85013-3225: Description2.54mm (.100) Pitch DIN 41612 Header, Through Hole, Vertical, Style R Reverse, 1楼矛m (40楼矛) Selective Gold (Au), 64 Circuits, Lead free; CategoryThe connector The connector; File Size123KB，5 Pages; ManufacturerMolex; Websitehttps://www.molex.com/molex/home; Environmental Compliance

Download Datasheet Parametric View All

85013-3225 Overview

2.54mm (.100) Pitch DIN 41612 Header, Through Hole, Vertical, Style R Reverse, 1楼矛m (40楼矛) Selective Gold (Au), 64 Circuits, Lead free

85013-3225 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Molex
Reach Compliance Code	unknow
Other features	STANDARD: DIN 41612
Connector type	BOARD EURO CONNECTOR
Contact to complete cooperation	NOT SPECIFIED
Contact point gender	MALE
Contact material	BRASS
DIN compliance	YES
Filter function	NO
IEC compliance	NO
MIL compliance	NO
Manufacturer's serial number	85013
Plug information	MULTIPLE MATING PARTS AVAILABLE
Mixed contacts	NO
Installation method	STRAIGHT
Installation type	BOARD
Number of rows loaded	2
Options	GENERAL PURPOSE
Terminal pitch	2.54 mm
Termination type	SOLDER
Total number of contacts	64
UL Flammability Code	94V-0

Preview

Download Datasheet

View All

This document was generated on 05/17/2010

PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMA

Part Number:

Status:

Overview:

Description:

0850133225

Active

din_41612

2.54mm (.100") Pitch DIN 41612 Header, Through Hole, Vertical, Style R Reverse, 1µm

(40µ") Selective Gold (Au), 64 Circuits, Lead free
