SMD Crystal Oscillators
DSO753H SERIES
Features
Available with three types of output functions:
CMOS, PECL, LVDS
●
Differential output (PECL, LVDS)
●
Low jitter
●
3-state function
●
RoHS Compliant
Applications
●
Actual size
Optical transmission device,
radio transmitter-receiver equipment
Standard Specification
Item
Output Specification
Output Frequency Range
Supply Voltage
Storage Temperature Range
Operating Temperature Range
Frequency Tolerance
Current Consumption
Output Load
Symmetry
Rise and Fall Time
0 Level Output Voltage
1 Level Output Voltage
Differential Output Voltage
Change to V
OD
Offset Voltage
Change to V
OS
Output Enable Time
Output Disable Time
OE Pin 0 Level Input Voltage
OE Pin 1 Level Input Voltage
Packing Unit
Type Legend
−
fo
Vdd
T_stg
T_use
f_tol
Idd
L_
CMOS
SYM
tr, tf
Vol
Voh
V
OD1
, V
OD2
⊿V
OD
V
OS1
, V
OS2
⊿V
OS
Ｔpzl
Ｔplz
Vil
Vih
50mA max.
15pF max.
45∼55%[50% V
dd
Level]
2.0ns max.[10∼90% V
dd
Level]
V
dd
×0.1 max.
V
dd
×0.9 min.
−
−
−
−
DSO753HV
CMOS
150∼230MHz
DSO753HK
LV-PECL
160∼230MHz
＋3.3±0.165V
−40∼85℃
−20∼70℃
±50×10
−6
max.
80mA max.
50Ω to V
dd
−2V
60mA max.
100Ω Output−OUTN
DSO753HJ
LVDS
160∼230MHz
45∼55%[at outputs cross point]
1.0ns max.[20∼80% Output Level]
V
dd
−1.025∼V
dd
−0.88V
V
dd
−1.81∼V
dd
−1.62V
−
−
−
−
2ms max.
200ns max.
Vdd×0.7 min.
Vdd×0.3 max.
−
−
0.247∼0.454V
50mV[⊿V
OD
=½V
OD1
−V
OD2
½]
1.125∼1.375V
100mV[⊿V
OS
=½V
OS1
−V
OS2
½]
100pcs. / reel or 500pcs. / reel（φ180）
Consult our sales representative for other specifications.
Dimensions[mm]
7.0±0.2
Frequency
Model Code
DSO753HV→O753HV
DSO753HK→O753HK
DSO753HJ →O753HJ
Logo
Lot No.
Pin Connections
Pin No. Connection
#1
OE(Output Enable)
NC
#2
GND
#3
Output
#4
#5
NC
- DSV753HV
OUTN - DSV753HK
DSV753HJ
#6
Function
#1 input
H
Open
L
V
dd
Recommended Land Pattern
[mm]
〈Top View〉
2.54
2.54
#1 Index
2.0±0.2
5.0±0.2
2.54
2.54
#1
#2
#3
4.2
2.6
#6
1.4
#5 #4
#4,#5 output condition
Oscillation out
Oscillation out
High Z
1.8
2.0
