3.3V Surface Mount
Crystal Clock Oscillator
HSM6
XO)
2111 Comprehensive Drive
2111 Comprehensive Drive
Aurora, Illinois 60505
Aurora, Illinois 60505
Phone: 630- 851- 4722
Phone: 630- 851- 4722
Fax: 630- 851- 5040
Fax: 630- 851- 5040
www.conwin.com
www.conwin.com
US Headquarters:
630-851-4722
European Headquarters:
+353-61-472221
Features:
1.0 to 170 MHz
3.3V Operation
RoHS Compliant
Tri-State Enable/Disable
Power Saving Function: 10uA When Disabled
Overall Frequency Tolerance:
HSM613 ± 25 ppm
HSM623 ± 50 ppm
HSM633 ± 100 ppm
Temperature Range: -40 to 85°C
Ceramic Surface Mount Package
Tape and Reel Packaging
The Connor-Winfield HSM613, HSM623,
and HSM633 are 7.5mm x 5mm, 3.3V
HCMOS, Surface Mount, Fixed Frequency
Crystal Oscillators (XO) designed for use in all
applications requiring precision clocks. The RoHS
compliant surface mount package is designed for
high-density mounting and is optimum for mass
production.
Absolute Maximum Ratings
Parameter
Storage Temperature
Supply Voltage (Vcc)
Minimum
-55
-0.5
Nominal
-
-
Maximum
125
5.0
Units
°C
Vdc
Notes
Operating Specifications
Parameter
Frequency Range (Fo)
HSM613
HSM623
HSM633
Frequency Tolerance
HSM613
HSM623
HSM633
Operating Temp Range
Supply Voltage (Vdd)
Supply Current (Icc)
1.000 to 31.999 MHz
32 to 49.999 MHz
50 to 66.999 MHz
67 to 124.999 MHz
125 to 170 MHz
Minimum
1.0
Nominal
-
Maximum
125
170
170
25
50
100
85
3.6
15
20
25
40
50
Units
MHz
Notes
-25
-50
-100
-40
3.0
-
-
ppm
1
-
3.3
-
°C
Vdc
mA
Input Characteristics
Parameter
Enable Voltage - (Vih)
Disable Voltage - (Vil)
Enable Time
Disable Time
Output Disable Current (lcc)
≥
70% Vdd
-
-
-
-
Minimum
Nominal
-
-
-
-
-
-
≤
30% Vdd
10
150
10
Maximum
Units
Vdc
Vdc
mS
nS
uA
Notes
2
HCMOS Output Characteristics
Parameter
Load
Voltage High (Voh)
Low (Vol)
Current High (loh)
Low (lol)
Duty Cycle at 50% of Vcc
Rise / Fall Time: 20% to 80%
1.000 to 19.999 MHz
20.00 to 49.999 MHz
50.00 to 99.9999 MHz
100.00 to 170 MHz
Start-Up Time
Jitter
(10 Hz to 20 MHz)
(12 kHz to 20 MHz)
Notes:
Minimum
-
2.91
-
-2
-
45
-
-
-
-
-
-
-
Nominal
-
-
-
-
-
50
Maximum
15
-
0.33
-
2
55
6.0
4.0
3.0
1.0
10
5
1
Units
pF
Vdc
mA
%
nS
Notes
Bulletin
Revision
Date
Sm044
13
27 March 2012
3.0
2.0
1.5
0.5
-
-
-
mS
pS RMS
1. Inclusive of calibration @ 25°C , frequency stability vs temperature, supply voltage change, load change, shock and vibration, 10 years aging.
2. Oscillator output is enabled with no connection on pad 1
Specifications subject to change without notice. All dimensions in inches. © Copyright 2012 The Connor-Winfield Corporation
2111 Comprehensive Drive
Aurora, Illinois 60505
Phone: 630- 851- 4722
Fax: 630- 851- 5040
www.conwin.com
Package Characteristics
Package
Hermetically sealed ceramic package and metal cover
Suggested Pad Layout
Environmental Characteristics
Temperature Cycle The specimen shall meet electrical characteristics after
tested 5 cycles of -55°C / 30 minutes and +125°C / 30 minutes
Hermetical No bubbles appear in Flourinert (FC-43) at 125°C ±5°C for 5 minutes
Solvent Resistance
Marking will withstand immersion in
Isopropyl Alcohol or Trichloroethylene
Soldering
260°C max x 10 sec max x 2 times max or
230°C max x 180 sec max x 1 time
Typical Operation Data
(Vapor phase reflow)
20 to 100 sec up to 215°C, 50 sec
at 215°C, then down to room temperature per 1 to 5°C / sec
General Conditions
Test Circuit
Mechanical Characteristics
The specimen shall meet electrical characteristics after tested 3 times,
Free Drop testing on the hard wooden board from a height of 75 cm.
Vibration
The specimen shall meet electrical characteristics after tested
by the following conditions: 10-55Hz 1.5mm Amplitude,
55-2000 Hz 20 G's, 2 hours for each plane
Thermal Shock
After applied Thermal Shock of 260°C
max x 10 sec max x 2 times, or 230°C max x 180 sec max,
the specimen shall meet electrical characteristics
Solderability
(EIAJ-RCX-0102.101 Condition 1a)
1) Flux: MIL-F-14256 (WW Rosin=25%, Isopropyl Alcohol = 75%)
2) Solder: QQ-S-571 (Sn = 63%, Pb = 37%)
3) Solder bath temperature: 235°C ±5°C
4) Depth of immersion: Up to electrical terminal
5) Immersing time: Within 2 sec ±0.5 sec into solder bath
After performing the above procedures, a newly soldered coverage shall be greater than 90%
Free Drop
Output Waveform
TF
TR
"1" LEVEL
80%
50%
Pin Connections
1: Tri-State E/D
2: Ground
3: Output
4: VDD
20%
"0" LEVEL
SYMMETRY
Dimensional Tolerance: ±.02” (.508mm)
±.005” (.127mm)
Ordering Information
Tape and Reel Dimensions
HSM633 -
CLOCK
SERIES
125.0M
CENTER
FREQUENCY
Bulletin
Revision
Dimensional Tolerance: ±.02” (.508mm)
±.005” (.127mm)
Sm044
13
27 March 2012
Date
Specifications subject to change without notice. All dimensions in inches. © Copyright 2012 The Connor-Winfield Corporation
