MCK Series
DIP Sockets
A
Removable
Carrier
Socket
Terminals
Typical PCB
MCK-RGHT-316
PERFORMANCE SPECIFICATIONS:
FEATURES:
The Augat VisInPak
™
Family allows gang mounting of socket
terminals without the need for a permanent insulator. The removable
carrier withstands temperature up to 400°C, typical of soldering,
vapor phase and infrared processed. Various terminal choices
provide a full range of mounting profiles.
• Available in all DIP patterns
• Four socket profiles
• The Visual Inspection Package provides easy cleaning
and solder joint inspection
MECHANICAL
Vibration
Type H, R, A .......... Passed MIL-STD-1344, Method 2005.1,
Condition III, 15 G’s
Type B .................... Passed MIL-STD-1344, Method 2005.1,
Condition V/J
Shock
Type H, R, A ............ Passed MIL-STD-1344, Method 2004.1,
Condition G, 100 G’s
Type B ...................... Passed MIL-STD-202F, Method 213,
Condition I
Durability ...................... Passed MIL-STD-1344, Method 2016
Normal Force
Type H & R .............. 115 Grams (4.1 oz.) with .018" (0,46) dia.
polished steel pin
Type B ...................... 238 Grams (8.4 oz.) with .018" (0,46) dia.
polished steel pin
Type A ...................... 35 Grams (1.2 oz.) with .018" (0,46) dia.
polished steel pin
Inner Contact
Retention .................... 7.5 Lbs. per line average
Solderability .................. Passed MIL-STD-202F, Method 208
Insertion Force with .018" (0,46) dia. polished steel pin
Type H ...................... 134 Grams (4.7 oz.)
Type R ...................... 179 Grams (6.3 oz.)
Type B ...................... 344 Grams (12.0 oz.)
Type A ...................... 81 Grams (2.9 oz.)
Withdrawal Force with .018" (0,46) dia. polished steel pin
Type H ...................... 77 Grams (2.5 oz.)
Type R ...................... 63 Grams (2.2 oz.)
Type B ...................... 174 Grams (6.1 oz.)
Type A ...................... 50 Grams (1.8 oz.)
ELECTRICAL
Contact Resistance ........ 10 Milliohms
Contact Rating .............. 3 Amps
Capacitance .................... 1.0 pF per MIL-STD-202F, Method 305
(contact to contact)
ENVIRONMENTAL
Humidity ........................ Passed MIL-STD-1344, Method 1002.2
Thermal Shock .............. Passed MIL-STD-1344, Method 1003.1
Operation Temp. ............ Gold inner contact -55°C to +125°C,
Tin/lead inner contact -55°C to +105°C
APPLICATION DIMENSIONS:
Contact Styles: H, R, B
• PCB Thickness Range: Standard .062" and .092" (1,57 and 2,34)
• IC Pin Dimension Range: .016" to .021" (0,41 to 0,53) dia.
.105" (2,67) min. length
Contact Style: A
• PCB Thickness Range: Standard .062" and .092" (1,57 and 2,34)
• IC Pin Dimension Range: .016" to .019" (0,41 to 0,48) dia.
.100" (2,54) min. length
MATERIAL SPECIFICATIONS:
Carrier ............................ KAPTON
®
or equivalent
Inner Contact .................. Beryllium copper, gold or tin/lead plated
Outer Sleeve .................. Brass or copper, gold or tin/lead plated
Quality & Innovation From The
Product Group
A22
Thomas & Betts
1555 Lynnfield Road
Memphis, TN 38119
(901) 682-8221 FAX (901) 537-8805
DIP Sockets
TABLE 2 - PIN SELECTION
.075
(1,91)
Max.
MCK Series
“A”
H
.075
(1,91)
Max.
K
.075
(1,91)
Max.
.095
±
.015
(2,41
±
0,38)
N**
.060
(1,52)
Max.
S***
A
“B” “C”
.166
±
.015
(4,22
±
0,38)
.035
(0,89)
Max.
.175
±
.015
(4,45
±
0,38)
.035
(0,89)
Max.
.035
(0,89)
Max.
.155
(3,94)
.035
(0,89)
Max.
.125
±
.015
(3,18
±
0,38)
.125
±
.015
(3,18
±
0,38)
.053
±
.003
(1,35
±
0,08)
.020
±
.003
(0,51
±
0,08)
.038
±
.003
(0,97
±
0,08)
.030
±
.003
(0,76
±
0,08)
.035" Dia.*
.058" Dia.*
.040" Dia.*
.050" Dia.* Min.
** N pin only available with R contact
*** S pin only available with A contact
* Recommended Hole Size
TABLE 3 - DIP STANDARD CONFIGURATONS
Number of
Contacts
6
8
14
16
18
20
22
22
24
24
24
28
±
.025 (0,64)
.300
(7,62)
.400
(10,16)
.700
(17,78)
.800
(20,32)
.900
(22,86)
1.000
(25,4)
1.100
(27,94)
1.100
(27,94)
1.200
(30,48)
1.200
(30,48)
1.200
(30,48)
1.400
(35,56)
Dim. “A”
Dim. “B”
(Typ.)
.300
(7,62)
.300
(7,62)
.300
(7,62)
.300
(7,62)
.300
(7,62)
.300
(7,62)
.400
(10,16)
.300
(7,62)
.300
(7,62)
.600
(15,24)
.400
(10,16)
.300
(7,62)
±
.025 (0,64)
.200
(5,08)
.400
(10,16)
.400
(10,16)
.400
(10,16)
.400
(10,16)
.400
(10,16)
.500
(12,70)
.400
(10,16)
.400
(10,16)
.700
(17,78)
.500
(12,70)
.400
(10,16)
Dim. “C”
Number of
Contacts
28
32
32
36
40
42
48
50
52
52
64
±
.025 (0,64)
1.400
(35,56)
1.600
(40,64)
1.600
(40,64)
1.800
(45,72)
2.000
(50,80)
2.100
(53,34)
2.400
(60,96)
2.500
(63,50)
2.600
(66,04)
2.600
(66,04)
3.200
(81,28)
Dim. “A”
Dim. “B”
(Typ.)
.600
(15,24)
.600
(15,24)
.900
(22,86)
.600
(15,24)
.600
(15,24)
.600
(15,24)
.600
(15,24)
.900
(22,86)
.600
(15,24)
.900
(22,86)
.900
(22,86)
±
.025 (0,64)
.700
(17,78)
.700
(17,78)
1.000
(25,4)
.700
(17,78)
.700
(17,78)
.700
(17,78)
.700
(17,78)
1.000
(25,4)
.700
(17,78)
1.000
(25,4)
1.000
(25,4)
Dim. “C”
HOW TO ORDER
TABLE 1 - CONTACT SELECTION
Letter
Contact Features
Normal Force (machined)
Normal Force (stamped)
High Force (machined)
Normal Force (stamped)
*** S pin only available with A contact.
H
R
MCK
Contact Selection
(see Table 1)
Pin Selection
(see Table 2)
Contact Plating
G
- Low Gold
Sleeve Plating
H
- Gold
G
- Gold
T
- Tin/Lead
T
- Tin/Lead
Number
of Contacts
Row Spacing
(see Table 3 for
standard
configurations)
B
A
** N pin only available with R contact.
Part Number Example: MCK-RHGT-628
QUAD and ZIP Patterns available. Please consult factory. For SIP Patterns, see page B4.
Need more technical information?
Consult your Thomas & Betts
sales office listed on the back cover
Thomas & Betts
1555 Lynnfield Road
Memphis, TN 38119
(901) 682-8221 FAX (901) 537-8805
A23
