isc
Silicon NPN Power Transistor
DESCRIPTION
·High
DC Current Gain-
: h
FE
= 30-120@I
C
= 5A
·Excellent
Safe Operating Area
·High
Current Capability
·Minimum
Lot-to-Lot variations for robust device
performance and reliable operation
APPLICATIONS
·Designed
for use in switching-control amplifiers,
BDY90
power
gates,switching regulators, converters, and inverters.
ABSOLUTE MAXIMUM RATINGS(T
a
=25
℃)
SYMBOL
V
CBO
V
CEO
V
EBO
I
C
I
CM
I
B
P
C
T
J
T
stg
PARAMETER
Collector-Base Voltage
Collector-Emitter Voltage
Emitter-Base Voltage
Collector Current-Continuous
Collector Current-Peak
Base Current-Continuous
Collector Power Dissipation
@T
C
≤25℃
Junction Temperature
Storage Temperature Range
VALUE
120
100
6
10
15
2
60
175
-65~175
UNIT
V
V
V
A
A
A
W
℃
℃
THERMAL CHARACTERISTICS
SYMBOL
R
th j-c
PARAMETER
Thermal Resistance,Junction to Case
MAX
2.5
UNIT
℃/W
isc website
：
www.iscsemi.com
1
isc & iscsemi
is registered trademark
isc
Silicon NPN Power Transistor
ELECTRICAL CHARACTERISTICS
T
C
=25℃ unless otherwise specified
SYMBOL
V
CEO(SUS)
V
CE
(sat)-1
V
CE
(sat)-2
V
BE
(sat)-1
V
BE
(sat)-2
I
CBO
I
EBO
h
FE-1
h
FE-2
h
FE-3
f
T
PARAMETER
Collector-Emitter
Voltage
Collector-Emitter
Voltage
Collector-Emitter
Voltage
Sustaining
Saturation
Saturation
CONDITIONS
I
C
= 30mA ;I
B
= 0
I
C
= 5A; I
B
= 0.5A
I
C
= 10A; I
B
= 1A
I
C
= 5A; I
B
= 0.5A
I
C
= 10A; I
B
= 1A
V
CB
=120V; I
E
=0
V
EB
=6V; I
C
=0
I
C
= 1A ; V
CE
= 2V
I
C
= 5A ; V
CE
= 5V
I
C
= 10A ; V
CE
= 5V
I
C
= 0.5 A;V
CE
= 5V;f
test
= 5MHz
30
30
20
70
MIN
120
TYP
BDY90
MAX
UNIT
V
0.5
1.5
1.2
1.5
1.0
1.0
V
V
V
V
mA
mA
Base-Emitter Saturation Voltage
Base-Emitter Saturation Voltage
Collector Cutoff Current
Emitter Cutoff current
DC Current Gain
DC Current Gain
DC Current Gain
Current-Gain—Bandwidth Product
120
MHz
Switching Times
t
on
t
stg
t
f
Turn-On Time
Storage Time
Fall Time
I
C
= 5A; I
B1
= -I
B2
= 0.5A,
V
CC
=30V
0.35
1.3
0.2
μs
μs
μs
NOTICE：
ISC reserves the rights to make changes of the content herein the datasheet at any time without
notification. The information contained herein is presented only as a guide for the applications of
our products.
ISC products are intended for usage in general electronic equipment. The products are not designed
for use in equipment which require specialized quality and/or reliability, or in equipment which
could have applications in hazardous environments, aerospace industry, or medical field. Please
contact us if you intend our products to be used in these special applications.
ISC makes no warranty or guarantee regarding the suitability of its products for any particular
purpose, nor does ISC assume any liability arising from the application or use of any products, and
specifically disclaims any and all liability, including without limitation special, consequential or
incidental damages.
