Silicon Switching Diode Chips
CD914, CD4148, CD4531, CD6642, CD3600, CD4150,
CD6640, CD4153 & CD4454
CD914, CD4148 & CD4531 available in JANHC & JANKC per MIL-PRF-19500/116
CD4153 available in JANHC & JANKC per MIL-PRF-19500/133
CD6642 available in JANHC & JANKC per MIL-PRF-19500/578
CD6640 available in JANHC & JANKC per MIL-PRF-19500/609
Features
•
•
All junctions completely protected with silicon dioxide.
Compatible with all wire bonding and die attach techniques.
Maximum Ratings
Operating Temperature:
Storage Temperature:
-55°C to 175°C
-65°C to +175°C
Electrical Specifications @ +25 ºC (Unless Otherwise Specified)
TYPE
Number
Volts (min) Volts (pk)
CD914
CD4148
CD4531
CD6642
CD4454
100
100
100
75
75
75
75
50
mA
75
200
200
200
Vdc
0.8
0.8
0.8
1.0
Vdc
1.2
N/A
N/A
N/A
Vdc
N/A
1.2
1.2
N/A
nsec
5
5
5
4
nA
25
25
25
N/A
VBR
@ 100
μA
VRWM
IO
VF3
IF = 10 mA IF = 50 mA IF = 100 mA
VF1
VF2
Trr
IR1
@ 20 Vdc
IR2
IR3
@ 20 Vdc
TA =150°C TA =150°C
μA
@ V
μA
μA
@ V
0.5 @ 75
0.5 @ 75
0.5 @ 75
0.1 @ 50
35
35
50
N/A
75 @ 75
75 @ 75
100 @ 75
100 @ 50
IR4
Capacitance Capacitance
@ 0V
@1.5 V
pF
4.0
4.0
4.0
2.0
pF
2.8
2.8
2.8
N/A
VBR
TYPE
Number
IR = 10
μA*
Volts (min)
CD3600
CD4150
CD6640
CD4153
75
75
75
75*
VRWM
IR1
VR = 50 Vdc
μA
Vdc
0.10
0.10
0.10
0.05
IR2
VR = 50 Vdc
TA =150°C
μA
Vdc
100
100
90
150
Capacitance
VR = 0; f = 1 MHz;
ac signals = 50 mV (p-p)
pF
2.5
2.5
2.5
2.0
Trr
Volts (pk)
50
50
50
50
nsec
4
4
4
4
*@ 5
μA
for CD4153
Foward Voltage Limits - CD3600, CD4150 and CD6640:
Limits
VF1
VF2
VF3
IF = 1 mA dc IF = 10 mA dc IF = 50 mA dc
(Pulsed)
(Pulsed)
(Pulsed)
Vdc
Vdc
Vdc
0.540
0.680
0.760
0.620
0.740
0.860
VF4
VF5
IF = 100 mA dc IF = 200 mA dc
(Pulsed)
(Pulsed)
Vdc
Vdc
0.820
0.870
0.920
1.000
mimimum
maximum
Foward Voltage Limits - CD4153:
Limits
mimimum
maximum
VF1
IF = 100
μA
dc
Vdc
0.49
0.55
VF2
IF = 250
μA
dc
Vdc
0.53
0.59
VF3
IF = 1 mA dc
Vdc
0.59
0.67
VF4
IF = 2 mA dc
Vdc
0.62
0.70
VF5
IF = 10 mA dc
Vdc
0.70
0.81
VF6
IF = 20 mA dc
Vdc
0.74
0.88
Revision Date: 12/5/2013
1
CD914, CD4148, CD4531, CD6642, CD3600,
CD4150, CD6640, CD4153 & CD4454
Outline Drawing
