XT49ML
Vishay Dale
Low Profile SMD Type Crystal Units
FEATURES
• Low cost
• Industry standard
• Wide frequency range
• Excellent aging
• Surface mount
• Compliant to RoHS directive 2002/95/EC
This part is a miniature AT cut strip crystal unit packaged for
surface mounting.
STANDARD ELECTRICAL SPECIFICATIONS
PARAMETER
Frequency range
Frequency tolerance
Temperature stability
Operating temperature range
Storage temperature range
Shunt capacitance
Load capacitance
Insulation resistance
Drive level
Aging
SYMBOL
F
O
ΔF/F
O
T
C
T
OPR
T
STG
C
0
C
L
I
R
D
L
Fa
at 25 °C, per year
customer specified
100 V
DC
at 25 °C
ref. to 25 °C
CONDITION
UNIT
MHz
ppm
ppm
°C
°C
pF
pF
MΩ
μW
ppm
MIN.
3.200
± 10
± 10
- 20
- 40
-
10
500
-
-5
TYP.
-
± 30
± 30
-
-
-
-
-
100
-
MAX.
66.000
± 50
± 50
+ 70
+ 85
7
series
-
500
+5
EQUIVALENT SERIES RESISTANCE (ESR) AND MODE OF VIBRATION (MODE)
FREQUENCY RANGE (MHz)
3.200 to 4.499
4.500 to 5.999
6.000 to 6.999
7.000 to 7.999
8.000 to 8.999
MAX. ESR (Ω)
150
120
100
90
80
MODE
fundamental/AT
fundamental/AT
fundamental/AT
fundamental/AT
fundamental/AT
FREQUENCY RANGE (MHz)
9.000 to 9.999
10.000 to 12.999
13.000 to 29.999
30.000 to 66.000
MAX. ESR (Ω)
60
50
40
80
MODE
fundamental/AT
fundamental/AT
fundamental/AT
3
rd
overtone
DIMENSIONS
in inches [millimeters]
0.403 [10.24] max.
0.150 [3.8]
max.
Crystal Unit
0.008 [0.2]
0.138 [3.5]
max.
max.
0.150 [3.8] max.
0.508 ± 0.016
[12.9 ± 0.4]
0.449 ± 0.012
[11.4 ± 0.3]
0.031 ± 0.012
[0.8 ± 0.3]
0.201 ± 0.020
[5.1 ± 0.5]
Insulation Base
0.012 [0.3]
max.
0.354 [9.0]
Crystal Lead
0.185 ± 0.012
[4.7 ± 0.3]
0.236 [6.0]
Solder
Pattern
0.078
[2.0]
Document Number: 35047
Revision: 18-Oct-07
For technical questions, contact:
frequency@vishay.com
www.vishay.com
1
