ISL6566CRR5184 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Power/power management> The power supply circuit> ISL6566CRR5184

ISL6566CRR5184: DescriptionSWITCHING CONTROLLER, 1500kHz SWITCHING FREQ-MAX, PQCC40, 6 X 6 MM, PLASTIC, MO-220VJJD-2, QFN-40; CategoryPower/power management The power supply circuit; File Size1MB，30 Pages; ManufacturerRenesas Electronics Corporation; Websitehttps://www.renesas.com/

Download Datasheet Parametric View All

ISL6566CRR5184 Overview

SWITCHING CONTROLLER, 1500kHz SWITCHING FREQ-MAX, PQCC40, 6 X 6 MM, PLASTIC, MO-220VJJD-2, QFN-40

ISL6566CRR5184 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	Renesas Electronics Corporation
Parts packaging code	QFN
package instruction	6 X 6 MM, PLASTIC, MO-220VJJD-2, QFN-40
Contacts	40
Reach Compliance Code	not_compliant
ECCN code	EAR99
Analog Integrated Circuits - Other Types	SWITCHING CONTROLLER
control mode	VOLTAGE-MODE
Control Technology	PULSE WIDTH MODULATION
Maximum input voltage	5.25 V
Minimum input voltage	4.75 V
Nominal input voltage	5 V
JESD-30 code	S-PQCC-N40
JESD-609 code	e0
length	6 mm
Humidity sensitivity level	2
Number of functions	1
Number of terminals	40
Maximum operating temperature	70 °C
Minimum operating temperature
Maximum output current	0.001 A
Package body material	PLASTIC/EPOXY
encapsulated code	HVQCCN
Encapsulate equivalent code	LCC40,.24SQ,20
Package shape	SQUARE
Package form	CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE
Peak Reflow Temperature (Celsius)	240
Certification status	Not Qualified
Maximum seat height	1 mm
surface mount	YES
Switch configuration	PHASE-SHIFT
Maximum switching frequency	1500 kHz
Temperature level	COMMERCIAL
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	NO LEAD
Terminal pitch	0.5 mm
Terminal location	QUAD
Maximum time at peak reflow temperature	NOT SPECIFIED
width	6 mm

Preview

Download Datasheet

View All

DATASHEET

ISL6566

Three-Phase Buck PWM Controller with Integrated MOSFET Drivers for VRM9,

VRM10, and AMD Hammer Applications

The ISL6566 three-phase PWM control IC provides a

precision voltage regulation system for advanced

microprocessors. The integration of power MOSFET drivers

into the controller IC marks a departure from the separate

PWM controller and driver configuration of previous multi-

phase product families. By reducing the number of external

parts, this integration is optimized for a cost and space

saving power management solution.

Outstanding features of this controller IC include

programmable VID codes compatible with Intel VRM9,

VRM10, as well as AMD Hammer microprocessors. A unity

gain, differential amplifier is provided for remote voltage

sensing, compensating for any potential difference between

remote and local grounds. The output voltage can also be

positively or negatively offset through the use of a single

external resistor.

A unique feature of the ISL6566 is the combined use of both

DCR and r

DS(ON)

current sensing. Load line voltage

positioning (droop) and overcurrent protection are

accomplished through continuous inductor DCR current

sensing, while r

DS(ON)

current sensing is used for accurate

channel-current balance. Using both methods of current

sampling utilizes the best advantages of each technique.

Protection features of this controller IC include a set of

sophisticated overvoltage, undervoltage, and overcurrent

protection. Overvoltage results in the converter turning the

lower MOSFETs ON to clamp the rising output voltage and

protect the microprocessor. The overcurrent protection level

is set through a single external resistor. Furthermore, the

ISL6566 includes protection against an open circuit on the

remote sensing inputs. Combined, these features provide

advanced protection for the microprocessor and power

system.

FN9178

Rev 4.00

Mar 9, 2006

Features

• Integrated Multi-Phase Power Conversion

- 1, 2, or 3-Phase Operation

• Precision Core Voltage Regulation

- Differential Remote Voltage Sensing

0.5%

System Accuracy Over Temperature

- Adjustable Reference-Voltage Offset

• Precision Channel Current Sharing

- Uses Loss-Less r

DS(ON)

Current Sampling

• Accurate Load Line Programming

- Uses Loss-Less Inductor DCR Current Sampling

• Variable Gate Drive Bias: 5V to 12V

• Microprocessor Voltage Identification Inputs

- Up to a 6-Bit DAC

- Selectable between Intel’s VRM9, VRM10, or AMD

Hammer DAC Codes

- Dynamic VID Technology

• Overcurrent Protection

• Multi-tiered Overvoltage Protection

• Digital Soft-Start

• Selectable Operation Frequency up to 1.5MHz Per Phase

• Pb-Free Plus Anneal Available (RoHS Compliant)

Pinout

ISL6566 (QFN)

TOP VIEW

UGATE1

30 BOOT1

29 PHASE1

28 PHASE2

27 UGATE2

GND

26 BOOT2

25 ISEN2

24 PVCC2

23 LGATE2

22 PHASE3

21 BOOT3

RGND

VSEN

OCSET

ICOMP

ISUM

IREF

LGATE3

PVCC3

ISEN3

UGATE3

LGATE1

PGOOD

PVCC1

ISEN1

ENLL

VID2

VID3

VID4

VID1

VID0

VID12.5

VRM10

REF

OFS

VCC

COMP

VDIFF 10

FN9178 Rev 4.00

Mar 9, 2006

Page 1 of 30
