DATA SHEET
E.S.D NOISE CLIPPING DIODES
NNCD5.6MG to NNCD6.8MG
LOW CAPACITANCE HIGH ESD TYPE
ELECTROSTATIC DISCHARGE NOISE CLIPPING DIODES
(QUARTO TYPE: COMMON ANODE)
5-PIN MINI MOLD
This product series is a low capacitance type diode developed for
E.S.D.
(Electrostatic
Discharge)
protection.
Based
on
the
IEC61000-4-2 test on electromagnetic interference (EMI), the diode
assures an endurance of no less than 30 kV, and capacitance is
small with 20 pF TYP. This product series is the most suitable for
the ESD protection in the high-speed data communication bus such
With four elements mounted in the 5-PIN Mini Mold Package, that
product can cope with high density assembling.
2.9
±
0.2
0.95
PACKAGE DIMENSIONS
(in millimeters)
2.8
±
0.2
0.32
−0.06
+0.1
1.5
0.65
−0.15
+0.1
as USB.
1.9
1
5
FEATURES
• Based on the electrostatic discharge immunity test (IEC61000-4-
2), the product assures the minimum endurance of 30 kV.
• Capacitance is small with 20 pF TYP. (at V
R
= 0 V, f = 1 MHz). It
is excellent in the frequency characteristic.
• With 4 elements mounted (common anode) in the SC-74A
package, that product can cope with high density assembling.
1.1 to 1.4
0.8
0.95
2
3
4
APPLICATIONS
• External interface circuit E.S.D. protection in the high-speed data
communication bus such as USB.
(SC-74A)
PIN CONNECTION
5
4
MAXIMUM RATINGS (T
A
= 25°C)
°
Power Dissipation
Surge Reverse Power
Junction Temperature
Storage Temperature
P
P
RSM
T
j
T
stg
200 mW (Total)
2 W (t = 10
µ
s 1 pulse) Fig.5
150°C
−55°C
to +150°C
1:
2:
3:
4:
5:
1
2
3
K1
A
K2
K3
K4
0 to 0.1
Cathode 1
Anode (common)
Cathode 2
Cathode 3
Cathode 4
The information in this document is subject to change without notice. Before using this document, please
confirm that this is the latest version.
Not all devices/types available in every country. Please check with local NEC representative for
availability and additional information.
Document No. D13910EJ2V0DS00 (2nd edition)
Date Published February 2000 N CP(K)
Printed in Japan
©
0.16
−0.06
+0.1
1999
