10mm BI-POLAR AND BI-COLOR
INDICATOR LAMPS
Features
UNIFORM LIGHT OUTPUT.
LOW POWER CONSUMPTION.
3 LEADS WITH ONE COMMON CATHODE LEAD.
THIRD COLOR (MIXED COLOR) AVAILABLE.
SUPER BRIGHT VERSION AVAILABLE.
I.C. COMPATIBLE.
LONG LIFE - SOLID STATE RELIABILITY.
L819 SERIES
Package Dimensions
Description
The High Efficiency Red and Orange source color devices
are made with Gallium Arsenide Phosphide on Gallium
Phosphide Orange Light Emitting Diode.
The Green source color devices are made with Gallium
Phosphide Green Light Emitting Diode.
The Yellow source color devices are made with Gallium
Arsenide Phosphide on Gallium Phosphide Yellow Light
Emitting Diode.
The Super Bright Red source color devices are made with
Gallium Aluminum Arsenide Red Light Emitting Diode.
The Hyper Red (SURK) source color devices are made
with DH InGaAlP on GaAs substrate Light Emitting Diode.
Notes:
1. All dimensions are in millimeters (inches).
2. Tolerance is
±0.25(0.01")
unless otherwise noted.
3. Lead spacing is measured where the lead emerge package.
4. Specifications are subjected to change without notice.
Selection Guide
Par t No .
Di c e
HIGH EFFICIENCY RED (GaAsP/GaP)
HIGH EFFICIENCY RED (GaAsP/GaP)
GREEN (GaP)
GREEN (GaP)
YELLOW (GaAsP/GaP)
YELLOW (GaAsP/GaP)
HIGH EFFICIENCY RED (GaAsP/GaP)
GREEN (GaP)
SUPER BRIGHT RED (GaAlAs)
SUPER BRIGHT GREEN (GaP)
HYPER RED (InGaAlP)
SUPER BRIGHT GREEN (GaP)
L en s Ty p e
Iv (mc d )
@ 20 mA
Min .
L819IID
L819GGD
L819YYD
L819EGW
L819SRSGW/CC
L819SURKSGW
RED DIFFUSED
GREEN DIFFUSED
YELLOW DIFFUSED
WHITE DIFFUSED
WHITE DIFFUSED
WHITE DIFFUSED
20
20
12
12
12
12
30
20
100
30
300
30
Ty p .
70
70
40
40
30
30
80
50
200
50
600
50
View in g
An g l e
2θ1/2
50°
50°
50°
50°
50°
50°
Note:
1.
θ1/2
is the angle from optical centerline where the luminous intensity is 1/2 the optical centerline value.
SPEC NO: DSAA0300
REV NO: V.1
DATE: MAR/15/2001
PAGE: 1 OF 6
Electrical / Optical Characteristics at T
)
=25°C
°
Sy m b o l
Par ameter
Dev ic e
High Efficiency Red
Green
Super Bright Green
Yellow
Super Bright Red
Hyper Red
High Efficiency Red
Green
Super Bright Green
Yellow
Super Bright Red
Hyper Red
High Efficiency Red
Green
Super Bright Green
Yellow
Super Bright Red
Hyper Red
High Efficiency Red
Green
Super Bright Green
Yellow
Super Bright Red
Hyper Red
All
Ty p .
625
565
565
590
660
640
45
30
30
35
20
25
12
45
45
10
95
35
2.0
2.2
2.2
2.1
1.85
2.0
2.5
2.5
2.5
2.5
2.5
2.2
10
Max .
Un i t s
Tes t Co n d itio n s
λ
peak
Peak Wavelength
nm
IF=20mA
∆λ
1/2
Spectral Line Halfwidth
nm
IF=20mA
C
Capacitance
pF
VF=0V;f=1MHz
V
F
Forward Voltage
V
IF=20mA
I
R
Reverse Current
uA
VR = 5V
Absolute Maximum Ratings at T
)
=25°C
°
Par ameter
Power dissipation
DC Forward Current
Peak Forward Current [1]
Reverse Voltage
Operating/Storage Temperature
Lead Soldering Temperature [2]
Notes:
1. 1/10 Duty Cycle, 0.1ms Pulse Width.
2. 4mm below package base.
Hi g h
Effic ien c y
Red
105
30
150
5
Gr een
105
25
150
5
Yello w
105
30
150
5
Su p er
B r ih g t
Gr een
105
25
150
5
-40
°
C To +85
°C
Su p er
B r ig h t
Red
100
30
150
5
Hy p er Red
170
50
150
5
Un i t s
mW
mA
mA
V
260
°
C For 5 Seconds
SPEC NO: DSAA0300
REV NO: V.1
DATE: MAR/15/2001
PAGE: 2 OF 6
