Part Number:
Status:
Description:
0942403818
Active
2.54mm (.100") Pitch, MOX Header, 3.50mm (.137") Grid, Through Hole, PBT, Vertical,
18 Circuit, Gray
Documents:
3D Model
Drawing (PDF)
Product Specification PS-94240-001 (PDF)
RoHS Certificate of Compliance (PDF)
General
Product Family
Series
Application
Product Name
PCB Headers
94240
Wire-to-Board
MOX
Physical
Breakaway
Circuits (Loaded)
Circuits (maximum)
Color - Resin
Durability (mating cycles max)
First Mate / Last Break
Glow-Wire Compliant
Lock to Mating Part
Material - Metal
Material - Plating Mating
Material - Plating Termination
Material - Resin
Number of Rows
Orientation
PC Tail Length (in)
PC Tail Length (mm)
PCB Locator
PCB Retention
PCB Thickness Recommended (in)
PCB Thickness Recommended (mm)
Packaging Type
Pitch - Mating Interface (in)
Pitch - Mating Interface (mm)
Plating min: Mating (µin)
Plating min: Mating (µm)
Plating min: Termination (µin)
Plating min: Termination (µm)
Polarized to Mating Part
Polarized to PCB
Shrouded
Stackable
Surface Mount Compatible (SMC)
Temperature Range - Operating
Termination Interface: Style
No
18
18
Natural
100
No
No
Yes
Brass
Tin
Tin
Polyester
2
Vertical
0.130 In
3.30 mm
Yes
Yes
0.062 In
1.60 mm
Tray
0.100 In
2.54 mm
120
3
120
3
Yes
Yes
Partial
No
No
-25°C to +105°C
Through Hole
EU RoHS
ELV and
Complia
REACH S
Not Revie
Halogen
Status
Not Revi
Need mo
environm
Email pro
For a mu
Complian
Please vi
non-prod
Search
94240S
Mates
98695
Electrical
Current - Maximum per Contact
Voltage - Maximum
6A
125V
Solder Process Data
Duration at Max. Process Temperature (seconds)
Lead-free Process Capability
Max. Cycles at Max. Process Temperature
Process Temperature max. C
10
Wave Capable (TH only)
3
250
Material Info
Reference - Drawing Numbers
Product Specification
Sales Drawing
PS-94240-001
SD-94240-003
