NAZT472M10V16X17HLSBF

Description
CAPACITOR, ALUMINUM ELECTROLYTIC, NON SOLID, POLARIZED, 10V, 4700uF, SURFACE MOUNT, 6464, CHIP, ROHS COMPLIANT
CategoryPassive components    capacitor
File Size62KB，4 Pages
ManufacturerNichicon
Websitehttp://www.nichicon.co.jp
Environmental Compliance
Related ProductsFound8parts with similar functions to NAZT472M10V16X17HLSBF
Download Datasheet Parametric Compare View All

NAZT472M10V16X17HLSBF Overview

CAPACITOR, ALUMINUM ELECTROLYTIC, NON SOLID, POLARIZED, 10V, 4700uF, SURFACE MOUNT, 6464, CHIP, ROHS COMPLIANT

NAZT472M10V16X17HLSBF Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
Is it Rohs certified?conform to
package instruction, 6464
Reach Compliance Codecompli
capacitance4700 µF
Capacitor typeALUMINUM ELECTROLYTIC CAPACITOR
JESD-609 codee3
leakage current0.47 mA
Manufacturer's serial numberNAZT
Installation featuresSURFACE MOUNT
negative tolerance20%
Maximum operating temperature105 °C
Minimum operating temperature-55 °C
Package shapeCYLINDRICAL PACKAGE
method of packingTR, 15 INCH
polarityPOLARIZED
positive tolerance20%
Rated (DC) voltage (URdc)10 V
ripple current1800 mA
size code6464
surface mountYES
Delta tangent0.3
Terminal surfaceMATTE TIN
Terminal shapeFLAT
Base Number Matches1

Preview

Download Datasheet
Surface Mount Aluminum Electrolytic Capacitors
FEATURES
•
•
•
•
•
•
CYLINDRICAL V-CHIP CONSTRUCTION FOR SURFACE MOUNTING
AVAILABLE WITH ANTI-VIBRATION WIDE TERMINATIONS
VERY LOW IMPEDANCE & HIGH RIPPLE CURRENT AT 100KHz
EXTENDED LOAD LIFE (2,000 ~ 5,000 HOURS @ +105°C)
SUITABLE FOR DC-DC CONVERTER, DC-AC INVERTER, ETC.
DESIGNED FOR AUTOMATIC MOUNTING AND REFLOW SOLDERING
Rated Voltage Rating
Rated Capacitance Range
Operating Temp. Range
Capacitance Tolerance
Max. Leakage Current
After 2 Miuntes @ 20°C
Tan
δ
@ 120Hz/20°C
Low Temperature
Stability
Impedance Ratio @ 120Hz
Load Life Test @ 105°C
4 ~ 6mm Dia. 2,000 hours
8 ~ 16mm Dia. 5,000 hours
6.3 ~ 100Vdc
4.7 ~ 6,800μF
-55 ~ +105°C
±20% (M)
0.01CV or 3μA
whichever is greater
W.V. (Vdc)
S.V. (Vdc)
4 ~ 8mm diameter
8 ~ 16mm diameter
W.V. (Vdc)
Z-25°C/Z+20°C
Z-55°C/Z+20°C
Capacitance Change
Tan
δ
Leakage Current
SAC
Alloy Compatible
230°C ~ 260°C
NAZT Series
NEW
Expanded Values
63V ~ 100V
CHARACTERISTICS
RoHS
Compliant
includes all homogeneous materials
*See Part Number System for Details
6.3
8.0
0.26
0.28
6.3
3
4
10
13
0.20
0.24
10
2
4
LOW ESR COMPONENT
LIQUID ELECTROLYTE
For Performance Data
see www.LowESR.com
100
125
-
0.07
100
2
3
16
25
35
50
63
20
32
44
63
79
0.16
0.14
0.12
0.12
-
0.22
0.16
0.14
0.14
0.08
16
25
35
50
63
2
2
2
2
2
4
3
3
3
3
Within ±30% of initial measured value
Less than ±300% of the specified maximum value
Less than the specified maximum value
STANDARD VALUES AND CASE SIZES (mm)
Cap.
(μF)
4.7
10
15
22
27
33
47
56
68
100
150
220
330
470
680
1000
1500
2200
3300
4700
6800
Code
4R7
100
150
220
270
330
470
560
680
101
151
221
331
471
681
102
152
222
332
472
682
6.3
-
-
-
-
4x6.3
5x6.3
5x6.3
5x6.3
6.3x6.3
6.3x6.3
6.3x6.3
6.3x6.3
6.3x8
8x10.5
8x10.5
8x10.5
10x10.5
10x10.5
12.5x14
-
-
16x17
10
-
-
-
4x6.3
5x6.3
5x6.3
6.3x6.3
6.3x6.3
6.3x6.3
6.3x6.3
6.3x6.3
6.3x8
8x10.5
8x10.5
10x10.5
10x10.5
12.5x14
12.5x14
-
16x17
-
16
-
-
4x6.3
5x6.3
5x6.3
6.3x6.3
6.3x6.3
6.3x6.3
6.3x6.3
6.3x6.3
6.3x8
6.3x8
8x10.5
8x10.5
10x10.5
12.5x14
-
-
16x17
-
-
Working Voltage (Vdc)
25
35
-
4x6.3
4x6.3
5x6.3
5x6.3
5x6.3
5x6.3
5x6.3
6.3x6.3
6.3x6.3
6.3x6.3
6.3x6.3
6.3x6.3
6.3x6.3
6.3x6.3
6.3x8
6.3x6.3
6.3x8
6.3x8
8x10.5
8x10.5
8x10.5
8x10.5
8x10.5
8x10.5
10x10.5
10x10.5 12.5x14
12.5x14 12.5x14
-
16x17
16x17
-
-
-
16x17
16x17
-
-
-
-
50
4x6.3
6.3x6.3
6.3x6.3
6.3x6.3
6.3x8
6.3x8
6.3x8
8x10.5
8x10.5
8x10.5
10x10.5
10x10.5
12.5x14
16x17
16x17
16x17
-
-
-
-
-
63
-
-
-
-
-
-
-
-
-
-
12.5x14
12.5x14
-
16x17
-
-
-
-
-
-
-
100
-
-
-
-
-
10x10.5
12.5x14
-
12.5x14
16x17
16x17
-
-
-
-
-
-
-
-
-
-
New Expanded Values
DIMENSIONS (mm) AND REEL QUANTITIES
Case Size
φD±0.5
L max. A±0.2 B±0.2 I±0.3
W
P±0.3 Qty/Reel
4x6.3
4.0
6.3
4.3
4.3
1.8 0.5~0.8 1.0
1,200
5x6.3
5.0
6.3
5.3
5.3
2.2 0.5~0.8 1.4
800
6.3x6.3
6.3
6.3
6.6
6.6
2.5 0.5~0.8 2.2
800
6.3X8
6.3
8.0
6.6
6.6
2.5 0.5~0.8 2.2
500
8x10.5
8.0
10.5
8.3
8.3
2.9 0.7~1.0 3.2
300
10x10.5
10.0
10.5
10.3 10.3 3.2 1.1~1.4 4.6
300
12.5x14
12.5
14.0
12.8 12.8 4.5 1.1~1.4 4.6
200
16x17
16.0
17.0
16.3 16.3 5.5 1.8~2.1 7.0
125
Dφ
W
0.3mm max.
+
I
I
-
L
P
B
A
66
NIC COMPONENTS CORP.
www.niccomp.com
www.lowESR.com
www.RFpassives.com
www.SMTmagnetics.com

NAZT472M10V16X17HLSBF Related Products

NAZT472M10V16X17HLSBF NAZT102M50V16X17HLSBF NAZT222M25V16X17HLSBF NAZT332M16V16X17HLSBF NAZT471M50V16X17HLSBF
Description CAPACITOR, ALUMINUM ELECTROLYTIC, NON SOLID, POLARIZED, 10V, 4700uF, SURFACE MOUNT, 6464, CHIP, ROHS COMPLIANT CAPACITOR, ALUMINUM ELECTROLYTIC, NON SOLID, POLARIZED, 50V, 1000uF, SURFACE MOUNT, 6464, CHIP, ROHS COMPLIANT CAPACITOR, ALUMINUM ELECTROLYTIC, NON SOLID, POLARIZED, 25V, 2200uF, SURFACE MOUNT, 6464, CHIP, ROHS COMPLIANT CAPACITOR, ALUMINUM ELECTROLYTIC, NON SOLID, POLARIZED, 16V, 3300uF, SURFACE MOUNT, 6464, CHIP, ROHS COMPLIANT CAPACITOR, ALUMINUM ELECTROLYTIC, NON SOLID, POLARIZED, 50V, 470uF, SURFACE MOUNT, 6464, CHIP, ROHS COMPLIANT
Is it lead-free? Lead free Lead free Lead free Lead free Lead free
Is it Rohs certified? conform to conform to conform to conform to conform to
package instruction , 6464 , 6464 , 6464 , 6464 , 6464
Reach Compliance Code compli compli compli compli compli
capacitance 4700 µF 1000 µF 2200 µF 3300 µF 470 µF
Capacitor type ALUMINUM ELECTROLYTIC CAPACITOR ALUMINUM ELECTROLYTIC CAPACITOR ALUMINUM ELECTROLYTIC CAPACITOR ALUMINUM ELECTROLYTIC CAPACITOR ALUMINUM ELECTROLYTIC CAPACITOR
JESD-609 code e3 e3 e3 e3 e3
leakage current 0.47 mA 0.5 mA 0.55 mA 0.528 mA 0.235 mA
Manufacturer's serial number NAZT NAZT NAZT NAZT NAZT
Installation features SURFACE MOUNT SURFACE MOUNT SURFACE MOUNT SURFACE MOUNT SURFACE MOUNT
negative tolerance 20% 20% 20% 20% 20%
Maximum operating temperature 105 °C 105 °C 105 °C 105 °C 105 °C
Minimum operating temperature -55 °C -55 °C -55 °C -55 °C -55 °C
Package shape CYLINDRICAL PACKAGE CYLINDRICAL PACKAGE CYLINDRICAL PACKAGE CYLINDRICAL PACKAGE CYLINDRICAL PACKAGE
method of packing TR, 15 INCH TR, 15 INCH TR, 15 INCH TR, 15 INCH TR, 15 INCH
polarity POLARIZED POLARIZED POLARIZED POLARIZED POLARIZED
positive tolerance 20% 20% 20% 20% 20%
Rated (DC) voltage (URdc) 10 V 50 V 25 V 16 V 50 V
ripple current 1800 mA 1610 mA 1800 mA 1800 mA 1610 mA
size code 6464 6464 6464 6464 6464
surface mount YES YES YES YES YES
Delta tangent 0.3 0.14 0.18 0.26 0.14
Terminal surface MATTE TIN MATTE TIN MATTE TIN MATTE TIN MATTE TIN
Terminal shape FLAT FLAT FLAT FLAT FLAT
Maker - Nichicon Nichicon Nichicon Nichicon
