ADVANCE DATA
Data Sheet No. PD60194
IR21592
(S)
IR21593
(S)
Features
DIMMING BALLAST CONTROL IC
•
Full lamp fault protection
•
Brown-out protection
•
Automatic restart
•
Micro-power startup
•
Zener clamped Vcc
•
Over-temperature protection
•
16-pin DIP and SOIC package types
Parameter
Deadtime
Frequency
Range
IR21592
1.8us
See
Graph 3
IR21593
1.0us
See
Graph 4
•
Ballast control and half-bridge driver in one IC
•
Transformer-less lamp power sensing
•
Closed-loop lamp power control
•
Closed-loop preheat current control
•
Programmable preheat time
•
Programmable preheat current
•
Lamp ignition detection
•
Programmable ignition-to-dim time
•
0.5 to 5VDC dimming control input
•
Min and max lamp power adjustments
•
Programmable minimum frequency
•
Internal current sense blanking
Description
Description: The IR21592/IR21593 are complete dimming ballast controllers and 600V
half-bridge drivers all in one IC. The architecture includes phase control for trans-
former-less lamp power sensing and regulation which minimizes changes needed to
adapt non-dimming ballasts for dimming. Externally programmable features such as
preheat time and current, ignition-to-dim time, and a complete dimming interface with
minimum and maximum settings provide a high degree of flexibility for the ballast
design engineer. Protection from failure of a lamp to strike, filament failures, thermal
overload, or lamp failure during normal operation, as well as an automatic restart
function, have been included in the design. The heart of this control IC is a voltage-
controlled oscillator with externally programmable minimum frequency. The IR21592/
IR21593 are available in both 16 pin DIP and 16 pin narrow body SOIC packages.
Packages
16 Lead SOIC
(narrow body)
16 Lead PDIP
Typical Connection
+ Rectified AC Line
+ DC Bus
R
VDC
C
VDC
C
VCO
C
PH
R
DIM
0.5 to 5VDC
R
MAX
R
MIN
R
FMIN
R
IPH
R
VAC
R
PULL-UP
1
16
Single Lamp Dimmable
VDC
HO
2
VCO
VS
15
3
CPH
VB
14
4
DIM
VCC
13
5
MAX
COM
12
6
MIN
LO
11
7
FMIN
CS
10
8
IPH
SD
9
R
CS
- DC Bus
www.irf.com
1
IR21592/IR21593
(S)
ADVANCE DATA
Absolute Maximum Ratings
Absolute maximum ratings indicate sustained limits beyond which damage to the device may occur. All voltage
parameters are absolute voltages referenced to COM, all currents are defined positive into any lead. The thermal
resistance and power dissipation ratings are measured under board mounted and still air conditions.
Symbol
V
B
V
S
V
HO
V
LO
I
OMAX
V
VCO
I
CPH
V
IPH
V
DIM
V
MAX
V
MIN
V
CS
I
SD
I
CC
dV/dt
P
D
Rth
JA
T
J
T
S
T
L
Note 1:
Definition
High side floating supply voltage
High side floating supply offset voltage
High side floating output voltage
Low side output voltage
Maximum allowable output current (either output)
due to external power transistor miller effect
Voltage controlled oscillator input voltage
CPH current
IPH voltage
Dimming control pin input voltage
Maximum lamp power setting pin input voltage
Minimum lamp power setting pin input voltage
Current sense input voltage
Shutdown pin current
Supply current (note 1)
Allowable offset voltage slew rate
Package power dissipation @ T
A
≤
+25°C
P
D =
(T
JMAX
-T
A
)/Rth
JA
Thermal resistance, junction to ambient
Junction temperature
Storage temperature
Lead temperature (soldering, 10 seconds)
(16 pin DIP)
(16 pin SOIC)
(16 pin DIP)
(16 pin SOIC)
Min.
-0.3
V
B
- 25
V
S
- 0.3
-0.3
-500
-0.3
-5
-0.3
-0.3
-0.3
-0.3
-0.3
-5
—
-50
—
—
—
—
-55
-55
—
Max.
625
V
B
+ 25
V
B
+ 0.3
V
CC
+ 0.3
500
6.0
5
5.5
5.5
5.5
5.5
5.5
5
25
50
1.60
1.25
75
115
150
150
300
Units
V
mA
V
mA
V
mA
V/ns
W
o
C/W
o
C
This IC contains a zener clamp structure between the chip V
CC
and COM which has a nominal breakdown
voltage of 15.6V (V
CLAMP
). Please note that this supply pin should not be driven by a DC, low impedance
power source greater than the diode clamp voltage (V
CLAMP
) as specified in the Electrical Characteristics
section.
2
www.irf.com
ADVANCE DATA
IR21592/IR21593
(S)
Recommended Operating Conditions
For proper operation the device should be used within the recommended conditions.
Symbol
V
BS
V
S
V
CC
I
CC
V
VCO
V
DIM
V
MAX
V
MIN
R
FMIN
I
SD
I
CS
T
J
Note 2:
Note 3:
Definition
High side floating supply voltage
Steady state high side floating supply offset voltage
Supply voltage
Supply current
VCO pin voltage
DIM pin voltage
MAX pin current (note 3)
MIN pin voltage
Minimum frequency setting resistance
Shutdown pin current
Current sensing pin current
Junction temperature
Min.
V
CC
- 0.7
-1
V
CCUV+
note 2
0
0
-750
1
10
-1
-1
-40
Max.
V
CLAMP
600
V
CLAMP (15.6)
10
5
5
0
3
100
1
1
125
Units
V
mA
V
µ
A
V
kΩ
mA
o
C
Enough current should be supplied into the VCC lead to keep the internal 15.6V zener clamp diode on this lead
regulating its voltage, V
CLAMP
.
The MAX lead is a voltage-controlled current source. For optimum dim interface current mirror performance,
this current should be kept between 0 and 750µA.
Electrical Characteristics
V
CC
= V
BS
= V
BIAS
= 14V +/- 0.25V, V
CS
= 0.5V, V
SD
= 0.0V, R
FMIN
= 40k, C
VCO
= 10 nF, V
DIM
= 0.0V, R
MAX
= 33k,
R
MIN
= 56k, V
CPH
= 0.0V, C
LO,HO
= 1000pF, T
A
= 25
o
C unless otherwise specified.
Symbol Definition
Min.
Typ.
Max.
Units
Test Conditions
Supply Characteristics
V
CCUV+
V
CCHYS
I
QCCUV
I
QCCFLT
I
QCCFMIN
I
QCCFMAX
I
QCCFMIN
I
QCCFMAX
V
CLAMP
V
CC
supply undervoltage positive going
threshold
V
CC
supply undervoltage lockout hysteresis
UVLO mode quiescent current
Fault-mode quiescent current
V
CC
supply current @ FMIN (IR21592)
V
CC
supply current @ FMAX (IR21592)
V
CC
supply current @ FMIN (IR21593)
V
CC
supply current @ FMAX (IR21593)
V
CC
zener shunt clamp voltage
12.0
1.5
—
—
—
—
—
—
14.5
12.5
1.6
200
240
5.6
6.6
5.4
6.8
15.6
13.0
V
1.7
—
—
—
—
—
—
16.5
V
CC
= 10V
SD=5V, CS=2V, or
Tj > T
SD
V
VCO
= 0V
V
VCO
= 5V
V
VCO
= 0V
V
VCO
= 5V
I
CC
= 10mA
µA
mA
V
www.irf.com
3
IR21592/IR21593
(S)
Electrical Characteristics (cont.)
ADVANCE DATA
V
CC
= V
BS
= V
BIAS
= 14V +/- 0.25V, V
CS
= 0.5V, V
SD
= 0.0V, R
FMIN
= 40k, C
VCO
= 10 nF, V
DIM
= 0.0V, R
MAX
= 33k,
R
MIN
= 56k, V
TPH
= 0.0V, C
LO,HO
= 1000pF, T
A
= 25
o
C unless otherwise specified.
Symbol Definition
Min. Typ.
Max.
Units Test Conditions
Floating Supply Characteristics
I
QBS0
I
QBS1
V
BSMIN
I
LK
Quiescent V
BS
supply current
Quiescent V
BS
supply current
Minimum required V
BS
voltage for proper
HO functionality
Offset supply leakage current
—
—
—
—
0
30
4
—
—
—
5
50
µA
V
µA
V
B
= V
S
= 600V
V
HO
= V
S
V
HO
= V
B
Oscillator I/O Characteristics
fvco
VCO frequency range (IR21592)
(See graph 3)
fvco
VCO frequency range (IR21593)
(See graph 4)
d
Gate drive outputs duty cycle
V
VCOFLT
Fault-mode VCO pin voltage (UVLO,
shutdown, over-current/temp.)
I
VCOPH
Preheat mode VCO pin discharge current
I
VCODIM
Dim mode VCO pin discharge current
I
VCOPK
t
DTLO
t
DTHO
t
DTLO
t
DTHO
Amplitude control VCO pin charging current
LO output deadtime (IR21592)
HO output deadtime (IR21592)
LO output deadtime (IR21593)
HO output deadtime (IR21593)
—
—
—
—
—
—
—
—
—
—
—
—
—
25
95
30
230
50
5
1.0
16.0
60.0
1.8
1.8
1.0
1.0
—
—
—
—
—
VVCO=0V, RFMIN=39KΩ
kHz
%
V
µA
VVCO=5V, RFMIN=10KΩ
VVCO=0V, RFMIN=68KΩ
VVCO=5V, RFMIN=10KΩ
V
VCO
= 0V
—
—
—
—
—
—
—
V
CPH
< 5V
µA
µs
V
CPH
< 5V, V
CS
>V
IPH
Gate Driver Output Characteristics
V
OL
V
OH
tr
tf
Low-level output voltage
High-level output voltage
Turn-on rise time
Turn-off fall time
—
—
—
—
—
—
—
—
100
100
150
100
mV
ns
V
BIAS
- Vo
4
www.irf.com
ADVANCE DATA
IR21592/IR21593
(S)
Electrical Characteristics (cont.)
V
CC
= V
BS
= V
BIAS
= 14V +/- 0.25V, V
CS
= 0.5V, V
SD
= 0.0V, R
FMIN
= 40k, C
VCO
= 10 nF, V
DIM
= 0.0V, R
MAX
= 33k,
R
MIN
= 56k, V
TPH
= 0.0V, C
LO,HO
= 1000pF, T
A
= 25
o
C unless otherwise specified.
Symbol Definition
Min.
Typ.
Max.
Units Test Conditions
Preheat Characteristics
I
CPH
V
CPHIGN
V
CPHCLMP
I
IPH
V
CSTH
V
CPHFLT
CPH pin charging current
CPH pin ignition mode threshold voltage
CPH pin clamp voltage
IPH pin DC source current
Peak preheat current regulation threshold
CPH pin voltage during UVLO or fault
—
—
—
—
—
—
1.3
5.0
10
25.0
0.7
0.0
—
—
—
—
—
—
µA
V
µA
V
V
I
IPH
= 1/R
FMIN
V
CSTH
=(I
IPH
) x (R
IPH
)
SD = 5V, or CS = 2V,
or Tj > TSD
Ignition Detection
I
IPHIGN+
I
IPHIGN-
IPH source current (Vcs rising)
IPH source current (Vcs falling)
—
—
30
27.5
—
—
µA
VCPH>5.1V,V
CS<
V
IPH
VCPH>5.1V,V
CS>
V
IPH
Protection Characteristics
V
SDTH+
V
CSTH
V
VDCTH+
V
SDHYS
V
VDCHYS
V
SDCLMP
V
CSTH
T
SD
Rising shutdown pin threshold voltage
Peak over current threshold
Rising VDC pin threshold voltage
SD threshold hysteresis
VDC threshold hysteresis
SD pin clamp voltage
Peak over-current latch threshold voltage
Thermal shutdown junction temperature
—
—
—
—
—
—
—
—
2.0
1.6
5.1
150
2.1
7.6
1.6
165
—
—
—
—
—
—
—
—
V
mV
V
o
C
V
CPH
< 5V
ISD = 100mA
V
CPH
> 5.1V
Phase Control
V
CSTHZX
R
FB
t
Blank
Zero-crossing threshold voltage
Phase control FB resistor (Internal)
Zero-crossing internal blank time
—
—
—
0.0
5.7
400
—
—
—
V
kΩ
ns
Dimming Interface
V
DIMOFF
V
DIM
V
MINMIN
V
MINMAX
V
DIMTH
V
DIMTH
DIM pin offset voltage
DIM pin input voltage range
DIM minimum reference voltage (MIN pin)
DIM maximum reference voltage (MIN pin)
DIM mode VCO Threshold (IR21592)
DIM mode VCO Threshold (IR21593)
—
0.0
—
—
—
—
0.5
—
1.0
3.0
0.5
1.1
—
5.0
—
—
—
—
V
V
DIM
= 5V
V
DIM
= 0V
Minimum Frequency Setting
V
FMIN
V
FMINFLT
FMIN pin voltage during normal operation
FMIN pin voltage during fault mode
—
—
5.1
0.0
—
—
V
V
SD = 5V, or CS = 2V,
or Tj > TSD
www.irf.com
5
京公网安备 11010802033920号
EEWORLD
