SN74ALS137AN datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > logic> logic> SN74ALS137AN

SN74ALS137AN: DescriptionDecoder/Driver, ALS Series, Inverted Output, TTL, PDIP16, 0.300 INCH, ROHS COMPLIANT, PLASTIC, DIP-16; Categorylogic logic; File Size1MB，15 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

SN74ALS137AN Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	SN74ALS137AN	-	-	View	Buy Now

SN74ALS137AN Overview

Decoder/Driver, ALS Series, Inverted Output, TTL, PDIP16, 0.300 INCH, ROHS COMPLIANT, PLASTIC, DIP-16

SN74ALS137AN Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Rochester Electronics
Parts packaging code	DIP
package instruction	DIP,
Contacts	16
Reach Compliance Code	unknown
ECCN code	EAR99
Other features	ADDRESS LATCHES
series	ALS
Input adjustment	STANDARD
JESD-30 code	R-PDIP-T16
JESD-609 code	e4
length	19.305 mm
Logic integrated circuit type	OTHER DECODER/DRIVER
Number of functions	1
Number of terminals	16
Maximum operating temperature	70 °C
Minimum operating temperature
Output polarity	INVERTED
Package body material	PLASTIC/EPOXY
encapsulated code	DIP
Package shape	RECTANGULAR
Package form	IN-LINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
propagation delay (tpd)	20 ns
Certification status	Not Qualified
Maximum seat height	5.08 mm
Maximum supply voltage (Vsup)	5.5 V
Minimum supply voltage (Vsup)	4.5 V
Nominal supply voltage (Vsup)	5 V
surface mount	NO
technology	TTL
Temperature level	COMMERCIAL
Terminal surface	NICKEL PALLADIUM GOLD
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
width	7.62 mm
