AR0618LC2C Overview

Down Converter, ULTRA SMALL PACKAGE

AR0618LC2C Parametric

Parameter Name	Attribute value
Maker	MITEQ Inc
Reach Compliance Code	unknown
Other features	SMA-F, IMAGE REJECTION, LOW NOISE
structure	COAXIAL
Downconversion gain - minimum	22 dB
Maximum IF frequency	200 MHz
Minimum IF frequency	100 MHz
LO tunable	YES
maximum noise index	4 dB
Maximum operating temperature	85 °C
Minimum operating temperature	-54 °C
Maximum RF input frequency	18000 MHz
Minimum RF input frequency	6000 MHz
RF/Microwave Device Types	DOWN CONVERTER
Maximum voltage standing wave ratio	2

Preview

Download Datasheet

View All

6 TO 18 GHz LOW-NOISE RECEIVER FRONT ENDS

MODELS: AR0618LC2A, AR0618LC2B AND AR0618LC2C

FEATURES

• RF/LO Coverage ......... 6 to 18 GHz

• Conversion Gain.......... 24 dB Typical

• Noise Figure............... 3.5 dB Maximum

MITEQ’s AR model series offers state-of-the-art low-noise amplifiers integrated with our ultra-small image

rejection mixers to provide a complete receiver front-end assembly. This device comes in a nonhermetic

housing, however a hermetically-sealed housing is available for extreme environmental conditions.

ELECTRICAL SPECIFICATIONS

INPUT PARAMETERS

RF frequency range

RF VSWR (RF = -10 dBm, LO = +10 dBm)

LO frequency range

LO power range

LO VSWR (RF = -10 dBm, LO = +10 dBm)

DC power

TRANSFER CHARACTERISTICS

Conversion gain (Note 1)

Single-sideband noise figure

Image rejection (Note 1)

LO-to-RF isolation

LO-to-IF isolation

RF-to-IF isolation

Output power at 1 dB compression

Output two-tone third-order intercept point

OUTPUT PARAMETERS

IF frequency range (Note 2)

CONDITION

AR0618LC2A

AR0618LC2B

AR0618LC2C

@ 25°C

+15 VDC

CONDITION

UNITS

GHz

Ratio

GHz

dBm

Ratio

UNITS

dBm

UNITS

MHz

Ratio

MIN.

100

MIN.

+10

2.5:1

150

TYP.

3.5

TYP.

MAX.

200

MAX.

MIN.

2.5:1

+13

TYP.

MAX.

IF VSWR (IF = -10 dBm, LO = +10 dBm)

2:1

AR0618LC2C Related Products

	AR0618LC2C	AR0618LC2A	AR0618LC2B
Description	Down Converter, ULTRA SMALL PACKAGE	Down Converter, ULTRA SMALL PACKAGE	RF/MICROWAVE DOWN CONVERTER, ULTRA SMALL PACKAGE
Maker	MITEQ Inc	MITEQ Inc	MITEQ Inc
Reach Compliance Code	unknown	unknown	unknown
Other features	SMA-F, IMAGE REJECTION, LOW NOISE	SMA-F, IMAGE REJECTION, LOW NOISE	SMA-F, IMAGE REJECTION, LOW NOISE
structure	COAXIAL	COAXIAL	COAXIAL
Downconversion gain - minimum	22 dB	22 dB	22 dB
Maximum IF frequency	200 MHz	40 MHz	80 MHz
Minimum IF frequency	100 MHz	20 MHz	40 MHz
LO tunable	YES	YES	YES
maximum noise index	4 dB	4 dB	4 dB
Maximum operating temperature	85 °C	85 °C	85 °C
Minimum operating temperature	-54 °C	-54 °C	-54 °C
Maximum RF input frequency	18000 MHz	18000 MHz	18000 MHz
Minimum RF input frequency	6000 MHz	6000 MHz	6000 MHz
RF/Microwave Device Types	DOWN CONVERTER	DOWN CONVERTER	DOWN CONVERTER
Maximum voltage standing wave ratio	2	2	2
