FW FW5A SF SF5A
■
■
■
FULL SIZE HIGH PERFORMANCE RELAYS
FW FW5A SF SF5A
■
■
■
ELECTRICAL CHARACTERISTICS
CONTACT ARRANGEMENT
OPERATING CHARACTERISTICS
TIMING
TWO POLE FULL SIZE
CRYSTAL CAN RELAY
2 Form C
CONTACT MATERIAL
FW QUALIFIED TO MIL–R–5757/10
Stationary:
Bifurcated hardened silver alloy
Moveable:
Gold plated hardened silver alloy
CONTACT RESISTANCE
FW
BLUE BEAD
B1
A2
X1
(+)
A3
Before Life:50 milliohms max.
(measured @ 10 mA @ 6 Vdc)
After Life:100 Milliohms max.
(measured @ 2 mA @ 28 Vdc)
SF
MECHANICAL LIFE EXPECTANCY
Operate Time:
15 ms max. (SF)
5 ms (FW)
6 ms max. (MIL-R-5757/10)
Release Time:
10 ms max. (SF)
5 ms max. (FW)
6 ms max. (MIL-R-5757/10)
Contact Bounce:
2 ms max.
DIELECTRIC WITHSTANDING VOLTAGE
B3
X2
B2
A1
50 million operations
COIL VOLTAGE
FEATURES
■
■
Hermetically sealed
Up to 5 amps switching
■
High shock & vibration ratings
■
Optional terminals
& mounting options
■
Excellent RF switching
.030
+.003 –.002
(0.76
+.08 –.06
)
1.8 Vdc to 110 Vdc
COIL POWER
Between Open Contacts:
500 Vrms, 60 Hz
Between Adjacent Contacts:
1,000 Vrms, 60 Hz
Between Contacts and Coil:
1,000 Vrms, 60 Hz
INSULATION RESISTANCE
1.5 watts max. @ 25° C
DUTY CYCLE
10,000 Megohms @ 500 Vdc
ENVIRONMENTAL CHARACTERISTICS
TEMPERATURE RANGE
Continuous
PICK-UP VOLTAGE
Approximately 50% of
nominal coil voltage
PICK-UP SENSITIVITY
-65° to +125°C
WEIGHT
1
.030 RAD.
(.76)
.210
(5.33) MAX
C BLUE BEAD
L
250 mW (FW)
40 mW (SF)
80 mW (SF 5A)
RF PERFORMANCE (FW ONLY)
FREQUENCY
(MHz)
–.002
–.06
)
0.6 oz. max. ( FW)
0.7 oz. max. (SF 6)
1.1 oz. max. (SF/SF 5A)
STANDARD VIBRATION RESISTANCE
C
L
.400
(10.16)
.600
(15.24)
.187
±.020
(4.75
±.51
)
.200
(5.08)
RF LOSSES VSWR
(dB)
ISOLATION
(dB)
20 G’s, 10 to 2000 Hz (FW)
15 G’s, 10 to 2000 Hz (SF)
QPL: 20 G’s, 10 to 2000 Hz
SHOCK RESISTANCE
.030
+.003
(0.76
+.08
2
BLUE
100
250
500
750
1,000
0.1
0.2
0.3
0.4
0.4
1.17:1
1.18:1
1.19:1
1.19:1
1.19:1
40
33
28
25
23
100 G’s, 6 ±1 ms
QPL APPROVAL
MIL-R-5757/10 (FW only)
QPL EQUIVALENT
MIL-R-5757/13 (SFonly)
.400
(10.16)
.600
(15.24)
.200
(5.08)
CONTACT RATINGS
.030
+.003 –.002
(0.76
+.08 –.06
)
CONTACT
LOAD
TYPE
OPERATIONS
MIN.
3.000
±.000
(76.20
±.76
)
3
BLUE
.400
(10.16)
.600
(15.24)
.200
(5.08)
5 A @ 28 Vdc (FW5A/SF5A)
3 A @ 28 Vdc (FW)
2 A @ 28 Vdc (SF)
1 A @ 115 Vac, 60 Hz & 400 Hz (FW)
0.3 A @ 115 Vac, 60 Hz & 400 Hz (SF)
1 A @ 28 Vdc
0.1 A @ 28 Vdc
10 uA @ 50 mVdc
75 WATTS @ 50 MHz (FW)
Resistive
Resistive
Resistive
Resistive
Resistive
Inductive (200 mH)
Lamp
Low Level
RF
100,000
100,000
100,000
100,000
100,000
100,000
100,000
1,000,000
10,000,000
TERMINALS
38
Tyco Electronics Corporation www.tycoelectronics.com 800-522-6752 (U.S.A.) or 717-564-0100 Specifications subject to change. CII and TYCO are trademarks. ©2003 by Tyco Electronics Corporation
FW FW5A SF SF5A
■
■
■
FULL SIZE HIGH PERFORMANCE RELAYS
FW COIL DATA
NOM.
COIL
VOLTAGE
(Vdc)
COIL
RESISTANCE
IN OHMS
±10% @ 25°C
PICKUP
VOLTAGE
Vdc (MAX.)
@ 25°C
PICKUP
VOLTAGE
Vdc (MAX.)
@ 125°C
DROPOUT
VOLTAGE
Vdc (MIN.)
@ 25°C
DROPOUT
VOLTAGE
Vdc (MIN.)
@ -65°C
NOM. COIL
POWER
(W)
@ 25°C
MAX.
COIL
VOLTAGE
COIL
DESIG.
6.3
12.6
17.6
26.5
32.0
48.0
56.0
75.0
110.0
35
200
340
675
975
2,450
3,150
5,000
9,100
3.2
6.8
8.9
13.5
15.5
25.0
30.0
38.0
51.0
4.4
9.4
12.3
18.7
21.5
34.7
41.6
52.7
70.7
0.35
0.74
0.97
1.47
1.69
2.73
3.27
4.14
5.56
0.23
0.49
0.64
0.96
1.1
1.8
2.1
2.7
3.6
1.13
.79
.91
1.04
1.05
.94
1.90
1.13
1.33
7.9
15.8
22.0
33.1
40.0
60.0
70.0
93.8
137.5
A
D
E
G
H
L
M
N
R
SF5 /SF6 COIL DATA
NOM.
COIL
VOLTAGE
(Vdc)
NOM.
CURRENT
(mA)
COIL
RESISTANCE
IN OHMS
±10% @ 25°C
PICKUP
CURRENT
(mA)
@ 25°C
NOM. COIL
POWER
(mW)
@ 25°C
COIL
DESIG.
1.8
9.0
12.6
16.5
18.0
20.0
26.5
36.0
40.0
90.0
18.0
12.6
11.0
9.0
8.0
5.3
4.5
4.0
20
500
1,000
1,500
2,000
2,500
5,000
8,000
10,000
45.0
9.0
6.5
5.2
4.5
4.0
2.8
2.3
2.0
162
162
159
182
162
160
140
162
160
A
E
F
G
H
J
W
L
Y
SF5A COIL DATA
NOM.
COIL
VOLTAGE
(Vdc)
NOM.
CURRENT
(mA)
COIL
RESISTANCE
IN OHMS
±10% @ 25°C
PICKUP
CURRENT
(mA)
@ 25°C
NOM. COIL
POWER
(mW)
@ 25°C
COIL
DESIG.
2.8
4.0
12.0
18.0
26.5
40.0
140.0
80.0
24.0
18.0
10.6
8.0
20
50
500
1,000
2,500
5,000
65.0
41.6
12.5
9.3
5.6
4.0
392
320
288
324
281
320
A
B
E
F
J
W
NOTE:
FW/FW5A = .875 (22.23) MAX
SF6 = .900 (22.86) MAX
SF5/SF5A5 = 1.281 (32.54) MAX
.800 MAX (20.32)
.400 MAX
(10.16)
.562
(14.27)
.281
(7.14)
.400 MAX
(10.16)
.031
(.79)
1.330 MAX (33.78)
.400 MAX
(10.16)
.375
(9.53)
1.062 (26.97)
.400 MAX
(10.16)
1.320 MAX (33.53)
.120 DIA.
.800 MAX (20.32)
.250
(6.35)
.800 MAX (20.32)
+4-40 THD.
2 STUDS
1.078 (27.38)
.030
(.76)
1.062 (26.96)
.800 MAX (20.32)
(NOTE)
(NOTE)
.375
(9.53)
.120
(3.06)
(NOTE)
.020
(.51)
(NOTE)
01
02
09
MOUNTING STYLES
TYPE
SERIES
TERMINALS
MOUNTINGS
.375
±
.030
(9.52
±
.25
)
.125
±
.020
(9.53
±
.51
)
20
SPECIFYING A PART NUMBER EXAMPLE
:
COILS
FEATURES
FW
SF
SF5A
SF
1
5
5
6
1
1
1
1
20
20
20
20
G
W
W
W
00
00
00
00
39
