SURFACE MOUNT SCHOTTKY BARRIER RECTIFIER

Preview

Download Datasheet

View All

SKN0 - SKN2

PRV : 20 - 40 Volts

I

O

: 3.0 Ampere

FEATURES :

*

High current capability

High surge current capability

High reliability

High efficiency

Low power loss

Low cost

Low forward voltage drop

Pb / RoHS Free

SURFACE MOUNT

SCHOTTKY BARRIER RECTIFIERS

SMC (DO-214AB)

0.060(1.52)

0.030(0.76)

0.320(8.13)

0.305(7.75)

0.280(7.11)

0.260(6.60)

0.008(0.203)

0.004(0.102)

0.121(3.07)

0.115(2.92)

0.245(6.22)

0.220(5.59)

0.103(2.62)

0.079(2.00)

0.012(0.305)

0.006(0.152)

MECHANICAL DATA :

*

Case : SMC Molded plastic

Epoxy : UL94V-O rate flame retardant

Lead : Lead Formed for Surface Mount

Polarity : Color band denotes cathode end

Mounting position : Any

Weight : 0.21 gram

Dimensions in inches and (millimeter)

MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS

Rating at 25

°

C ambient temperature unless otherwise specified.

Single phase, half wave, 60 Hz, resistive or inductive load.

For capacitive load, derate current by 20%.

RATING

Maximum Recurrent Peak Reverse Voltage

Maximum RMS Voltage

Maximum DC Blocking Voltage

Maximum Average Forward Current

T

L

= 95

°C

SYMBOL

V

RRM

V

RMS

V

DC

I

F(AV

)

I

FSM

V

F

I

R

I

R(H)

R

θ

JL

T

J

T

STG

SKN0

20

14

20

SKN1

30

21

30

3.0

80

SKN2

40

28

40

UNIT

V

A

Maximum Peak Forward Surge Current,

8.3ms single half sine wave superimposed

on rated load (JEDEC Method) T

L

= 75°C

Maximum Forward Voltage at I

F

= 3.0 A (Note 1)

Maximum Reverse Current at

Rated DC Blocking Voltage (Note 1)

Typical Thermal Resistance

Junction Temperature Range

Storage Temperature Range

Ta = 25

°C

Ta = 100

°C

0.475

0.500

2.0

20

- 65 to + 125

0.525

V

mA

°C/W

°C

Note :

(1) Pulse Test : Pulse Width = 300

µs,

Duty Cycle = 2%.

Page 1 of 2

Rev. 02 : March 25, 2005

SKN0_05 Related Products

	SKN0_05	SKN0	SKN2	SKN1
Description	SURFACE MOUNT SCHOTTKY BARRIER RECTIFIER	SURFACE MOUNT SCHOTTKY BARRIER RECTIFIER	SURFACE MOUNT SCHOTTKY BARRIER RECTIFIER	SURFACE MOUNT SCHOTTKY BARRIER RECTIFIER
Is it Rohs certified?	-	conform to	conform to	conform to
package instruction	-	SMC, 2 PIN	SMC, 2 PIN	SMC, 2 PIN
Reach Compliance Code	-	compli	compli	compli
ECCN code	-	EAR99	EAR99	EAR99
Other features	-	HIGH RELIABILITY, LOW POWER LOSS	HIGH RELIABILITY, LOW POWER LOSS	HIGH RELIABILITY, LOW POWER LOSS
application	-	EFFICIENCY	EFFICIENCY	EFFICIENCY
Configuration	-	SINGLE	SINGLE	SINGLE
Diode component materials	-	SILICON	SILICON	SILICON
Diode type	-	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE
Maximum forward voltage (VF)	-	0.475 V	0.525 V	0.5 V
JEDEC-95 code	-	DO-214AB	DO-214AB	DO-214AB
JESD-30 code	-	R-PDSO-C2	R-PDSO-C2	R-PDSO-C2
Maximum non-repetitive peak forward current	-	80 A	80 A	80 A
Number of components	-	1	1	1
Phase	-	1	1	1
Number of terminals	-	2	2	2
Maximum operating temperature	-	125 °C	125 °C	125 °C
Minimum operating temperature	-	-65 °C	-65 °C	-65 °C
Maximum output current	-	3 A	3 A	3 A
Package body material	-	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
Package shape	-	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	-	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE
Maximum repetitive peak reverse voltage	-	20 V	40 V	30 V
Maximum reverse current	-	2000 µA	2000 µA	2000 µA
surface mount	-	YES	YES	YES
technology	-	SCHOTTKY	SCHOTTKY	SCHOTTKY
Terminal form	-	C BEND	C BEND	C BEND
Terminal location	-	DUAL	DUAL	DUAL
Base Number Matches	-	1	1	1
