48202-6043: DescriptionD-Subminiature Shielded I/O PCB Male Plug, Right Angle, Through Hole, 9 Circuits,#4-40 Flush Insert, 2 #4-40 Hex Internal Thread Screws Assembled, 0.76楼矛m (30楼矛")Gold (Au) Plating; CategoryThe connector The connector; File Size131KB，3 Pages; ManufacturerMolex; Websitehttps://www.molex.com/molex/home; Environmental Compliance

Download Datasheet Parametric View All

48202-6043 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	48202-6043	-	-	View	Buy Now

48202-6043 Overview

D-Subminiature Shielded I/O PCB Male Plug, Right Angle, Through Hole, 9 Circuits,#4-40 Flush Insert, 2 #4-40 Hex Internal Thread Screws Assembled, 0.76楼矛m (30楼矛")Gold (Au) Plating

48202-6043 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Reach Compliance Code	compli
Connector type	D SUBMINIATURE CONNECTOR
Contact to complete cooperation	NOT SPECIFIED
Contact point gender	MALE
Contact material	NOT SPECIFIED
DIN compliance	NO
empty shell	NO
Filter function	NO
IEC compliance	NO
insulator material	POLYESTER
MIL compliance	NO
Mixed contacts	NO
Installation type	BOARD
Options	GENERAL PURPOSE
Shell material	STEEL
Housing size	1/E
Termination type	SOLDER
Total number of contacts	9
UL Flammability Code	94V-0
Base Number Matches	1

Preview

Download Datasheet

View All

This document was generated on 03/31/2010

PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMA

Part Number:

Status:

Description:

0482026043

Active

D-Subminiature Shielded I/O PCB Male Plug, Right Angle, Through Hole, 9 Circuits,

#4-40 Flush Insert, 2 #4-40 Hex Internal Thread Screws Assembled, 0.76µm (30µ")

Gold (Au) Plating, PCB Thickness 1.60mm (.063"), Lead Free

Documents:

3D Model

Drawing (PDF)

RoHS Certificate of Compliance (PDF)

General

Product Family

Series

Application

Comments

Component Type

Product Name

Type

I/O Connectors

48202

Wire-to-Board

Shell: Steel

Plug

D-Sub

N/A

Physical

Boot Color

Circuits (Loaded)

Circuits (maximum)

Gender

Lock to Mating Part

Material - Plating Mating

Material - Plating Termination

Number of Rows

Orientation

PC Tail Length (in)

PC Tail Length (mm)

PCB Locator

PCB Retention

PCB Thickness Recommended (in)

PCB Thickness Recommended (mm)

Packaging Type

Panel Mount

Pitch - Mating Interface (in)

Pitch - Mating Interface (mm)

Pitch - Term. Interface (in)

Pitch - Term. Interface (mm)

Plating min: Mating (µin)

Plating min: Mating (µm)

Plating min: Termination (µin)

Plating min: Termination (µm)

Polarized to Mating Part

Polarized to PCB

Ports

Surface Mount Compatible (SMC)

Temperature Range - Operating

Termination Interface: Style

Waterproof / Dustproof

Wire Size AWG

N/A

Male

Yes

Gold

Tin

Right Angle

0.125 In

3.18 mm

Yes

0.063 In

1.60 mm

Tray

Yes

0.054 In, 0.109 In

1.38 mm, 2.77 mm

0.054 In, 0.109 In

1.38 mm, 2.77 mm

0.76

100

2.54

Yes

-55°C to +85°C

Through Hole

N/A

EU RoHS

ELV and

Complia

REACH S

Not Revie

Halogen

Status

Not Revi

Need mo

environm

Email pro

For a mu

Complian

Please vi

non-prod

48202S

Mates

48201

Electrical

Current - Maximum per Contact
