YAGeo CorPorATIoN
INDUCTORS / BEADS
DIP Power Inductors
PMC Series
APPLICATIONS
excellent for power lines used on DC-DC conversion applications i.e. power switching, personal
computers and handheld devices.
FEATURES
PRODUCT IDENTIFICATION
PMC
☐☐☐☐
-
☐☐☐☐
-
☐☐
Internal No.
Tolerance
Inductance
Dimensions
Product Symbol
Halogen Free products
Shielded construction
Lowest DCr/µH, in this package size
Handles high transient current spikes without saturation
■
Tolerance: J = ±5%, K = ±10%, L = ±15%, M = ±20%,
■
Internal No.: HF = Halogen Free
P = ±25%, N = ±30%, Y = min
SHAPES AND DIMENSIONS
A
Unit: mm
B
XXX
G
D
TYPE
C
A
B
C
D
8.6
+0
10
+0
15
+0
8.5
+0
10
+0
E
F
G
1.3 ± 0.1
1.1 ± 0.1
1.4 ± 0.1
1.1 ± 0.1
1.1 ± 0.1
a
8.5
8.5
8.5
b
3.5
3.5
3.5
c
1.7
1.5
1.8
1.5
1.5
PMC107
PMC109
PMC115
b
11.5
+0
11.5
+0
3.4 ± 0.5
11.5
+0
11.5
+0
3.4 ± 0.5
11.5
+0
11.5
+0
3.4 ± 0.5
14.0
+0
14.0
+0
3.4 ± 0.5
14.0
+0
14.0
+0
3.4 ± 0.5
8.50 ± 0.5 3.5 ± 0.5
8.50 ± 0.5 3.5 ± 0.5
8.50 ± 0.5 3.5 ± 0.5
11.5 ± 0.5 6.5 ± 0.5
11.5 ± 0.5 6.5 ± 0.5
E
Land Pattern
a
F
c
PMC127
PMC129
11.5 6.5
11.5 6.5
