Real time clock module
REAL TIME CLOCK MODULE (I
2
C-Bus)
Low current consumption
Product Number (Please contact us)
RTC-8564JE : Q41856471000100
RTC-8564NB : Q41856492000200
RX-8564LC : Q418564C2xxxx00
RTC - 8564
JE
/
NB
RX - 8564 LC
Built
in frequency adjusted 32.768 kHz crystal unit.
Interface
Type
׃
I
2
C-Bus Interface (400kHz)
Operating
voltage range
׃
1.8Vto5.5V
Timekeeper
voltage range
׃
1.0Vto5.5V/-20C to +70C
Low
backup current
׃
275nA/3.0V(Typ.)
32.768
kHz frequency output function
׃
C-MOS output With Control Pin
The
various functions include full calendar, alarm, timer,
and power supply voltage monitoring function
*
The I
2
C-Bus is a trademark of NXP Semiconductors
Actual size
RTC-8564JE
RTC-8564NB
RX-8564LC
Block
diagram
Overview
Interface
Type
Control 1
OSC
Voltage Detector
Control 2
Seconds
Minutes
Hours
DIVIDER
Days
Weekdays
Month / Century
Years
00
32.768 kHz
CRYSTAL
•I
2
C-Bus Interface.(Hi-speed bus specifications 400kHz)
I
2
C-Bus slave address:read A3h and write A2h
Low Timekeeper voltage range
•1.0V to5.5V/ Ta=-20Cto+70C
•1.1V to5.5V/ Ta=-40Cto+85C
CLKOUT
CLKOE
OUTPUT
CONTROL
32.768
kHz frequency output function
•CLKOUT pin output (C-MOS output ), CL=30 pF
•CLKOE pin enables output on/off control.
•Output selectable
<32.768kHz,1024Hz,32Hz,1Hz>
/ INT
SCL
SDA
I C-BUS
INTERFACE
2
CONTROL
LOGIC
Minutes Alarm
Hour Alarm
Day Alarm
Weekday Alarm
CLKOUT frequency
Timer Control
Timer
0F
The
various interrupt function
•Timer function can be set up between 1/4096 second and
255 minutes.
• Alarm function can be set to any combination of day of
week, hour, or minute.
ADDRESS
POR
REGISTER
Pin Function
Signal Name Input/Output
SCL
SDA
CLKOUT
Input
Function
Serial clock input pin.
32.768kHzclock output pin with the
output control function. (C-MOS)
CLKOE pin control the condition of
CLKOUT with FE-bit, etc.
CLKOE pin
input
FE
bit
1
0
1
0
CLKOUT pin
output
Output
(C-MOS)
OFF
(LOW)
OFF
(LOW)
OFF
(LOW)
Terminal connection/External dimensions
RTC8564JE
0.65
(Unit׃mm)
RX8564LC
1.
2.
3.
4.
5.
6.
N.C.
N.C.
N.C.
N.C.
/INT
GND
2.8
2.4
1.2 Max.
RTC8564NB
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
N.C.
N.C.
CLKOE
V
DD
CLKOUT
SCL
SDA
(GND)
GND
/INT
20.
19.
7.0
0.3
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
/INT
0.5
22.
21.
6.3
Max.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
17.
16.
15.
N.C.
SDA
SCL
CLKOUT
V
DD
CLKOE
N.C.
N.C.
5.0
0.2
4.8
19.
18.
17.
16.
15.
14.
13.
12.
3.6
Bi-directional Data input and output pin.
Output
GND
(GND)
18.
20.
0.5
12.
11.
10.
9.
8.
7.
N.C.
CLKOE
V
DD
CLKOUT
SCL
SDA
5.4
14.
1.5
Max.
13.
1.3
0.1
CLKOE
Input
HIGH
LOW
12.
6.0
0.2
11.
/INT
V
DD
GND
Output
-
-
Interrupt output
(N-ch open drain)
VSOJ20
pin
SON22
pin
VSOJ12pin
Connected to a positive power supply.
Connected to a ground.
*Stop using the glue
Any glue must never use it after soldering LC-package to a circuit board.This product has glass on the back side of a package.When glue invasions
between circuit board side and glass side, then glass cracks by thermal expansion of glue.In this case a crystal oscillation stops.Consider glue
abolition or glue do not touch to LC-package
The metal case inside of the molding compound may be exposed on the top or bottom of this product.
This purely cosmetic and does not have any effect on quality, reliability or electrical specs.
Specifications (characteristics)
Recommended
Operating Conditions
Item
Symbol
Conditions
Power voltage
V
DD
-
Clock voltage
V
CLK
-
Operating
T
OPR
-
temperature
Low
voltage detection
Item
Symbol
Low voltage
detection
JE,NB
V
LOW
LC
Min.
1.8
V
LOW
-40
Typ.
3.0
3.0
+25
Max.
5.5
5.5
+85
Unit
V
V
°C
I
BK
Item
Symbol
Refer to application manual for details.
Current consumption characteristics
Conditions
Min.
V
DD
=5V
-
T
a
=-40Cto+85C
Typ.
330
Max.
800
Unit
f
SCL
=0Hz
CLKOE=GND
CLKOUT;
nA
-
275
700
Conditions
Ta=-20C+70C
Ta=-40C+85C
Ta=-20C+70C
Ta=-40C+85C
Typ.
0.9
0.9
0.9
0.9
Max.
1.0
1.1
1.2
1.3
Unit
V
V
V
V
Current
Consumtion
V
DD
output OFF(LOW)
=3V
V
DD
=5V
f
SCL
=0Hz
CLKOE=V
DD
I
32k
CLKOUT;
-
2.5
3.4
A
Frequency
characteristics
Item
Symbol
Conditions
Rating
Unit
Ta=+25°C
Frequency
f/f
10
6
B:
523*
tolerance
V
DD
=3.0V
* Please ask for tighter tolerance. (Equivalent to 1 minute of monthly deviation)
32.768kHz output ON
V
DD
(Output=OPEN ;
=3V
CL=0pF)
-
1.5
2.2
