48201-6061: Description9 CONTACT(S), FEMALE, D SUBMINIATURE CONNECTOR, SOLDER; CategoryThe connector The connector; File Size140KB，3 Pages; ManufacturerMolex; Websitehttps://www.molex.com/molex/home; Environmental Compliance

Download Datasheet Parametric View All

48201-6061 Overview

9 CONTACT(S), FEMALE, D SUBMINIATURE CONNECTOR, SOLDER

48201-6061 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Molex
package instruction	ROHS COMPLIANT
Reach Compliance Code	unknown
Connector type	D SUBMINIATURE CONNECTOR
Contact to complete cooperation	GOLD (2)
Contact completed and terminated	TIN (100)
Contact point gender	FEMALE
Contact material	PHOSPHOR BRONZE
DIN compliance	NO
empty shell	NO
Filter function	NO
IEC compliance	NO
insulator material	GLASS FILLED POLYESTER
JESD-609 code	e3
MIL compliance	NO
Manufacturer's serial number	48201
Plug information	NO
Mixed contacts	NO
Installation type	BOARD
Options	GENERAL PURPOSE
Shell surface	TIN
Shell material	SPCC
Housing size	1/E
Termination type	SOLDER
Total number of contacts	9
UL Flammability Code	94V-0
Base Number Matches	1

Preview

Download Datasheet

View All

This document was generated on 04/02/2010

PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMA

Part Number:

Status:

Description:

0482016061

Active

D-Subminiature Shielded I/O PCB Female Receptacle, Right Angle, Through Hole, 9

Circuits, 2 pcs #4-40 Round Inner Thread Screw Rivetted, BeveledMetal Pins, Gold

(Au) Flash, PCB Thickness 1.60mm (.063"), Lead Free

Documents:

3D Model

Drawing (PDF)

Product Specification PS-48201-001 (PDF)

RoHS Certificate of Compliance (PDF)

General

Product Family

Series

Application

Component Type

Product Name

Type

I/O Connectors

48201

Wire-to-Board

Receptacle

D-Sub

N/A

Physical

Boot Color

Circuits (Loaded)

Circuits (maximum)

Color - Resin

Durability (mating cycles max)

Gender

Lock to Mating Part

Material - Metal

Material - Plating Mating

Material - Plating Termination

Material - Resin

Number of Rows

Orientation

PC Tail Length (in)

PC Tail Length (mm)

PCB Locator

PCB Retention

PCB Thickness Recommended (in)

PCB Thickness Recommended (mm)

Packaging Type

Panel Mount

Pitch - Mating Interface (in)

Pitch - Mating Interface (mm)

Pitch - Term. Interface (in)

Pitch - Term. Interface (mm)

Plating min: Mating (µin)

Plating min: Mating (µm)

Plating min: Termination (µin)

Plating min: Termination (µm)

Polarized to Mating Part

Polarized to PCB

Ports

Surface Mount Compatible (SMC)

Temperature Range - Operating

Termination Interface: Style

Waterproof / Dustproof

Wire Size AWG

N/A

9

Black

600

Female

Yes

Phosphor Bronze

Gold

Tin

Polyester

2

Right Angle

0.125 In

3.18 mm

No

Yes

0.063 In

1.60 mm

Tray

Yes

0.054 In

1.38 mm

0.054 In

1.38 mm

2

0.05

100

2.54

Yes

1

No

-55°C to +85°C

Through Hole

No

N/A

EU RoHS

ELV and

Complia

REACH S

Not Revi

Halogen

Status

Not Revi

Need mo

environm

Email pro

For a mu

Complian

Please vi

non-prod

Search

48201S

Mates

48202
