ACHF
CONNECTOR
Circuit No.
No. of circuits
Emboss Tape
1.2mm pitch/Disconnectable Crimp style connectors
Specifications –––––––––––––––––––
• Current rating: 2.5 A AC, DC (AWG #28)
(Signal circuit of 4 and 6 circuits is 1.0 A.)
Current unit: A
1
2.5
2.5
2.5
2
2.5
1.0
2.5
3
2.5
1.0
1.0
4
2.5
1.0
5
6
3
4
6
2.5
2.5
• Voltage rating: 50 VAC, DC
• Temperature range:
-
25˚C to
+
85˚C
(including temperature rise in applying
electrical current)
• Contact resistance: Initial value/ 10 mΩ max.
After environmental tests/ 20 mΩ max.
• Insulation resistance: 100
Ω
min.
• Withstanding voltage: 500 VAC/minute
• Applicable wire: Conductor size/ AWG #30 to #28
Insulation O.D./ 0.5 to 0.63 mm
This ACHF connector is compact and low
profile type, height 1.43mm and width 4.95mm,
1.2mm pitch wire-to-board connector.
• High-strength
• Top entry but side feed type
• Connector for power supply
(Power supply circuit: 2.5 A, Signal circuit: 1.0 A )
* Refer to "General Instruction and Notice when using
Terminals and Connectors" at the end of this catalog.
* Contact JST for details.
* Compliant with RoHS.
Standards–––––––––––––––––––––––
0
Recognized E60389
PC board layout and Assembly layout
5.1
±0.03
3.25
±0.03
2.9
±0.03
1.05
±0.03
0.7
±0.05
0.6
±0.05
+0.1
0
1.2
4.95
A
±0.05
B
±0.05
1.1
±0.03
Circuits
3
4
6
Dimensions (mm)
A
B
2.4
3.6
6.0
5.5
6.7
9.1
Connector outline
0.35
Note: 1. The above figure is the figure viewed from the connector mounting side.
2. Tolerances are non-cumulative:
±
0.05 mm for all centers. The dimensions above should serve as a guideline. Contact JST for details.
Contact
Model No.
SACHF-003GAC-P0.2
3.55
1.45
0.7
1.2
0.85
Applicable wire
mm
2
AWG#
0.05∼0.08
30∼28
Insulation O.D. (mm) Q'ty/reel
0.5∼0.63
40,000
Material and Finish
Copper alloy, nickel-undercoated, gold-plated
RoHS compliance
Crimping
machine Crimp applicator
MKS-L-10-4
―
0.5
Contact
Applicator
Dies
―
Crimp applicator with dies
―
SACHF-003GAC-P0.2
AP-K2N
MK/SACHF-003-02 APLMK SACHF003-02
1
(1.43)
ACHF CONNECTOR
Housing
Circuits
Circuit No.1 mark
Model No.
ACHFR-03V-H
ACHFR-04V-H
ACHFR-06V-H
Material
PBT, UL94V-HB, gray
Dimensions (mm)
A
2.4
3.6
6.0
B
3.8
5.0
7.4
Q'ty/
bag
1,000
1,000
1,000
3
4
1.2
6
B
A
RoHS compliance
3.95
0.5
Shrouded header
Circuits
Circuit No.1 mark
1.2
Model No.
BM03B-ACHFKS-GACN-ETF
BM04B-ACHFKS-GACN-ETF
BM06B-ACHFKS-GACN-ETF
Material and Finish
Dimensions (mm)
A
2.4
3.6
6.0
B
6.1
7.3
9.7
Q'ty/
reel
6,000
6,000
6,000
3
4
6
B
A
1.2
Contact: Copper alloy, nickel-undercoated, gold-plated (nickel-stripe)
Housing: Heat resisting resin, UL94V-0, black
Reinforcement: Copper alloy, copper-undercoated, tin-plated (reflow treatment)
3
RoHS compliance
This product displays (LF)(SN) on a label.
Note: The products listed above are supplied on embossed-tape.
4.95
1.43
2
Mobile and portable
