BZD27C11PW – BZD27C220PW
Taiwan Semiconductor
1W, 11V-220V Voltage Regulator Diode
FEATURES
●
●
●
●
●
●
●
Silicon zener diodes
Low profile surface-mount package
Zener and surge current specification
Low leakage current
Excellent stability
Moisture sensitivity level: level 1, per J-STD-020
AEC-Q101 qualified available:
ordering code with suffix “H”
● RoHS Compliant
● Halogen-free according to IEC 61249-2-21
KEY PARAMETERS
PARAMETER
V
Z
Test current I
ZT
P
tot
V
F
at I
F
=0.2A
T
J MAX
Package
Configuration
VALUE
11 - 220
5 - 50
1.0
1.0
175
UNIT
V
mA
W
V
°C
SOD-123W
Single die
APPLICATIONS
●
●
●
●
Switching mode power supply (SMPS)
Adapters
Lighting application
On-board DC/DC converter
MECHANICAL DATA
●
●
●
●
●
●
Case: SOD-123W
Molding compound meets UL 94 V-0 flammability rating
Terminal: Matte tin plated leads, solderable per J-STD-002
Meet JESD 201 class 2 whisker test
Polarity: Indicated by cathode band
Weight: 16mg (approximately)
SOD-123W
ABSOLUTE MAXIMUM RATINGS
(T
A
= 25°C unless otherwise noted)
PARAMETER
Forward voltage @ I
F
=0.2A
Power dissipation at T
L
=80°C
T
A
=25°C (Note 1)
Non-repetitive peak pulse power dissipation
100μs square pulse (Note 2)
Non-repetitive peak pulse power dissipation
10/1000μs waveform (BZD27C11PW to BZD27C100PW)
Non-repetitive peak pulse power dissipation
10/1000μs waveform (BZD27C110PW to BZD27C220PW)
Operating and storage temperature range
Notes:
1. Mounted on Cu-Pad size 5mm x 5mm
2. T
J
=25°C prior to surge
SYMBOL
V
F
P
tot
P
ZSM
P
RSM
P
RSM
T
J
,T
STG
VALUE
1.0
2.3
1.0
300
150
100
-55 to +175
UNIT
V
W
W
W
W
°C
1
Version: B1906
BZD27C11PW – BZD27C220PW
Taiwan Semiconductor
THERMAL PERFORMANCE
PARAMETER
Junction-to-lead thermal resistance
Junction-to-ambient thermal resistance
SYMBOL
R
ӨJL
R
ӨJA
TYP
22
85
24
UNIT
°C/W
°C/W
°C/W
Junction-to-case thermal resistance
R
ӨJC
Thermal Performance Note: Units mounted on PCB (5mm x 5mm Cu pad test board)
ORDERING INFORMATION
ORDERING CODE
(Note 1, 2)
BZD27CxxPWHRVG
BZD27CxxPWHRQG
BZD27CxxPW RVG
BZD27CxxPW RQG
PACKAGE
SOD-123W
SOD-123W
SOD-123W
SOD-123W
PACKING
3,000 / 7” Plastic reel
10,000 / 13” Paper reel
3,000 / 7” Plastic reel
10,000 / 13” Paper reel
Note:
1. "xx" defines voltage from 11V (BZD27C11PW) to 220V (BZD27C220PW)
2. “H” means AEC-Q101 qualified
2
Version: B1906
BZD27C11PW – BZD27C220PW
Taiwan Semiconductor
ELECTRICAL SPECIFICATIONS
(T
A
= 25°C unless otherwise noted)
Zener voltage
Part number
Marking
code
Min.
BZD27C11PW
BZD27C12PW
BZD27C13PW
BZD27C15PW
BZD27C16PW
BZD27C18PW
BZD27C20PW
BZD27C22PW
BZD27C24PW
BZD27C27PW
BZD27C30PW
BZD27C33PW
BZD27C36PW
BZD27C39PW
BZD27C43PW
BZD27C47PW
BZD27C51PW
BZD27C56PW
BZD27C62PW
BZD27C68PW
BZD27C75PW
BZD27C82PW
BZD27C91PW
BZD27C100PW
BZD27C110PW
BZD27C120PW
BZD27C130PW
BZD27C150PW
BZD27C160PW
BZD27C180PW
BZD27C200PW
BZD27C220PW
N2
N3
N4
N5
N6
N7
P0
P1
P3
P4
P5
P6
P7
P8
Q0
Q1
Q2
Q5
Q7
R1
R2
R3
R4
R5
R6
R7
R8
R9
R10
R11
R12
R13
10.5
11.4
12.4
14.3
15.2
17.1
19
20.9
22.8
25.7
28.5
31.4
34.2
37.1
40.9
44.7
48.5
53.2
58.9
64.6
71.3
77.9
86.5
95
104.5
114
123.5
142.5
152
171
190
209
V
Z
@ I
ZT (1)
V
Nom.
11
12
13
15
16
18
20
22
24
27
30
33
36
39
43
47
51
56
62
68
75
82
91
100
110
120
130
150
160
180
200
220
Max.
11.6
12.6
13.7
15.8
16.8
18.9
21
23.1
25.2
28.4
31.5
34.7
37.8
41
45.2
49.4
53.6
58.8
65.1
71.4
78.8
86.1
95.6
105
115.5
126
136.5
157.5
168
189
210
231
50
50
50
50
25
25
25
25
25
25
25
25
10
10
10
10
10
10
10
10
10
10
5
5
5
5
5
5
5
5
5
5
Temperature
Test
Clamping Voltage Leakage current coefficient of
current
Zener voltage
I
ZT
mA
Vc
V
Max.
15.7
17.0
18.9
20.9
22.9
25.6
28.4
31.0
33.8
38.1
42.2
46.2
50.1
54.1
60.7
65.5
70.8
78.6
86.5
94.4
103.5
114
126
139
150
152
185
205
224
229
254
279
9.6
8.8
7.9
7.2
6.6
5.9
5.3
4.8
4.4
3.9
3.6
3.2
3.0
2.8
2.5
2.3
2.1
1.9
1.7
1.6
1.5
1.3
1.2
1.1
1.0
0.65
0.81
0.73
0.67
0.43
0.39
0.35
@I
RSM (2)
A
I
R
@ V
R (1)
µA
Max.
4.0
3.0
2.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
8.2
9.1
10
11
12
13
15
16
18
20
22
24
27
30
33
36
39
43
47
51
56
62
68
75
82
91
100
110
120
130
150
160
V
Min.
0.05
0.05
0.05
0.05
0.06
0.06
0.06
0.06
0.06
0.06
0.06
0.07
0.07
0.07
0.08
0.08
0.08
0.09
0.09
0.09
0.09
0.09
0.09
0.09
0.09
0.09
0.09
0.09
0.09
0.09
0.09
0.09
αV
Z
@ I
ZT
mV/°C
Max.
0.10
0.10
0.10
0.10
0.11
0.11
0.11
0.11
0.11
0.11
0.11
0.12
0.12
0.12
0.13
0.13
0.13
0.13
0.13
0.13
0.13
0.13
0.13
0.13
0.13
0.13
0.13
0.13
0.13
0.13
0.13
0.13
Notes :
1. Pulse test with PW=30 ms
2. 10/1000µs waveform
4
Version: B1906
BZD27C11PW – BZD27C220PW
Taiwan Semiconductor
CHARACTERISTICS CURVES
(T
A
= 25°C unless otherwise noted)
Fig1. Steady State Power Derating Curve
Ptot - Maximum Power Dissipation (W)
1.5
1000
BZD27C12PW
BZD27C18PW
1
100
Fig2. Typical Junction Capacitance
CAPACITANCE (pF)
0.5
10
BZD27C36PW
BZD27C75PW
BZD27C220PW
f=1.0MHz
0
0
25
50
75
100
125
150
175
1
0.1
1
10
100
AMBIENT TEMPERATURE (
o
C)
REVERSE VOLTAGE (V)
Fig3. Typical Forward Characteristics
1
INSTANTANEOUS FORWARD CURRENT (A)
Fig4. Typical
Zener Impendance
10000
BZD27C220PW
BZD27C12PW
0.1
BZD27C36PW
Zz - DYNAMIC IMPEDANCE (Ω)
1000
BZD27C75PW
100
BZD27C18PW
BZD27C36PW
0.01
BZD27C220PW
10
BZD27C12PW
0.001
0.6
0.7
0.8
0.9
FORWARD VOLTAGE (V)
1
0.1
1
10
100
Iz - ZENER TEST CURRENT (mA)
5
Version: B1906
