5300CF15A0950

Description
5.3 GHz Directional Coupler/ Low Pass Filter Combination
File Size119KB,4 Pages
ManufacturerJohanson Technology
Websitehttp://www.johansontechnology.com
Download Datasheet View All

5300CF15A0950 Overview

5.3 GHz Directional Coupler/ Low Pass Filter Combination

High Frequency Ceramic Solutions
5.3 GHz Directional Coupler/ Low Pass Filter Combination
Detail Specification: 12/11/08
P/N 5300CF15A0950
Page 1 of 4
General Specifications
Part Number
Frequency (MHz)
Insertion Loss
Return Loss
Attenuation (min.)
Coupling
Isolation
5300CF15A0950
4900 - 5850
0.8 dB max.
20 dB min.
20 dB @ 2 x Fo
15 ± 1 dB
22 dB min.
Terminal Configuration
Packaging
Style
Bulk
T&R
100% Tin
Tin / Lead
Suffix = S
Suffix = E
Suffix = None
Suffix = /Pb
Eg. 5300CF15A0950S
Eg. 5300CF15A0950E
Eg. 5300CF15A0950(E or S)
Eg. 5300CF15A0950(E or S)/Pb
No.
Impedance
Operating Temperature
Storage Temperature
Reel Quanity
50
-40 to +85°C
-40 to +85°C
4,000
Function
Termination
GND
GND
Input
Coupled Out
GND
GND
Output
3
2
1
8
5
6
7
P/N
Suffix Termination
Style
1
2
3
4
Mechanical Dimensions
In
L
W
T
a
b
c
g
p
0.079 ± 0.004
0.049 ± 0.004
0.027 ± 0.004
0.012 ± 0.004
0.008 ± 0.004
0.012 +.004/-.008
0.014 ± 0.004
0.026 ± 0.002
5
mm
2.00 ± 0.10
1.25 ± 0.10
0.70 ± 0.10
0.30 ± 0.10
0.20 ± 0.10
0.30
+0.1/-0.2
g
b
T
L
a
p
a
c
W
6
7
8
4
0.35 ± 0.10
0.65 ± 0.05
Mounting Considerations
Mount these devices with brown mark facing up.
Line width should be designed to provide 50 ohm impedance, depending on PCB material and thickness
Units: mils
112
Solder Resist
66
12
14
Land
Through-hole ( 12 mil diameter)
14
Johanson Technology, Inc. reserves the right to make design changes without notice.
All sales are subject to Johanson Technology, Inc. terms and conditions.
www.johansontechnology.com
4001 Calle Tecate • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821
2003 Johanson Technology, Inc. All Rights Reserved
