WMS128K8-85DECA datasheet, PDF

Datasheet> All Categories > storage> storage> WMS128K8-85DECA

WMS128K8-85DECA: DescriptionStandard SRAM, 128KX8, 85ns, CMOS, CDSO32, CERAMIC, SOJ-32; Categorystorage storage; File Size146KB，8 Pages; ManufacturerMicrosemi; Websitehttps://www.microsemi.com

Download Datasheet Parametric View All

WMS128K8-85DECA Overview

Standard SRAM, 128KX8, 85ns, CMOS, CDSO32, CERAMIC, SOJ-32

WMS128K8-85DECA Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
package instruction	CERAMIC, SOJ-32
Reach Compliance Code	unknown
Maximum access time	85 ns
JESD-30 code	R-CDSO-J32
length	21.1 mm
memory density	1048576 bit
Memory IC Type	STANDARD SRAM
memory width	8
Number of functions	1
Number of terminals	32
word count	131072 words
character code	128000
Operating mode	ASYNCHRONOUS
Maximum operating temperature	70 °C
Minimum operating temperature
organize	128KX8
Package body material	CERAMIC, METAL-SEALED COFIRED
encapsulated code	SOJ
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Parallel/Serial	PARALLEL
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Certification status	Not Qualified
Maximum seat height	3.96 mm
Maximum supply voltage (Vsup)	5.5 V
Minimum supply voltage (Vsup)	4.5 V
Nominal supply voltage (Vsup)	5 V
surface mount	YES
technology	CMOS
Temperature level	COMMERCIAL
Terminal form	J BEND
Terminal pitch	1.27 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED

Preview

Download Datasheet

View All

White Electronic Designs

FEATURES

Access Times 70, 85, 100, 120ns

Revolutionary, Center Power/Ground Pinout

JEDEC Approved

• 32 lead Ceramic SOJ (Package 101)

Evolutionary, Corner Power/Ground Pinout

JEDEC Approved

• 32 pin Ceramic DIP (Package 300)

• 32 lead Ceramic SOJ (Package 101)

• 32 lead Ceramic Flat Pack (Package 206)

WMS128K8-XXX

128Kx8 MONOLITHIC SRAM, SMD 5962-96691

MIL-STD-883 Compliant Devices Available

Commercial, Industrial and Military Temperature Range

5 Volt Power Supply

Low Power CMOS

2V Data Retention Devices Available

(Low Power Version)

TTL Compatible Inputs and Outputs

EVOLUTIONARY

INOUT

CSOJ

32 C SOJ (DR)

VOLUTIONARY

INOUT

32 DIP (C)

32 C SOJ (DE)

FLATPA

32 FL ATPACK (FE)

IEW

ESCRIPTION

0-16

I/O

0-7

GND

Address Inputs

Data Input/Output

Chip Select

Output Enable

Write Enable

+5.0V Power

Ground

EPTEMBER

2002 R

. 5

White Electronic Designs Corporation • (602) 437-1520 • www.whiteedc.com
