MULTIPOLE
CONNECTORS
XB SERIES
Patent
P
Technoending
logy
XB is a new size to complete the B Series
connector range
LEMO B Series connectors are now available
with a new connector size.
The XB Series can accommodate 12 or 22
electrical contacts. This connector is an
intermediate connector size between the well
known 1B and 2B Series. The market need
for a compact connector resulted in this new
high contact density product.
Features
endurance: over 5000 mating cycles
temperature range: -55°C to + 250°C
protection index: IP 50 (when mated)
360° screening for full EMC shielding
high packing density for space savings
Models
FGG
Straight plug, key (G) or keys (A and E),
cable collet
44
33.5
Part Number
ø 13
Number
of contacts
12
22
FGG.XB.312.CLAD••
FGG.XB.322.CLAD••
S 10
S 11
Note:
Replace by •• collet size reference (see table).
FGG
Straight plug, key (G) or keys (A and E),
cable collet and nut for fitting a bend relief
47.5
37
Part Number
ø 13
Number
of contacts
12
22
FGG.XB.312.CLAD••Z
FGG.XB.322.CLAD••Z
S 10
S 11
Note:
Replace by •• collet size reference (see table).
The bend relief must be ordered separately.
23.5
20
S 17
1.5
EGG
Fixed socket, key (G) or keys (A and E),
nut fixing
Part Number
Number
of contacts
12
22
M 14 x 1
ø 19
ø 16
EGG.XB.312.CLL
EGG.XB.322.CLL
7 maxi
S 12.5
23.5
20
S
17
3.5
ECG
Fixed socket with two nuts, key (G)
or keys (A and E)
(back panel mounting)
Part Number
Number
of contacts
12
22
M 14 x 1
ø
19
ø
18
ECG.XB.312.CLL
ECG.XB.322.CLL
6 maxi
S
12.5
23
20
S
17
3.5
ECG
Fixed socket with two nuts, key (G)
or keys (A and E) and straight contact
for printed circuit
(back panel mounting)
Part Number
ø
18
M 14 x 1
Number
of contacts
12
22
ø
19
ECG.XB.312.CLN
ECG.XB.322.CLN
6 maxi
S
12.5
PHG
Free socket, key (G) or keys (A and E),
cable collet
46
Part Number
ø
13
Number
of contacts
12
22
S
10
S
11
PHG.XB.312.CLLD••
PHG.XB.322.CLLD••
Note:
Replace by •• collet size reference (see table).
Note:
All dimensions are in millimetres.
PHG
Free socket, key (G) or keys (A and E),
cable collet and nut for fitting a bend relief
49.5
ø
13
Part Number
PHG.XB.312.CLLD••Z
PHG.XB.322.CLLD••Z
Number
of contacts
12
22
S
10
S
11
Note:
Replace by •• collet size reference (see table).
The bend relief must be ordered separately.
Insert configuration and electrical characteristics
Male solder contacts
ø
A
Female solder contacts
Contact
type
Solder
contact
Test voltage (kV rms)
Contact-contact
Test voltage (kV rms)
Contact-shell
1.65
0.90
0.34
0.09
Number of contacts
Reference
1
2
4
3
4
3
1
2
312
12
0.7
●
●
1.35
5.00
322
22
0.5
●
●
0.50
1.50
D type collets for XB series
ø
B
ø
A
Reference
Type
D
D
D
D
••
52
62
72
82
øA
5.2
6.2
7.2
8.2
Collet ø
øB
7.2
7.2
7.2
7.2
max.
5.0
6.0
7.0
8.0
Cable ø
min.
4.4
5.4
6.4
7.4
Nut for fitting
a bend relief
Bend relief
GMA.1B.045.DG
GMA.1B.054.DG
GMA.1B.065.DG
–
FFM.1B.131.LC
–
Contacts
(solder type)
ø
A
ø
C
Conductor
Contact
Solid
Reference
Stranded
AWG
max.
22
1)
28
Section (mm
2
)
max.
øA
(mm)
312
322
0.7
0.5
øC
(mm)
0.80
0.45
AWG
max.
22
28
Section (mm
2
)
max.
0.34
0.09
ø
A
ø
C
Note:
1)
for a given AWG, the diameter of some stranded conductor designs is larger than the solder cup diameter.
Make sure that the maximum conductor diameter is smaller than ø C.
Alignment Key and Polarized Keying System
XB series connector model part numbers are composed of three letters. The LAST LETTER indicates the
key position.
α
Contact type
Reference
β
Nb of Angles Series
keys
XB
Plug
Socket
female
female
female
Note
G
A
E
●
First choice alternative
●
Special order alternative
1
2
2
α
β
0°
30°
120°
male
male
male
●
●
●
Rated current (A)
Print (straight)
ø A (mm)
Solder
Accessories
GMA
Bend relief for FGG and PHG models
with nut for fitting a bend relief
Part Number
L
Dimensions (mm)
Bend relief
Cable ø
A
L
max. min.
4.0
4.5
5.4
6.5
Ref.
J
M
N
30
30
30
30
Colour
yellow
brown
black
4.4
4.9
6.0
7.0
4.0
4.5
5.4
6.5
Ref.
R
S
V
Colour
red
orange
green
GMA.1B.040.DG
GMA.1B.045.DG
GMA.1B.054.DG
GMA.1B.065.DG
Ref.
A
B
G
Colour
blue
white
grey
Note:
Material: Polyurethane elastomer
Temperature range in dry atmosphere: -40°C +80°C
øA
Note:
The last letter «G» of the part number indicates the colour grey of the
bend relief. For others colour, refer to the above table and replace letter «G» by
the letter of the colour required.
Panel cut-out
EGG-ECG
21.5 mini
PCB drilling pattern
312
45
°
322
25’
51
°
+ 0.1
0
22°30’
25
°
4
2
12°51’
ø
14.1
ø
5.4
’
ø
2.4
ø
0.8
ø
0.6
Cable stripping lengths
ø contact
(mm)
L
T
Mounting nut torque
Cable stripping
lengths (mm)
Solder
L
16.5
17.5
S
7.5
8.0
T
3.5
4.0
5.0
Torque (Nm)
Connector
Type
312
322
S
0.7
0.5
Note:
all dimensions are in millimetres.
Refer to B series catalog for general characteristics
LEMO
HEADQUARTERS
SWITZERLAND
LEMO SA
Chemin des Champs-Courbes 28 - P.O. Box 194 - CH-1024 Ecublens
Tel. (+41 21) 695 16 00 - Fax (+41 21) 695 16 02 - e-mail: info@lemo.com
www.lemo.com
CAT.XB.LEN.P0307
CHF 1.50 / EURO 1 / USD 1.1 / RMB 10
Data subject to change, printed in Switzerland, March 2007
Updated May 2008
