48325-1106 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> The connector> 48325-1106

48325-1106: Description1.00mm (.039"), 1.27mm (.050") Pitch Slimline Serial ATA Receptacle, Right Angle, Reverse Type; CategoryThe connector The connector; File Size164KB，4 Pages; ManufacturerMolex; Websitehttps://www.molex.com/molex/home; Environmental Compliance

Download Datasheet Parametric Compare View All

48325-1106 Overview

1.00mm (.039"), 1.27mm (.050") Pitch Slimline Serial ATA Receptacle, Right Angle, Reverse Type

48325-1106 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Molex
Reach Compliance Code	unknow
Connector type	USB CONNECTOR
Contact to complete cooperation	AU
Contact material	COPPER ALLOY
Contact resistance	30 mΩ
Durability	500 Cycles
Insulation resistance	1000000000 Ω
insulator material	THERMOPLASTIC
Installation option 1	LOCKING
Installation method	RIGHT ANGLE
Number of connectors	ONE
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Rated current (signal)	1 A
Guideline	CSA, UL
reliability	COMMERCIAL

Preview

Download Datasheet

View All

This document was generated on 04/19/2010

PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMA

Part Number:

Status:

Overview:

Description:

0483251106

Active

Slimline Serial ATA ODD Connectors

1.00mm (.039"), 1.27mm (.050") Pitch Slimline Serial ATA Receptacle, Right Angle,

Reverse Type, Through Hole, Gold (Au) Flash Plating, with Screw and Clip, Lead free

Documents:

3D Model

Drawing (PDF)

Product Specification PS-48321-001 (PDF)

RoHS Certificate of Compliance (PDF)

Agency Certification

CSA

LR19980

E29179

General

Product Family

Series

Application

Comments

Overview

Product Name

PCB Receptacles

48325

Board-to-Board

Screw and Clip version

Slimline Serial ATA ODD Connectors

Serial ATA, Slimline Serial ATA

Physical

Circuits (Loaded)

Circuits (maximum)

Color - Resin

Durability (mating cycles max)

Flammability

Glow-Wire Compliant

Guide to Mating Part

Keying to Mating Part

Lock to Mating Part

Material - Metal

Material - Plating Mating

Material - Plating Termination

Material - Resin

Number of Rows

Orientation

PCB Locator

PCB Retention

PCB Thickness Recommended (in)

PCB Thickness Recommended (mm)

Packaging Type

Pitch - Mating Interface (in)

Pitch - Mating Interface (mm)

Pitch - Term. Interface (in)

Pitch - Term. Interface (mm)

Plating min: Mating (µin)

Plating min: Mating (µm)

Plating min: Termination (µin)

Plating min: Termination (µm)

Polarized to Mating Part

Polarized to PCB

Robotic Placement

Stackable

Surface Mount Compatible (SMC)

Black

500

94V-0

Yes

Copper Alloy

Gold

Tin

High Temperature Thermoplastic

Right Angle

Yes

0.047 In

1.20 mm

Embossed Tape on Reel

0.039 In, 0.050 In

1.00 mm, 1.27 mm

0.039 In, 0.050 In

1.00 mm, 1.27 mm

0.05

100

2.54

Yes

Pick and Place Cap

Yes

EU RoHS

ELV and

Complia

REACH S

Contains

Halogen

Status

Halogen

Need mo

environm

Email pro

For a mu

Complian

Please vi

non-prod

48325S

Mates

473001

48325-1106 Related Products

	48325-1106	SD-48325-003
Description	1.00mm (.039"), 1.27mm (.050") Pitch Slimline Serial ATA Receptacle, Right Angle, Reverse Type	1.00mm (.039"), 1.27mm (.050") Pitch Slimline Serial ATA Receptacle, Right Angle, Reverse Type
