85001-9012: Description2.54mm (.100) Pitch DIN 41612 B Style Male Header, PBT, Right Angle, Through Hole, 0.60楼矛m (24楼矛) Selective Gold (Au) Plating, 64 Circuits, with Mounting Clips; File Size66KB，3 Pages; ManufacturerMolex; Websitehttps://www.molex.com/molex/home

Download Datasheet View All

85001-9012 Overview

2.54mm (.100) Pitch DIN 41612 B Style Male Header, PBT, Right Angle, Through Hole, 0.60楼矛m (24楼矛) Selective Gold (Au) Plating, 64 Circuits, with Mounting Clips

Preview

Download Datasheet

View All

This document was generated on 05/17/2010

PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMA

Part Number:

Status:

Overview:

Description:

0850019012

Active

din_41612

2.54mm (.100") Pitch DIN 41612 B Style Male Header, PBT, Right Angle, Through

Hole, 0.60µm (24µ") Selective Gold (Au) Plating, 64 Circuits, with Mounting Clips, No

Flux Proof

Documents:

Drawing (PDF)

Product Specification PS-85003-0001 (PDF)

RoHS Certificate of Compliance (PDF)

EU RoHS

Complia

Not Revi

REACH S

Not Revi

Halogen

Status

Not Revi

Need mo

environm

General

Product Family

Series

Application

Comments

Component Type

Overview

Product Name

Style

Backplane Connectors

85001

Backplane

With Mounting Clips. No Flux Proof

PCB Header

din_41612

IEC 603-2/DIN 41612

B

Email pro

For a mu

Complian

Please vi

non-prod

Physical

Circuits (Loaded)

Circuits (maximum)

Circuits Detail

Color - Resin

Durability (mating cycles max)

First Mate / Last Break

Guide to Mating Part

Keying to Mating Part

Material - Metal

Material - Plating Mating

Material - Plating Termination

Material - Resin

Number of Columns

Number of Pairs

Number of Rows

Orientation

PC Tail Length (in)

PC Tail Length (mm)

PCB Locator

PCB Retention

Packaging Type

Pitch - Mating Interface (in)

Pitch - Mating Interface (mm)

Pitch - Term. Interface (in)

Pitch - Term. Interface (mm)

Plating min: Mating (µin)

Plating min: Mating (µm)

Plating min: Termination (µin)

Plating min: Termination (µm)

Polarized to PCB

Stackable

Surface Mount Compatible (SMC)

Temperature Range - Operating

64

Contact Positions at: A:a1-a2,a4-a31; B:b1-b31; Y:b32;

Z:a3,a32

Natural

400

Yes

No

Yes

Brass

Gold

Tin

Polyester

16

Open Pin Field

2

Right Angle

0.118 In

3.00 mm

No

Yes

Carton

0.100 In

2.54 mm

0.100 In

2.54 mm

24

0.60

98

2.5

Yes

No

-55°C to +125°C
