MODEL HM75 SERIES
High Current
Surface Mount Inductors
Inductance Range: 0.33 to 100µH
Rated Current: Up to 19 Amps
NEW PRODUCT
FEATURES AND BENEFITS
•
•
•
•
High performance, high current rating
Low profile, small footprint designed for machine placement
Compatible with vapor phase and infrared reflow soldering
Self-leaded design, excellent for high current applications
APPLICATIONS
•
•
•
•
•
Note book computers, PDA’s
DC/DC converters for mother board applications
Battery charging circuits
EMI filters
Inductor for general purpose
ELECTRICAL / ENVIRONMENTAL
Operating Temperature Range
Storage Temperature Range
Ambient Temperature, Maximum
Insulation System
Temperature Rise, Maximum
Specifications subject to change without notice.
Last Update: 03/17/2003.
-40°C to +125°C
-40°C to +85°C
85°C
Class B, 130°C
40°C
6
6-149
Model HM75 Series
SPECIFICATIONS
Part
Number
HM75-10R47
HM75-101R0
HM75-101R5
HM75-102R2
HM75-103R3
HM75-104R7
HM75-106R8
HM75-10100
HM75-10150
HM75-10220
HM75-10330
HM75-10470
HM75-20R33
HM75-20R68
HM75-201R0
HM75-201R5
HM75-202R2
HM75-202R7
HM75-203R3
HM75-204R7
HM75-20100
HM75-20150
HM75-20220
HM75-20330
HM75-20470
HM75-20680
HM75-20101
HM75-30R47
HM75-301R0
HM75-301R5
HM75-302R2
HM75-303R3
HM75-304R7
HM75-306R8
HM75-30100
HM75-30150
– Rated Inductance –
L w/o DC
L
DC
L
O
(1)
µH Typical
µH ±20%
0.47
0.47
1.0
1.0
1.5
1.6
2.2
2.26
3.3
3.45
4.7
4.85
6.8
6.9
10
10.4
15
15.3
22
23
33
33.6
47
48.5
0.33
0.33
0.68
0.80
1.0
1.1
1.5
1.5
2.2
2.3
2.7
2.9
3.3
3.3
4.7
4.8
10
10.0
15
15.43
22
22.5
33
33.2
47
48.7
68
68.2
100
103
0.47
0.45
1.0
1.34
1.5
1.65
2.2
2.3
3.3
3.44
4.7
5.0
6.8
6.9
10
11
15
16.4
DC
Resistance
Max.
(4)
mΩ
7.9
12.5
14.5
24.1
31.8
54.7
57.1
81.3
124
183
265
334
2.0
3.5
4.6
6.1
7.8
10.0
11.0
15.1
35
45
62
92
139
177
237
2.1
3.8
4.9
5.1
10
11.4
17.8
22.8
35.0
Rated
Current
I
RMS
(2)
Amps
6.0
4.4
4.2
3.1
2.9
2.2
1.7
1.5
1.2
1.0
0.82
0.72
16
12
10
9
7.4
6.6
5.9
4.8
3.3
3.1
2.8
2.1
1.7
1.5
1.2
16
12.5
10
9.2
8.0
6.5
5.8
4.3
3.9
I
SAT
(3)
Amps
7.7
5.3
4.5
3.5
3.0
2.6
2.2
1.9
1.5
1.2
0.99
0.87
20
13
11
9
7.8
7.0
6.4
5.4
4.3
3.0
2.0
1.7
1.4
1.2
0.95
25.1
15.3
12
10.2
9.3
7.7
6.2
5.2
4.3
Notes: (1) Inductance measured at 100 kHz, 100 mVrms, OADC.
(2) RMS current is the approximate current at which inductance will decrease by 10%.
from its initial value (zero DC) or the DC current at which
∆T
= 40°C, whichever is lower.
(3) Saturation current for approximately 30% roll-off.
(4) DC resistance measured at 20°C.
6-150
Model HM75 Series
SPECIFICATIONS
Part
Number
HM75-30220
HM75-30330
HM75-30470
HM75-30680
HM75-30101
HM75-40R47
HM75-401R0
HM75-401R3
HM75-402R2
HM75-403R3
HM75-403R9
HM75-404R7
HM75-406R0
HM75-407R8
HM75-40100
HM75-40150
HM75-40220
HM75-40330
HM75-40470
HM75-40680
HM75-40101
HM75-50R78
HM75-501R0
HM75-501R5
HM75-502R2
HM75-503R3
HM75-503R9
HM75-504R7
HM75-507R5
HM75-50100
HM75-50150
HM75-50220
HM75-50330
HM75-50470
HM75-50680
HM75-50101
– Rated Inductance –
L w/o DC
L
DC
L
O
(1)
µH Typical
µH ±20%
22
23.9
33
33.9
47
51
68
69.5
100
101.4
0.47
0.47
1.0
0.92
1.3
1.3
2.2
2.2
3.3
3.3
3.9
3.9
4.7
5.3
6.0
6.0
7.8
7.8
10
10.0
15
15.6
22
22.6
33
34.5
47
48.0
68
69.2
100
103
0.78
0.78
1.0
0.92
1.5
1.52
2.2
2.27
3.3
3.2
3.9
4.0
4.7
4.7
7.5
7.5
10
10
15
15
22
22
33
33
47
47
68
68
100
100
DC
Resistance
Max.
(4)
mΩ
49.1
69
108.2
156
205.5
1.7
2.5
3.5
4.7
8.4
7.5
9.5
13.7
15.4
22.0
29.5
34
52
71
104
156
2.6
3.1
4.0
5.6
7.0
10
9.5
15
40
50
66
80
110
170
220
Rated
Current
I
RMS
(2)
Amps
3.1
2.4
1.9
1.6
1.4
19.2
17.3
15
12
10
9
8.5
7.5
7.5
6.0
5.5
4.5
3.7
3.1
2.4
2.0
15
17.3
15
12
11
9
6.5
6
3.5
3.0
2.5
2.0
1.6
1.2
1.2
I
SAT
(3)
Amps
3.7
3.0
2.4
2.0
1.8
51.7
37.3
25
20
17
15
15
12
11
10
9.1
7.6
6.1
5.2
4.3
3.6
30
37.3
28.9
23.7
20.0
15
10.7
9.8
8.0
7.0
5.5
4.0
3.8
3.0
2.5
6
Notes: (1) Inductance measured at 100 kHz, 100 mVrms, OADC.
(2) RMS current is the approximate current at which inductance will decrease by 10%.
from its initial value (zero DC) or the DC current at which
∆T
= 40°C, whichever is lower.
(3) Saturation current for approximately 30% roll-off.
(4) DC resistance measured at 20°C.
6-151
Model HM75 Series
OUTLINE DIMENSIONS (Inch/mm)
A Max.
Case
Size
B Max.
10
20
C Max.
30
40
A
.350
8.89
.530
13.46
.768
19.5
.865
21.97
.530
13.46
B
.240
6.09
.395
10.03
.52
13.21
.60
15.24
.395
10.03
C
.217
5.5
.270
6.90
.283
7.2
.315
8.0
.50
12.7
D
.29
7.37
.410
10.41
.610
15.5
.690
17.53
.410
10.41
E
.137
3.48
.135
3.43
.135
3.43
.150
3.81
.135
3.43
F
.225
5.72
.295
7.49
.283
7.2
.370
9.40
.295
7.49
Recommended Solder Pad Layout
E
F
D
50
PACKAGING
Standard:
Embossed Tape & Reel
Reel:
Diameter
Capacity: Case size 10
Case size 20
Case size 30
Case size 40
Case size 50
=
=
=
=
=
=
13” (330.2mm)
1,000 Units
550 Units
450 Units
275 Units
250 Units
ORDERING INFORMATION
HM75
Model Series
Case Size
20
101
Inductance Code:
1st two digits are significant.
Last digit denotes number of
trailing zeros. Values below
10µH "R" denotes decimal point.
6-152
