AD632SD/883B datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> The signal circuit> AD632SD/883B

AD632SD/883B: DescriptionANALOG MULTIPLIER OR DIVIDER, 1 MHz BAND WIDTH, CDIP14, SIDE BRAZED, TO-116, CERAMIC, DIP-14; CategoryAnalog mixed-signal IC The signal circuit; File Size913KB，7 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/

Download Datasheet Parametric View All

AD632SD/883B Overview

ANALOG MULTIPLIER OR DIVIDER, 1 MHz BAND WIDTH, CDIP14, SIDE BRAZED, TO-116, CERAMIC, DIP-14

AD632SD/883B Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	Rochester Electronics
Parts packaging code	DIP
package instruction	DIP,
Contacts	14
Reach Compliance Code	unknown
Analog Integrated Circuits - Other Types	ANALOG MULTIPLIER OR DIVIDER
Nominal bandwidth	1 MHz
JESD-30 code	R-CDIP-T14
JESD-609 code	e0
length	18.885 mm
Humidity sensitivity level	NOT SPECIFIED
Maximum negative supply voltage (Vsup)	-22 V
Negative supply voltage minimum (Vsup)	-8 V
Nominal Negative Supply Voltage (Vsup)	-15 V
Maximum negative input voltage	-10 V
Number of functions	1
Number of terminals	14
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Package body material	CERAMIC, METAL-SEALED COFIRED
encapsulated code	DIP
Package shape	RECTANGULAR
Package form	IN-LINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Maximum positive input voltage	10 V
Certification status	MILITARY
Maximum seat height	2.95 mm
Maximum supply voltage (Vsup)	22 V
Minimum supply voltage (Vsup)	8 V
Nominal supply voltage (Vsup)	15 V
surface mount	NO
Temperature level	MILITARY
Terminal surface	TIN LEAD
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
width	7.62 mm
