FX
CONNECTOR
0.3mm pitch/Connectors for FPC
Emboss Tape
NON-
Specifications –––––––––––––––––––
• Current rating: 0.2A AC, DC
• Voltage rating: 50V AC, DC
• Temperature range: -25˚C to +85˚C
(including temperature rise in applying
electrical current)
• Contact resistance: Initial value/50m
Ω
max.
After environmental testing/50m
Ω
max.
(variation from initial value)
• Insulation resistance:
50M
Ω
min.
• Withstanding voltage: 200V AC/minute
• Applicable FPC: Conductor pitch/0.3mm
<0.6mm pitch staggered>
Conductor width/0.3mm
Mating part thickness/0.2±0.03mm
Note
:
FPC to be actually used should be checked for applicability.
Non-ZIF type connector for FPC's, with
only 2.25mm height when mounted on the
PC board. Temporary retention mechanism
and flip-lock device provide good
operational efficiency.
• Good for high density mounting
• Heat resisting design suitable for surface
mounting
• Easy mounting operation
• Embossed taping for automatic mounting
* Compliant with RoHS.
* Refer to "General Instruction and Notice when using
Terminals and Connectors" at the end of this catalog.
* Contact JST for details.
Standards ––––––––––––––––––––––
1
Certified LR20812
0
Recognized E60389
PC board layout (viewed from component side) and Assembly layout
0.3
±0.05
1.25
±0.1
0.6
±0.05
4.6
0.5
±0.05
0.5
±0.1
1.45
Contact point
0.675
±0.05
Note: 1. Tolerances are non-cumulative:
±
0.05mm for all centers.
2. The dimensions above should serve as a guideline. Contact JST for details.
178
2.25
Line a
Line b
5.4
±0.1
FX CONNECTOR
Connector
Reverse type
A
0.6
1.7
Circuits
15
21
23
25
27
33
39
45
51
57
Model No.
15FX-RSM1-S-TB
21FX-RSM1-S-TB
23FX-RSM1-S-TB
25FX-RSM1-S-TB
27FX-RSM1-S-TB
33FX-RSM1-S-TB
39FX-RSM1-S-TB
45FX-RSM1-S-TB(12)
51FX-RSM1-S-TB
57FX-RSM1-S-TB
A
3.6
5.4
6.0
6.6
7.2
9.0
10.8
12.6
14.4
16.2
Dimensions (mm)
B
4.2
6.0
6.6
7.2
7.8
9.6
11.4
13.2
15.0
16.8
C
7.0
8.8
9.4
10.0
10.6
12.4
14.2
16.0
17.8
19.6
Q'ty /
reel
3,000
3,000
3,000
3,000
3,000
3,000
3,000
2,500
3,000
3,000
0.6
Material and Finish
C
B
4.6
0.5
Contact: Copper alloy, copper-undercoated, tin-plated (reflow treatment)
Housing: LCP, UL94V-0
Solder tab: Copper alloy, copper-undercoated, tin-plated (reflow treatment)
Cover: Heat-resisting polyamide, UL94V-0
2.25
0.3
RoHS compliance
This product displays (LF)(SN) on a label.
Note: Contact JST for gold-plated products.
Lead section dimensions of FPC
±
0.3×
N+1
）
0.05
（
±
0.3×
N- 1
）
0.03
（
±0.07
0.3
0.6
±0.02
0.3
＋0.04
−0.03
0.3
±0.07
0.2
±0.03
3.3
±0.3
Reinforcing layer
Note: N---Number of circuits
4.5
179
