VF6323A2R

Description
For electrovalves, style B, 2p+G, female, field attachable
File Size140KB,2 Pages
ManufacturerSHIELD
Websitehttp://www.shield.net/
Download Datasheet View All

VF6323A2R Overview

For electrovalves, style B, 2p+G, female, field attachable

CONNECTORS | CONNETTORI
version 091028
For electrovalves, style B, 2p+G, female, field attachable
Per elettrovalvole, stile B, 2p+T, femmina, da cablare
EN175301-803 style B rectangular connector,
(former DIN 43650-B), ISO 6952,
2 poles + ground, contact distance 10 mm;
field attachable, screw terminals;
profile gasket;
application with electrovalves, etc.
connettore rettangolare EN175301-803 stile B,
(ex DIN 43650-B), ISO 6952,
2 poli + terra, interasse contatti 10 mm;
da cablare, con terminali a vite;
guarnizione a profilo;
applicazione con elettrovalvole, ecc.
make the description code in a few steps
A
B
C
D
(E)
(yellow codes are preferred)
forma il codice descrittivo in pochi passaggi
(i codici gialli sono preferiti)
At the first order, the sales service will communicate also a 5-character short code, to make easier filing and further orders.
Al momento del primo ordine, il servizio vendite comunicherà anche un codice breve di 5 caratteri, per semplificare l'archivio e il riordino.
VF6x xxxxx
x
xx
xxxx xxx
General characteristics
housing material: PA66 30%GF
contact material: nickel plated CuZn
max wires section: 1,50 mm
2
protection degree IEC 60529: IP65
working temperature: -40…125° C (max 70°C with electronic components)
oil resistance: good
M3 central screw material: zinc plated iron (for stainless steel, see table E)
Caratteristiche generali
materiale rivestimento: PA66 30%GF
materiale contatti: CuZn nichelato
max sezione fili: 1,50 mm
2
grado protezione
IEC 60529:
IP65
temperatura di lavoro: -40…125°C (max 70°C con componenti elettronici)
resistenza olio: buona
materiale vite centrale M3: ferro zincato (per acciaio inox, vedere tabella E)
circuit
schema
schema
circuito
(a2)
description
descrizione
voltage
tensione
Vdc
without electronic
senza elettronica
1..250
1..250
1..38
1..80
1..170
1..250
1..250
voltage
tensione
Vac
1..250
1..250
1..30
1..60
1..130
1..250
--
max
current
corrente
max
A
10
10
10
10
10
10
10
clamping
voltage
tensione
intervento
V
--
--
38..104
80..165
170..340
320..640
V+1
housing
colour
colore
rivestimento
black
nero
grey
grigio
black
nero
tipo contatto
contact type
main descript.
descriz. princip.
(a1)
VF61 02A00
VF62 02A00
VF61 04A20
VF61 04A40
VF61 04A60
VF61 04A90
VF61 05A00
A
cable gland
pressacavo
(a1)
3
3
3
3
3
3
3
B
gasket
guarnizione
(a1)
00
00
00
00
00
00
00
C
packaging
imballaggio
(a1)
S000
S000
S000
S000
S000
S000
S000
D
varistor
varistore
diode
diodo
black
nero
VF63 19A3R
VF63 19A8R
VF63 23A2R
VF63 23A4R
VF63 23A6R
VF63 23A9R
VF63 24A3R
VF63 24A8R
3
3
3
3
3
3
3
3
00
00
00
00
00
00
00
00
S000
S000
S000
S000
S000
S000
S000
S000
red Led
Led rosso
(a7)
red Led + varistor
Led rosso +
varistore
(a7)
red Led + diode
Led rosso + diodo
(a7)
10..50
70..250
1..38
1..80
1..170
1..250
10..50
70..250
10..50
70..250
1..30
1..60
1..130
1..250
--
--
10
10
10
10
10
10
10
10
--
--
38..104
80..165
170..340
320..640
V+1
V+1
transp.
trasp.
spring
contact
contatto a
molla
transp.
trasp.
transp.
trasp.
(a1) yellow codes are preferred; more other circuits available on page 46-2; columns B, C, D show standard versions, see the following tables for more data and available options;
i codici gialli sono preferiti; molti altri circuiti sono disponibili a pagina 46-2; colonne B, C, D mostrano le versioni standard, vedere le tabelle seguenti per maggiori dati e alternative possibili.
(a2) suggested wire colour, abbreviations: bn = brown, gn = green, ye = yellow, bu = blue;
colore fili consigliato, abbreviazioni: bn = marrone, gn = verde, ye = giallo, bu = blu.
(a7) the last character on the right in column A specify the Led colour: B = blue, R = red, T = yellow, W = green;
l'ultimo carattere a destra nella colonna A determina il colore del Led: B = blue, R = rosso, T = giallo, W = verde.
VF
45-22
www.shield.net
