BJ39-34 datasheet, PDF - EEWORLD Datasheet

EEWORLDEEWORLD

Datasheet

Datasheet> All Categories > The connector> The connector> BJ39-34

Preview

BJ39-34: DescriptionTWINAXIAL CONNECTOR, JACK; CategoryThe connector The connector; File Size61KB，1 Pages; ManufacturerVertiv

Download Datasheet Parametric View All

BJ39-34 Overview

TWINAXIAL CONNECTOR, JACK

BJ39-34 Parametric

Parameter Name	Attribute value
Maker	Vertiv
Reach Compliance Code	unknown
ECCN code	EAR99
Body/casing type	JACK
Connector type	RF TWINAXIAL CONNECTOR
DIN compliance	NO
IEC compliance	NO
MIL compliance	NO
Manufacturer's serial number	30
Options	GENERAL PURPOSE

Preview

Download Datasheet

View All

22

Two-pin polarized 30/330 series twbnc/twtnc

Mil-C-3655 Interface

.650 DIA MAX

OVER KNURL

.437 HEX NUT

,,,,,,,

.960

.096

.625 WRENCH FLATS

.687 WRENCH

FLATS

.750 DIA

.380

DIA

1.216

1.046

.946

.718

.050

.34

.665

,,,,,,

.650 DIA MAX

OVER KNURL

.030 TYP

.500-28UNEF-2A

.562 HEX NUT

.124

.058 TYP

.13 TYP

.258 TYP

.090 TYP

.100

1.740

.130

Cable Plug

TWTNC Positive Aligning

Two-pin polarized

.096

.931

.070 DIA TYP

.0625 DIA

.258

TYP

PLPA330

.050

.258

.100

.437 HEX NUT

.437 WRENCH FLATS

.593 DIA MAX

Circuit Board Bulkhead Jack

PL30-

PL330-

1

Cable Plug

Wrench Crimp, Two-pin polarized

BJ30 Shown

2-lug

Threaded

Right Angle-Two-pin

polarized Twinax (TWBNC)

Mounting Hole:

D3.125

BJ31 Shown

CBBJR39A

1.070

.046

.468

.040 DIA

CONDUCTORS

.380

DIA

.837

.093

.562 HEX NUT

.131

SOLDER POT

ACCEPTS .040 DIA

CONDUCTORS

.310

.375-32UNEF-2A

.437 HEX NUT

.468 HEX NUT

BJ31 SHOWN

.500-28UNEF-2A

.730 DIA

Bulkhead Jack

Front mount, Solder pot

Two-pin Polarized

2-lug

BJ30

Threaded

BJ330

Mounting Hole:

D5.130

Bulkhead Jack

Rear mount, Solder pot

Two-pin polarized

2-lug

BJ31

Threaded

BJ331

Mounting Hole:

D3.280

1.000

1.308

.783

.806

.096

.794

.437 HEX NUT

.500-28UNEF-2A

.525

.625 HEX

.687HEX

.687 HEX NUT

.500-28UNEF-2A

.625 HEX NUT

Feed-Through Jack

Two-pin polarized

1

2-lug

BJ38

Threaded

BJ338

Mounting Hole:

D3.160

Bulkhead Cable Jack

Rear mount, Wrench Crimp

Two-pin polarized

2-lug

BJ39-

1

Threaded

BJ339-

1

Mounting Hole:

D3.218

- Refers to Cable Group Table, see pages 68-88. "D" mounting holes are on page 45.

Note:

Only

30/330 Series

have

two-pin polarizations.

Trompeter Products Catalog

ISO 9001

Registered

R

(800) 982-2629

Fax: (818) 706-1040
