ISL6532BCR: DescriptionSWITCHING CONTROLLER, 280kHz SWITCHING FREQ-MAX, PQCC20, 6 X 6 MM, PLASTIC, MO-220VJJB, QFN-20; CategoryPower/power management The power supply circuit; File Size754KB，15 Pages; ManufacturerRenesas Electronics Corporation; Websitehttps://www.renesas.com/

Download Datasheet Parametric Compare View All

ISL6532BCR Overview

SWITCHING CONTROLLER, 280kHz SWITCHING FREQ-MAX, PQCC20, 6 X 6 MM, PLASTIC, MO-220VJJB, QFN-20

ISL6532BCR Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	Renesas Electronics Corporation
Parts packaging code	QFN
package instruction	6 X 6 MM, PLASTIC, MO-220VJJB, QFN-20
Contacts	20
Reach Compliance Code	not_compliant
ECCN code	EAR99
Analog Integrated Circuits - Other Types	SWITCHING CONTROLLER
control mode	VOLTAGE-MODE
Control Technology	PULSE WIDTH MODULATION
Maximum input voltage	5.5 V
Minimum input voltage	4.5 V
Nominal input voltage	5 V
JESD-30 code	S-PQCC-N20
JESD-609 code	e0
length	6 mm
Humidity sensitivity level	2
Number of functions	1
Number of terminals	20
Maximum operating temperature	70 °C
Minimum operating temperature
Package body material	PLASTIC/EPOXY
encapsulated code	HVQCCN
Encapsulate equivalent code	LCC20,.23SQ,32
Package shape	SQUARE
Package form	CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE
Peak Reflow Temperature (Celsius)	240
Certification status	Not Qualified
Maximum seat height	1 mm
surface mount	YES
Switch configuration	PUSH-PULL
Maximum switching frequency	280 kHz
Temperature level	COMMERCIAL
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	NO LEAD
Terminal pitch	0.8 mm
Terminal location	QUAD
Maximum time at peak reflow temperature	NOT SPECIFIED
width	6 mm

Preview

Download Datasheet

View All

DATASHEET

ISL6532B

ACPI Regulator/Controller for Dual Channel DDR Memory Systems

The ISL6532B provides a complete ACPI compliant power

solution for up to 4 DIMM dual channel DDR/DDR2 memory

systems. Included are both a synchronous buck controller

and integrated LDO to supply V

DDQ

with high current during

S0/S1 states and standby current during S3 state. During

Run mode, a fully integrated sink-source regulator generates

an accurate (V

DDQ

/2) high current V

voltage without the

need for a negative supply. A buffered version of the V

DDQ

reference is provided as V

REF

The switching PWM controller drives two N-Channel

MOSFETs in a synchronous-rectified buck converter

topology. The synchronous buck converter uses voltage-

mode control with fast transient response. Both the switching

regulator and integrated standby LDO provide a maximum

static regulation tolerance of



2% over line, load, and

temperature ranges. The output is user-adjustable by means

of external resistors down to 0.8V.

Switching the memory core output between the PWM

regulator and the standby LDO during state transitions is

accomplished smoothly via the internal ACPI control

circuitry. The NCH signal provides synchronized switching of

a backfeed blocking switch during the transitions

eliminating

the need to route 5V Dual to the memory supply.

An integrated soft-start feature brings V

DDQ

into regulation

in a controlled manner when returning to S0/S1 state from

S4/S5 or mechanical off states. During S0 the PGOOD

signal indicates that all supplies are within spec and

operational.

Each output is monitored for under and over-voltage events.

Current limiting is included on the V

and V

DDQ

standby

regulators. Thermal shutdown is integrated.

FN9120

Rev 3.00

Jul 2004

Features

• Generates 2 Regulated Voltages

- Synchronous Buck PWM Controller with Standby LDO

- 3A Integrated Sink/Source Linear Regulator with

Accurate V

DDQ

/2 Divider Reference

- Glitch-free Transitions During State Changes

• ACPI Compliant Sleep State Control

• Integrated V

REF

Buffer

• PWM Controller Drives Low Cost N-Channel MOSFETs

• 250kHz Constant Frequency Operation

• Tight Output Voltage Regulation

- Both Outputs:



2% Over Temperature

• 5V or 3.3V Down Conversion

• Fully-Adjustable Outputs with Wide Voltage Range: Down

to 0.8V supports DDR and DDR2 Specifications

• Simple Single-Loop Voltage-Mode PWM Control Design

• Fast PWM Converter Transient Response

• Over Current Protection on V

and Under/Over-Voltage

Monitoring of Both Outputs

• Integrated Thermal Shutdown Protection

• QFN Package Option

- QFN Compliant to JEDEC PUB95 MO-220 QFN - Quad

Flat No Leads - Product Outline

- QFN Near Chip Scale Package Footprint; Improves

PCB Efficiency, Thinner in Profile

•

Pb-free available

Applications

• Single and Dual Channel DDR Memory Power Systems in

ACPI compliant PCs

• Graphics cards - GPU and memory supplies

• ASIC power supplies

• Embedded processor and I/O supplies

• DSP supplies

Pinout

ISL6532B (QFN)

TOP VIEW

UGATE

LGATE

P12V

S5#

S3#

15 NCH

14 PGOOD

13 GND

12 COMP

11 FB

VDDQ

VTTSNS

P5VSBY

VREF_OUT

VREF_IN

20 19 18 17 16

5VSBY 1

GND 2

VTT 3

VTT 4

VDDQ 5

Ordering Information

TEMP. RANGE

PART NUMBER

(

ISL6532BCR

ISL6532BCRZ

(See Note)

0 to 70

PACKAGE

20 Ld 6x6 QFN

(Pb-free)

PKG. DWG. #

L20.6x6

*Add “-T” suffix to part number for tape and reel packaging.

NOTE: Intersil Pb-free products employ special Pb-free material sets; molding

compounds/die attach materials and 100% matte tin plate termination finish, which

is compatible with both SnPb and Pb-free soldering operations. Intersil Pb-free

products are MSL classified at Pb-free peak reflow temperatures that meet or

exceed the Pb-free requirements of IPC/JEDEC J Std-020B.

FN9120 Rev 3.00

Jul 2004

Page 1 of 15
