TH97/10561QM
TW00/17276EM
IATF 0060636
SGS TH07/1033
ZPU100 - ZPU180
V
Z
:
100 to 180V
P
D
:
1.3W
FEATURES :
* Glass passivated junction chip
* For use in stabilizing and clipping circuits with
higher power rating.
* Other tolerances are available upon request.
* Pb / RoHS Free
ZENER DIODES
DO - 41
0.108 (2.74)
0.078 (1.99)
1.00 (25.4)
MIN.
0.205 (5.20)
0.161 (4.10)
MECHANICAL DATA :
* Case : DO-41 Molded plastic
* Epoxy : UL94V-O rate flame retardant
* Lead : Axial lead solderable per MIL-STD-202,
Method 208 guaranteed
* Polarity : Color band denotes cathode end
* Mounting position : Any
* Weight : 0.335 gram
0.034 (0.86)
0.028 (0.71)
1.00 (25.4)
MIN.
Dimensions in inches and ( millimeters )
Maximum Ratings and Thermal Characteristics
Parameter
Zener Current see Table "Characteristics"
Power Dissipation
Thermal Resistance Junction to Ambient Air
Junction temperature
Storage temperature range
P
D
R
ӨJA
T
J
T
STG
(Rating at 25
°
C ambient temperature unless otherwise specified.)
Symbol
Value
1.3
(1)
130
(1)
175
-55 to + 175
Unit
W
°C/W
°C
°C
Note :
(1) Valid provided that leads at a distance of 10mm from case are kept at ambient temperature.
Electrical Characteristics
Zener Voltage
V
Z
@ I
ZT
Type No.
Min.
(V)
88
107
130
160
Max.
(V)
110
134
165
200
(1)
(Ratings at 25
°
C ambient temperature unless otherwise specified.)
Test
Current
I
ZT
(mA)
5
5
5
5
ZPU100
ZPU120
ZPU150
ZPU180
Dynamic
Resistance
at I
ZT
, f = 1kHz
rzj
(Ω)
140 (<300)
170 (<330)
200 (<360)
220 (<380)
Reverse
Voltage at
I
R
= 0.5
μA
V
R
(V)
>75
>90
>112
>134
Admissible
Zener current
(2)
I
Z
(mA)
10
8.5
7
5.5
Temp. Coeff. of
Zener Voltage at I
ZT
α
VZ
(10
–4
/°C)
Min.
+9
+9
+9
+9
Max.
+13
+13
+13
+13
Notes :
(1) Tested with pulses tp = 5 ms
(2) Valid provided that electrodes are kept at ambient temperature
Page 1 of 1
Rev. 04 : June 11, 2008
