5597-06CPB7F: Description6 CONTACT(S), FEMALE, STRAIGHT FFC/FPC CONNECTOR, SOLDER; CategoryThe connector; File Size146KB，4 Pages; ManufacturerMolex; Websitehttps://www.molex.com/molex/home

Download Datasheet Parametric View All

5597-06CPB7F Overview

6 CONTACT(S), FEMALE, STRAIGHT FFC/FPC CONNECTOR, SOLDER

5597-06CPB7F Parametric

Parameter Name	Attribute value
Contact materials	NOT SPECIFIED
Terminal spacing	1.25 mm
Total number of contacts	6
Processing package description	LEAD FREE
Lead-free	Yes
EU RoHS regulations	Yes
state	ACTIVE
Options	GENERAL PURPOSE
Manufacturer Series	5597
Contact surface matching	NOT SPECIFIED
Contact coated terminals	NOT SPECIFIED
Connection Type	FFC/FPC CONNECTOR
Connector male and female	FEMALE
Installation method	STRAIGHT
Installation type	BOARD
Number of load rows	1
Terminal type	SOLDER
UL flammability code	94V-0

Preview

Download Datasheet

View All

This document was generated on 06/04/2010

PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMA

Part Number:

Status:

Overview:

Description:

0039532065

Active

1.25mm (.049") Pitch FFC/FPC Connector, Through-Hole, Vertical, ZIF, 6 Circuits,

Lead-free

Agency Certification

E29179

General

Product Family

Series

Overview

Product Name

FFC/FPC Connectors

5597

ffc_fpc_throughhole

N/A

EU RoHS

ELV and

Complia

REACH S

Not Revie

Halogen

Status

Not Revi

Need mo

environm

Email pro

For a mu

Complian

Physical

Circuits (Loaded)

Color - Resin

Contact Position

Durability (mating cycles max)

Entry Angle

Flammability

Mated Height (in)

Mated Height (mm)

Material - Metal

Material - Plating Mating

Material - Plating Termination

Material - Resin

Number of Rows

Orientation

PC Tail Length (in)

PC Tail Length (mm)

PCB Locator

PCB Retention

Packaging Type

Pitch - Mating Interface (in)

Pitch - Mating Interface (mm)

Plating min: Mating (µin)

Plating min: Mating (µm)

Plating min: Termination (µin)

Plating min: Termination (µm)

Polarized to PCB

Stackable

Surface Mount Compatible (SMC)

Temperature Range - Operating

Termination Interface: Style

Wire/Cable Type

Natural

N/A

Vertical

94V-0

0.295 In

7.50 mm

Phosphor Bronze

Tin-Bismuth

Polyester

Vertical

0.138 In

3.50 mm

None

Tray

0.049 In

1.25 mm

-20°C to +80°C

Through Hole

FFC/FPC

Please vi

non-prod

5597Se

Electrical

Current - Maximum per Contact

Voltage - Maximum

200V

Material Info

Old Part Number

5597-06CPB7F

Reference - Drawing Numbers

Packaging Specification

SPK-5597-001
