elite

CT-39

Latching

Multi-Throw Internal Terminations DC-22GHz

The CT-39 Switch is a Internally Terminated broadband, multi-throw, electromechanical coaxial

switch designed to switch a microwave signal from a common input to any of 3, 4, 5, or 6 outputs.

The characteristic impedance is 50 Ohms. Internal terminations provide an impedence match for the

unselected ports. The switches are small using the popular connector spacing on a 1.062" dia.

circle. Each position has an individual actuator mechanism allowing random position selection. This

also minimizes switching time.

Specifications

RF Contacts:

Actuator

Break before make

Voltage (VDC) 20

Latching Current (mA)

Positions

255

205

The CT-39 comes with a latching actuator. The latching switch

remains in the last position selected when the switch is de-energized.

STD dual command requires a reset pulse before a new selected

position. A separate reset circuit allows all positions to be set to an

open position. User must provide both reset (clear) and set (select

new position) commands.

Shock:

MIL-STD-202 Method 213, Condition D (500G

Non Operating)

MIL-STD-202 Method 214, Condition D (10G

RMS Non Operating)

Moisture Seal Available

Reset Current (mA)

765

615

270

360

Vibration:

Humidity:

4 1020 820

5 1275 1025 450

6 1530 1230 540

Switching Time:

Terminations:

Connectors:

Weight:

20 msec max

50 Ohm 2 Watts CW max

SMA (f)

6 oz. max

Typical Contact Life:

5 Million

Cycles

Insertion Loss Repeatability (1 Million Cycles):

DC to 6 GHz: 0.05 dB

DC to 20 GHz: 0.1 dB

Temperature Range:

-55

C to +85

C (Operating)

RF Power Handling (Non-Terminated)

Typical Performance

3000

800

400

Sta

Power CW (Watts)

nda

rd S

200

onn

ect

ors

Return Loss

0.01

Frequency GHz

22.0

1.0

4.0

Frequency GHz

18 22

0.4

IL dB

Specifications

DC-6 GHz 6-12 GHz 12-18 GHz 18-22 GHz

1.40:1

0.40 dB

60.0 dB

1.50:1

0.50 dB

60.0 dB

1.80:1

0.80 dB

50.0 dB

VSWR (max)

1.25:1

Insertion Loss (max) 0.20 dB

Isolation (min)

70.0 dB

0.01

Frequency GHz

22.0

Specifications subject to change without notice.

www.teledynecoax.com

email: coax@teledyne.com

Tel: (800) 351-7368

10/2007

Isolation dB

0.1

0.0
