HLMP-EDxx/ELxx
5 mm Precision Optical Performance Best Value
AlInGaP Lamps
Data Sheet
Description
These Precision Optical Performance AlInGaP and
AlInGaP II LEDs provide superior light output for
excellent readability in sunlight and are extremely
reliable.
These LED lamps are untinted, nondiffused, T-1 3/4
packages incorporating second generation optics
producing well defined spatial radiation patterns at
specific viewing cone angles.
These lamps are made with an advanced optical grade
epoxy, offering superior high temperature and high
moisture resistance performance in outdoor signal
and sign applications. The high maximum LED
junction temperature limit of +130°C enables high
temperature operation in bright sunlight conditions.
The package epoxy contains both uv-a and uv-b
inhibitors to reduce the effects of long term exposure
to direct sunlight.
Features
• Well defined spatial radiation pattern
• Viewing angles: 6°, 15°, 23°, 30°
• High luminous output
• Two red and amber intensity levels
AlInGaP (bright) and AlInGaP II (brightest)
• Colors: 626/630 nm red, 590/592 nm amber
• Superior resistance to moisture
• UV resistant epoxy
Benefits
• Viewing angles match traffic management sign and
requirements
• Colors meet automotive and pedestrian signal and
specifications
• Superior performance in outdoor environments
• Suitable for autoinsertion onto PC boards
Applications
• Traffic management:
Traffic signals
Work zone warning lights
Variable message signs
• Commercial outdoor advertising: signs, marquees
• Automotive: exterior and interior lights
Device Selection Guide for AlInGaP
Typical
Viewing Angle
2θ
1/2
6°
6°
15°
15°
23°
23°
30°
30°
6°
6°
15°
15°
23°
23°
30°
30°
Color and
Dominant
Wavelength
(nm), Typ.
[4]
Red 626
Red 626
Red 626
Red 626
Red 626
Red 626
Red 626
Red 626
Amber 590
Amber 590
Amber 590
Amber 590
Amber 590
Amber 590
Amber 590
Amber 590
Luminous Intensity
Iv (mcd)
[2][3]
at I
F
= 20 mA
Min.
2170
2170
590
590
450
450
270
270
2170
2170
450
450
345
345
270
270
Part Number
HLMP-EG08-T0000
HLMP-EG10-T0000
HLMP-EG15-N0000
HLMP-EG17-N0000
HLMP-EG24-M0000
HLMP-EG26-M0000
HLMP-EG30-K0000
HLMP-EG32-K0000
HLMP-EL08-T0000
HLMP-EL10-T0000
HLMP-EL15-M0000
HLMP-EL17-M0000
HLMP-EL24-L0000
HLMP-EL26-L0000
HLMP-EL30-K0000
HLMP-EL32-K0000
Leads with
Standoffs
No
Yes
No
Yes
No
Yes
No
Yes
No
Yes
No
Yes
No
Yes
No
Yes
Package
Drawing
A
B
A
B
A
B
A
B
A
B
A
B
A
B
A
B
2
Device Selection Guide for AlInGaP II
Typical
Viewing Angle
2θ
1/2
15°
15°
15°
15°
23°
23°
23°
23°
30°
30°
30°
30°
15°
15°
15°
15°
23°
23°
23°
23°
30°
30°
30°
30°
30°
Color and
Dominant
Wavelength
(nm), Typ.
[4]
Red 630
Red 630
Red 630
Red 630
Red 630
Red 630
Red 630
Red 630
Red 630
Red 630
Red 630
Red 630
Amber 592
Amber 592
Amber 592
Amber 592
Amber 592
Amber 592
Amber 592
Amber 592
Amber 592
Amber 592
Amber 592
Amber 592
Amber 592
Luminous Intensity
Iv (mcd)
[2][3]
at I
F
= 20 mA
Min.
1650
1650
1650
1650
1300
1300
1300
1300
1000
1000
1000
1000
1650
1650
1650
1650
1000
1000
1000
1000
765
765
765
765
1000
Part Number
HLMP-ED16-S0000
HLMP-ED16-S0T00
HLMP-ED18-S0000
HLMP-ED18-S0T00
HLMP-ED25-R0000
HLMP-ED25-R0T00
HLMP-ED27-R0000
HLMP-ED27-R0T00
HLMP-ED31-Q0000
HLMP-ED31-Q0T00
HLMP-ED33-Q0000
HLMP-ED33-Q0T00
HLMP-EL16-S0000
HLMP-EL16-S0R00
HLMP-EL18-S0000
HLMP-EL18-S0R00
HLMP-EL25-Q0000
HLMP-EL25-Q0R00
HLMP-EL27-Q0000
HLMP-EL27-Q0R00
HLMP-EL31-P0000
HLMP-EL31-P0R00
HLMP-EL33-P0000
HLMP-EL33-P0R00
HLMP-EL31-Q0R00
Leads with
Standoffs
No
No
Yes
Yes
No
No
Yes
Yes
No
No
Yes
Yes
No
No
Yes
Yes
No
No
Yes
Yes
No
No
Yes
Yes
No
Package
Drawing
A
A
B
B
A
A
B
B
A
A
B
B
A
A
B
B
A
A
B
B
A
A
B
B
A
Notes:
1. 2θ
1/2
is the off-axis angle where the luminous intensity is 1/2 the on-axis intensity.
2. The luminous intensity is measured on the mechanical axis of the lamp package.
3. The optical axis is closely aligned with the package mechanical axis.
4. The dominant wavelength,
λ
d
, is derived from the CIE Chromaticity Diagram and represents the color of the lamp.
3
Part Numbering System
HLMP-X X X X - X X X X X
MECHANICAL OPTIONS
00 - Bulk Packaging
DD: Ammo Pack
COLOR BIN SELECTIONS
0: No color bin limitation
K: Color bins 2 and 4
4: Amber color bin 4 only
R: Amber color bins 1, 2, 4, and 6 with V
F
max of 2.6 V
T: Red color with V
F
max of 2.6 V
MAX INTENSITY BIN
MIN INTENSITY BIN
VIEWING ANGLE and LEAD STANDOFFS
08: 6 degree without lead standoffs; AlInGaP
10: 6 degree with lead standoffs; AlInGaP
15: 15 degree without lead standoffs; AlInGaP
16: 15 degree without lead standoffs; AlInGaP II
17: 15 degree with lead standoffs; AlInGaP
18: 15 degree with lead standoffs; AlInGaP II
24: 23 degree without lead standoffs; AlInGaP
25: 23 degree without lead standoffs; AlInGaP II
26: 23 degree with lead standoffs; AlInGaP
27: 23 degree with lead standoffs; AlInGaP II
30: 30 degree without lead standoffs; AlInGaP
31: 30 degree without lead standoffs; AlInGaP II
32: 30 degree with lead standoffs; AlInGaP
33: 30 degree with lead standoffs; AlInGaP II
COLOR
D: 630 nm Red
G: 626 nm Red
L: 590/592 nm Amber
PACKAGE
E: 5 mm Round AlInGaP
4
Package Dimensions
A
8.71 ± 0.20
(0.343 ± 0.008)
5.00 ± 0.20
(0.197 ± 0.008)
B
5.00 ± 0.20
(0.197 ± 0.008)
1.14 ± 0.20
(0.045 ± 0.008)
d
8.71 ± 0.20
(0.343 ± 0.008)
2.35 (0.093)
MAX.
31.60
(1.244) MIN.
31.60
(1.244) MIN.
1.14 ± 0.20
(0.045 ± 0.008)
1.50 ± 0.15
(0.059 ± 0.006)
0.70 (0.028)
MAX.
CATHODE
LEAD
CATHODE
LEAD
0.70 (0.028)
MAX.
1.00 MIN.
(0.039)
0.50 ± 0.10 SQ. TYP.
(0.020 ± 0.004)
1.00 MIN.
(0.039)
0.50 ± 0.10 SQ. TYP.
(0.020 ± 0.004)
CATHODE
FLAT
5.80 ± 0.20
(0.228 ± 0.008)
CATHODE
FLAT
5.80 ± 0.20
(0.228 ± 0.008)
2.54 ± 0.38
(0.100 ± 0.015)
2.54 ± 0.38
(0.100 ± 0.015)
Notes:
1.
All Dimensions are in millimeters (inches).
2. Leads are mild steel, solder dipped.
3. Tapers shown at top of leads (bottom of lamp package) indicate an epoxy meniscus that may extend about 1mm (0.040 in.) down the leads.
4. Recommended PC board hole diameters:
• Lamp package A without standoffs: Flush mounting at base of lamp package = 1.143/1.067 (0.044/0.042).
• Lamp package B with standoffs: Mounting at lead standoffs = 0.965/0.889(0.038/0.035).
5. For dome height above lead stand-off seating plane, d, lamp package B. See table.
Part Number
HLMP-xx10
HLMP-xx17
HLMP-xx26
HLMP-xx32
HLMP-xx18
HLMP-xx27
HLMP-xx33
d
12.37
±
0.25
(0.487
±
0.010)
12.43
±
0.25
(0.489
±
0.010)
12.52
±
0.25
(0.493
±
0.010)
11.96
±
0.25
(0.471
±
0.010)
12.60
±
0.25
(0.496
±
0.010)
11.59
±
0.25
(0.446
±
0.010)
11.99
±
0.25
(0.472
±
0.010)
5
