SML4728A - SML4764A
V
Z
: 3.3 - 100 Volts
P
D
: 1 Watt
FEATURES :
* Complete Voltage Range 3.3 to 100 Volts
* High peak reverse power dissipation
* High reliability
* Low leakage current
* Pb / RoHS Free
SURFACE MOUNT SILICON
ZENER DIODES
SMA
1.3
±
0.2
5.3
±
0.35
4.2
±
0.25
2.3
±
0.2
1.6
±
0.25
2.6
±
0.15
MECHANICAL DATA :
* Case : SMA Molded plastic
* Epoxy : UL94V-O rate flame retardant
* Polarity : Color band denotes cathode end
* Mounting position : Any
* Weight : 0.060 gram (Approximately)
1.6
±
0.25
Dimensions in millimeters
MAXIMUM RATINGS
Rating at 25 °C ambient temperature unless otherwise specified
Rating
DC Power Dissipation at T
L
= 75 °C (Note1)
Maximum Forward Voltage at I
F
= 200 mA
Junction Temperature Range
Storage Temperature Range
Symbol
P
D
V
F
T
J
T
STG
Value
1.0
1.2
- 55 to + 150
- 55 to + 150
Unit
W
V
°C
°C
Note :
(1) P.C.B. Mounted on 0.31x0.31x0.08" (8x8x2mm) copper areas pad
Fig. 1 MAXIMUM CONTINUOUS POWER DERATING
P
D
, MAXIMUM DISSIPATION
(WATTS)
1.25
1.00
0.75
0.50
0.25
0
0
P.C.B. Mounted on
0.31x0.31x0.08" (8x8x2mm)
copper areas pads
25
50
75
100
125
150
175
T
L,
LEAD TEMPERATURE (°C)
Page 1 of 2
Rev. 05 : September 18, 2008
TH97/10561QM
TW00/17276EM
IATF 0060636
SGS TH07/1033
ELECTRICAL CHARACTERISTICS
Rating at 25 °C ambient temperature unless otherwise specified
Nominal Zener
Maximum Zener
Impedance
I
ZT
(mA)
76.0
69.0
64.0
58.0
53.0
49.0
45.0
41.0
37.0
34.0
31.0
28.0
25.0
23.0
21.0
19.0
17.0
15.5
14.0
12.5
11.5
10.5
9.5
8.5
7.5
7.0
6.5
6.0
5.5
5.0
4.5
4.0
3.7
3.3
3.0
2.8
2.5
Z
ZT
@ I
ZT
(Ω )
10
10
9.0
9.0
8.0
7.0
5.0
2.0
3.5
4.0
4.5
5.0
7.0
8.0
9.0
10
14
16
20
22
23
25
35
40
45
50
60
70
80
95
110
125
150
175
200
250
350
Z
ZK
@ I
ZK
(Ω )
400
400
400
400
500
550
600
700
700
700
700
700
700
700
700
700
700
700
750
750
750
750
750
1000
1000
1000
1000
1500
1500
1500
2000
2000
2000
2000
3000
3000
3000
I
ZK
(mA)
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
0.5
0.5
0.5
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
Maximum Reverse
Leakage Current
I
R
@ V
R
(μA)
100
100
50
10
10
10
10
10
10
10
10
10
10
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
(V)
1.0
1.0
1.0
1.0
1.0
1.0
2.0
3.0
4.0
5.0
6.0
7.0
7.6
8.4
9.1
9.9
11.4
12.2
13.7
15.2
16.7
18.2
20.6
22.8
25.1
27.4
29.7
32.7
35.8
38.8
42.6
47.1
51.7
56.0
62.2
69.2
76.0
Maximum DC
Zener Current
I
ZM
(mA)
276
252
234
217
193
178
162
146
133
121
110
100
91
83
76
69
61
57
50
45
41
38
34
30
27
25
23
22
19
18
16
14
13
12
11
10
9.0
Maximum
Surge Current
I
RM
(2)
(mApk)
1380
1260
1190
1070
970
890
810
730
660
605
550
500
454
414
380
344
305
285
250
225
205
190
170
150
135
125
115
110
95
90
80
70
65
60
55
50
45
Voltage
V
Z
(1)
@ I
ZT
(V)
SML4728A
SML4729A
SML4730A
SML4731A
SML4732A
SML4733A
SML4734A
SML4735A
SML4736A
SML4737A
SML4738A
SML4739A
SML4740A
SML4741A
SML4742A
SML4743A
SML4744A
SML4745A
SML4746A
SML4747A
SML4748A
SML4749A
SML4750A
SML4751A
SML4752A
SML4753A
SML4754A
SML4755A
SML4756A
SML4757A
SML4758A
SML4759A
SML4760A
SML4761A
SML4762A
SML4763A
SML4764A
Notes :
(1) Standard voltage tolerance is 5%, No Suffix ± 10%
±
(2) Surge current is a non-repetitive, 8.3ms pulse width square wave or equivalent sine-wave superimposed on IZT per JEDEC Method
(3) " SML " will be omitted in marking on the diode.
3.3
3.6
3.9
4.3
4.7
5.1
5.6
6.2
6.8
7.5
8.2
9.1
10
11
12
13
15
16
18
20
22
24
27
30
33
36
39
43
47
51
56
62
68
75
82
91
100
Type
Page 2 of 2
Rev. 05 : September 18, 2008
