SMZ35 Series
V
Z
: 3.3 - 200 Volts
P
D
: 1.5 Watts
*
*
*
*
*
Complete Voltage Range 3.3 to 200 Volts
High peak reverse power dissipation
High reliability
Low leakage current
Pb Free / RoHS Compliant
SURFACE MOUNT SILICON
ZENER DIODES
SOD-123FL
2.5(0.098)
2.9(0.114)
1.55(0.061)
1.95(0.077)
0.6(0.024)
1.0(0.039)
0.05(0.002)
0.25(0.010)
0.5(0.020)
1.1(0.043)
max0.1(0.004)
3.5(0.138)
3.9(0.154)
FEATURES :
MECHANICAL DATA :
* Case: JEDEC SOD-123FL, molded plastic
over passivated chip
* Terminals: Solder Plated, solderable per
MIL-STD-750, Method 2026
* Polarity: Color band denotes cathode end
* Mounting position : Any
* Weight: 0.02 gram (Approximate)
0.8(0.031)
1.2(0.047)
Dimensions in millimeters
MAXIMUM RATINGS
Rating at 25
°
C ambient temperature unless otherwise specified
Rating
DC Power Dissipation at T
L
= 75
°C
(Note1)
Maximum Forward Voltage at I
F
= 200 mA
Junction Temperature Range
Storage Temperature Range
Note :
Symbol
P
D
V
F
T
J
Ts
Value
1.5
1.5
- 55 to + 150
- 55 to + 150
Unit
W
V
°C
°C
(1) T
L
= Lead temperature at 5.0 mm
2
( 0.013 mm thick ) copper land areas.
Fig. 1 POWER TEMPERATURE DERATING CURVE
1.5
1.2
0.9
0.6
0.3
0
5.0 mm
2
( 0.013 mm thick )
copper land areas.
25
50
75
100
125
150
175
P
D
, MAXIMUM DISSIPATION
(WATTS)
T
L,
LEAD TEMPERATURE (
°
C)
Page 1 of 2
Rev. 01 : January 12, 2009
TH97/10561QM
TW00/17276EM
IATF 0060636
SGS TH07/1033
ELECTRICAL CHARACTERISTICS
(Rating at 25 °C ambient temperature unless otherwise specified)
Type No.
Marking
Nominal Zener
Voltage
I
ZT
V
Z
@ I
ZT
(V)
SMZ353D
SMZ353G
SMZ353J
SMZ354D
SMZ354H
SMZ355B
SMZ355G
SMZ356C
SMZ356I
SMZ357F
SMZ358C
SMZ359B
SMZ3510
SMZ3511
SMZ3512
SMZ3513
SMZ3515
SMZ3516
SMZ3518
SMZ3520
SMZ3522
SMZ3524
SMZ3527
SMZ3530
SMZ3533
SMZ3536
SMZ3539
SMZ3543
SMZ3547
SMZ3551
SMZ3556
SMZ3562
SMZ3568
SMZ3575
SMZ3582
SMZ3591
SMZ35B0
SMZ35B1
SMZ35B2
SMZ35B3
SMZ35B5
SMZ35B6
SMZ35B8
SMZ35D0
A9
B9
C9
D9
E9
F9
H9
J9
K9
M9
N9
P9
R9
X9
Y9
Z9
A0
B0
C0
D0
E0
F0
H0
J0
K0
M0
N0
P0
R0
X0
Y0
Z0
A1
B1
C1
D1
E1
F1
H1
J1
K1
M1
N1
P1
3.3
3.6
3.9
4.3
4.7
5.1
5.6
6.2
6.8
7.5
8.2
9.1
10
11
12
13
15
16
18
20
22
24
27
30
33
36
39
43
47
51
56
62
68
75
82
91
100
110
120
130
150
160
180
200
(mA)
113.6
104.2
96.1
87.2
79.8
73.5
66.9
60.5
55.1
50.0
45.7
41.2
37.5
34.1
31.2
28.8
25.0
23.4
20.8
18.7
17.0
15.6
13.9
12.5
11.4
10.4
9.6
8.7
8.0
7.3
6.7
6.0
5.5
5.0
4.6
4.1
3.7
3.4
3.1
2.9
2.5
2.3
2.1
1.9
Z
ZT
@ I
ZT
(Ω)
10
9.0
7.5
6.0
5.0
4.0
2.0
2.0
2.5
3.0
3.5
4.0
4.5
5.5
6.5
7.0
9.0
10
12
14
17.5
19
23
26
33
38
45
53
67
70
86
100
120
140
160
200
250
300
380
450
600
700
900
1900
Maximum Zener
Impedance
Z
ZK
@ I
ZK
(Ω)
500
500
500
500
500
350
250
200
200
400
400
500
500
550
550
550
600
600
650
650
650
700
700
750
800
850
900
950
1000
1100
1300
1500
1700
2000
2500
3000
3100
4000
4500
5000
6000
6500
7000
9990
I
ZK
(mA)
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
0.5
0.5
0.5
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
Maximum Reverse
Leakage Current
I
R
@ V
R
(
µ
A)
100
75
25
5.0
5.0
5.0
40
40
50
50
50
50
50
50
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
(V)
1.0
1.0
1.0
1.0
1.5
2.0
3.0
4.0
5.2
6.0
6.5
7.0
8.0
8.4
9.1
9.9
11.4
12.2
13.7
15.2
16.7
18.2
20.6
22.8
25.1
27.4
29.7
32.7
35.8
38.8
42.6
47.1
51.7
56.0
62.2
69.2
76.0
83.6
91.2
98.8
114.0
121.6
136.8
152.0
Maximum DC
Zener Current
I
ZM
(mA)
454
416
384
348
319
294
267
241
220
200
182
164
150
136
125
115
100
93
83
75
68
62
55
50
45
41
38
34
31
29
26
24
22
20
18
16
15
13
12
11
10
9.0
8.0
7.0
Note :
(1) The type number listed have a standard tolerance on the nominal zener voltage of ± 5.0%.
Page 2 of 2
Rev. 01 : January 12, 2009
