New
Spatializer I C A N 7 3 9 9 / S
s
Overvlew
A proprietary signal processing technology developed for the consumer
electronics and multi-media markets, the 3D Stereo integrated circuit is based on
technology derived from Desper Products multi-channel PRO 3D Audio Production
System.
The AN7399 makes use of this innovative technology to enhance and expand
existing stereo program material delivered by conventional 2 speaker stereo system.
(0.71)
SEATING PLANE
2.54
0.5±0.1
1.22±0.25
AN7399
19.2±0.3
16
9
Unit : mm
1
8
3.55±0.05
1.10±0.25
3.05±0.25
5.20±0.25
6.2±0.3
s
Features
q
Fewer external components.
(The minimum external components are 4 capacitors.)
q
Supply voltage ; 4.5 to 10V
7.62±0.25
5
°
3 to 1
+0.10
0.30
– 0.05
DIP016-P-0300D
AN7399S
10.1±0.3
16
9
Unit : mm
s
Applications
q
CD, radio casset recorders
q
Stereo-televisions, VCRs
q
Computer sound boards
4.2±0.3
6.5±0.3
(0.15)
0.3
1.5±0.2
(0 to 10°)
1
8
s
Application Circuit
(0.605)
1.27
0.40±0.25
SEATING PLANE
0.1±0.1
SEATING PLANE
SOP016-P-0225A
Spatializer ON (2.7V to Vcc)
Spatializer OFF
Vcc
10µF
L
IN
4.7nF
10µF
L
OUT
0 to 50kΩ
16
15
14
13
12
11
10
9
AN7399/S
1
2
3
4
5
6
7
8
56nF
R
IN
10µF
R
10µF
R
OUT
4.7nF
10µF
SPATIALIZER and the circle-in-square device trademarks are owned by Desper Products, Inc.
¶ The products and specifications are subject to change without any notice. Please ask for the latest product standards to guarantee the satisfaction of your product requirements.
Semiconductor Company, Matsushita Electronics Corporation
1 Kotari Yakemachi, Nagaokakyo, Kyoto, 617-8520 Japan
E00039AE
Tel. (075) 951-8151
http://www.mec.panasonic.co.jp
New publication, effective from June 16 1999.
s
Electrical Characteristics(Ta=25°C±2°C,Vcc=9V,unless otherwise specified.)
Parameter
Total Gain (OFF mode)
Total Harmonic Distortion (OFF mode)
Total Harmonic Distortion (ON mode)
Symbol
V
FFG
THD
FF
THD
ON
N
FF
N
ON
CT
V
MAX
I
TOTAL
V
OFF
V
ON
Condition
V
in
=1Vrms,f=1kHz
V
in
=1Vrms,f=1kHz
V
in
=0.4Vrms,f=1kHz
V
in
=0mVrms,Rg=4.7kΩ
V
in
=0mVrms,Rg=4.7kΩ
V
in
=1Vrms,f=1kHz
THD=1%,f=1kHz
V
in
=0mVrms
min
-1
—
—
—
—
—
2.0
0.8
0
2.7
typ
0
0.01
0.02
5
7
-95
2.4
1.4
—
—
max
1
0.05
0.1
15
20
-75
—
2.0
0.5
Vcc
Unit
dB
%
%
µVrms
µVrms
dB
Vrms
mA
V
V
Note
1
1
1
2
2
1
1
Output Noise Level (OFF Mode)
Output Noise Level (ON Mode)
Cross-Talk (OFF Mode)
Input Level (OFF Mode)
Total Circuit Current
OFF Mode Threshold Voltage
ON Mode Threshold Voltage
Note1) Use DIN AUDIO Filter.
Note2) Use "A" Curve Filter.
s
Circuit with minimum external parts
Spatializer ON/OFF
Vcc
L
IN
L
OUT
16
15
14
13
12
11
10
9
AN7399/S
1
2
3
4
5
6
7
8
It is not necessary input capacitors and output capacitors.
Condition
1) Vcc of AN7399 are same as Pre.-Amp. and Power-Amp.
2) Vref.of Pre.-Amp. and Vref.of Power-Amp. are 1/2Vcc.
3) Input impedance of Power-Amp. is higher than 20kΩ.
R
OUT
R
IN
s
Licensing agreement :
Signature between customer and Desper Products, Inc.
