BYD17DA - BYD17MA
PRV : 200 - 1000 Volts
Io : 1.5 Amperes
FEATURES :
*
*
*
*
*
*
Glass passivated junction chip
High maximum operating temperature
Low leakage current
Excellent stability
Smallest surface mount rectifier outline
Pb / RoHS Free
GENERAL PURPOSE CONTROLLED
AVALANCHE RECTIFIERS
SMA (DO-214AC)
5.0
±
0.15
4.5
±
0.15
1.1
±
0.3
1.2
±
0.2
2.1
±
0.2
2.6
±
0.15
0.2
±
0.07
MECHANICAL DATA :
*
*
*
*
*
*
Case : SMA Molded plastic
Epoxy : UL94V-O rate flame retardant
Lead : Lead Formed for Surface Mount
Polarity : Color band denotes cathode end
Mounting position : Any
Weight : 0.067 gram
2.0
±
0.2
Dimensions in millimeters
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
RATING
Maximum Repetitive Peak Reverse Voltage
Maximum Crest Working Reverse Voltage
Maximum Continuous Reverse Voltage
Min. Reverse Avalanche Breakdown Voltage at I
R
= 0.1 mA
Maximum Average Forward Current
Ttp = 105 °C
(Note 1)
Ta = 65 °C; PCB mounting
Maximum Non-Repetitive Peak Forward Surge Current (Note 2)
at I
F
= 1 A , Tj = 25 °C
Maximum Forward Voltage
at I
F
= 1 A , Tj = 175 °C
at V
R
= V
RRMmax
, Tj = 25 °C
Maximum Reverse Current
at V
R
= V
RRMmax
, Tj = 165 °C
Typical Reverse Recovery Time (Note 3)
Thermal Resistance from Junction to Tie-Point
Thermal Resistance from Junction to Ambient (Note 4)
Operating Junction Temperature Range
Storage Temperature Range
Notes :
(1) Averaged over any 20 ms period.
(2) t = 10ms half sine wave; Tj = Tjmax prior to surge; V
R
= V
RRMmax
(Tj = 25 °C unless otherwise specified.)
SYMBOL
V
RRM
V
RWM
V
R
V
(BR)R-min
I
F(AV)
I
FSM
V
F
I
R
I
R(H)
Trr
R
th j-tp
R
th j-a
T
J
T
STG
BYD
17DA
200
200
200
225
BYD
17GA
400
400
400
450
BYD
BYD
17JA 17KA
600
800
600
800
600
800
650
900
1.5
0.6
20
1.05
0.93
1.0
100
3
30
150
- 65 to + 175
- 65 to + 175
BYD
17MA
1000
1000
1000
1100
UNIT
V
V
V
V
A
A
V
μA
μA
μs
K/W
K/W
°C
°C
(3) Reverse Recovery Test Conditions : I
F
= 0.5 A, I
R
= 1.0 A, Irr = 0.25 A.
(4) Device mounted on an epoxy-glass printed-circuit board, 1.5 mm thick; thickness of copper
≥
40
μm.
Page 1 of 2
Rev. 00 : February 13, 2008
TH97/10561QM
TW00/17276EM
IATF 0060636
SGS TH07/1033
RATING AND CHARACTERISTIC CURVES ( BYD17DA - BYD17MA )
FIG.1 - MAXIMUM PERMISSIBLE AVERAGE FORWARD
CURRENT AS A FUNCTION OF TIE-POINT TEMPERATURE
AVERAGE FORWARD CURRENT, I
F(AV)
(A)
3.0
FIG.2 - MAXIMUM PERMISSIBLE AVERAGE FORWARD
CURRENT AS A FUNCTION OF AMBIENT TEMPERATURE
AVERAGE FORWARD CURRENT, I
F(AV)
(A)
1.2
a = 1.57; V
R
= V
RRMmax
;
δ
= 0.5.
1.0
2.5
2.0
0.8
1.5
0.6
1.0
0.4
0.5
0.2
0
0
40
80
120
160
200
a = 1.57; V
R
= V
RRMmax
;
δ
= 0.5.
0
0
25
50
75
100
125
150
175
TIE-POINT TEMPERATURE, Ttp ( °C)
AMBIENT TEMPERATURE, Ta ( °C)
FIG.3 - FORWARD CURRENT AS FUNCTION
OF FORWARD VOLTAGE; MAXIMUM VALUES
6
FIG.4 - REVERSE CURRENT AS FUNCTION
OF JUNCTION TEMPERATURE; MAXIMUM VALUES
1000
FORWARD CURRENT, I
F
(A)
REVERSE CURRENT, I
R
(μA)
4
100
T
J
= 175 °C
2
T
J
= 25 °C
10
1
0
0
0
1
2
40
80
120
160
200
JUNCTION TEMPERATURE, T
J
( °C)
FORWARD VOLTAGE, V
F
(V)
Page 2 of 2
Rev. 00 : February 13, 2008
