High-Efficiency CCFL Backlight
Controller with SMBus Interface
General Description
Features
♦
Synchronized to Resonant Frequency
Longer Lamp Life
Guaranteed Striking Capability
High Power-to-Light Efficiency
♦
Wide Input Voltage Range (4.6V to 28V)
♦
Feed Forward for Excellent Line Rejection
♦
SMBus Dimming Control Interface
♦
10:1 Dimming Range
♦
Guaranteed 200Hz to 220Hz DPWM Frequency
♦
Secondary Voltage Limit Reduces Transformer
Stress
♦
Adjustable Lamp-Out Protection with 1s Timer
♦
Secondary Current Limit Protects Against High-
Voltage Short Circuits to Ground
♦
Small 5mm x 5mm Thin QFN Package
MAX8709/MAX8709A
The MAX8709/MAX8709A integrated backlight controller
are optimized to drive cold-cathode fluorescent lamps
(CCFLs) using a resonant full-bridge inverter architecture.
The resonant operation maximizes striking capability and
provides near-sinusoidal waveforms over the entire input
range to improve CCFL lifetime. The controller operates
over a wide input voltage range of 4.6V to 28V with high
power-to-light efficiency. The device also includes safety
features that effectively protect against many single-point
fault conditions including lamp-out and short-circuit faults.
The MAX8709/MAX8709A achieve 10:1 dimming range
by “chopping” the lamp current on and off using a digital
pulse-width-modulation (DPWM) method. The minimum
DPWM duty cycle of the MAX8709 is 9.375% and the
minumum duty cycle of the MAX8709A is 12.5%. The
brightness is controlled with a 2-wire SMBus™-compati-
ble interface. The device directly drives the four external
N-channel power MOSFETs of the full-bridge inverter. An
internal 5.3V linear regulator powers the MOSFET dri-
vers, the DPWM oscillator, and most of the internal cir-
cuitry. The MAX8709/MAX8709A are available in a
space-saving 28-pin thin QFN package and operates
over a -40°C to +85°C temperature range.
Ordering Information
PART
MAX8709ETI
MAX8709AETI
TEMP RANGE
-40°C to +85°C
-40°C to +85°C
PIN-PACKAGE
28 Thin QFN 5mm x 5mm
28 Thin QFN 5mm x 5mm
Applications
Notebook Computer Displays
LCD Monitors
SMBus is a trademark of Intel Corp.
LCD TVs
Automotive Displays
Pin Configuration appears at end of data sheet.
Minimal Operating Circuit
V
IN
BATT
V
CC
V
DD
BST2
BST1
REF
GH1
GND
LOT
MAX8709/
MAX8709A
ILIM
LX1
LX2
GL1
CCV
PGND
CCI
GL2
GH2
SUS
SDA
SCL
VFB
ISEC
IFB
