MMSD–05–20–S–04.25–D–K–LUX
F-208-1
MMSS–10–20–S–03.25–D–K–LUS
IPD1–05–D–K
MINI MATE CABLE
MMSD, MMSS, IPD1 SERIES
SPECIFICATIONS
Mates with:
IPL1 (Does not
mate with IPT1)
For complete specifications
see www.samtec.com?MMSD,
www.samtec.com?MMSS or
www.samtec.com?IPD1
Insulator Material:
Nylon 66
Contact Material:
Phosphor Bronze
Plating:Au
or Sn over
50µ" (1,27µm) Ni
Operating Temp Range:
-55°C to +105°C (20-26 AWG)
-55°C to +80°C (28-30 AWG)
Voltage Rating:
675 VAC
Wire:
20 to 30 AWG
RoHS Compliant:
Yes
CURRENT RATING
AMBIENT MMSS/IPL1 MMSD/IPL1
TEMP
6.8A
5.8A
20°C
6.0A
5.2A
40°C
5.3A
4.5A
60°C
3.6A
3.0A
95°C
MMSS 6 POSITIONS IN LINE POWERED
MMSD 2x3 CLUSTER POWERED
®
TYPE
PINS PER
ROW
WIRE
GAUGE
PLATING
OPTION
ASSEMBLY
LENGTH
END
OPTION
K
OTHER
OPTION
MMSD
= Double Row
MMSS
= Single Row
(02, 05 and
10 positions
only)
–02,
–05,
–10,
–15,
–20,
–25
–20
–22
–24
–24C
= Color
Coded
Cable
–S
= 30µ"
(0,76µm)
Gold on
contact
–“XX.XX”
= Assembly
Length in
Inches
(82,55mm)
03.25" min.
–S
= Single
End
–K
= Keyed
Polarization
–D
= Double
End
(Available on
–D end
option only.
Applies
to End 2
housing)
–LUS
= Latch up,
straight
No. of positions
x (2,54) .100
+ (1,40) .055
25
01
(8,89)
.350
(2,54)
(2,54) .100 .100
–26
–28
–30
Assembly
Length
± (3,18)
.125
–LDS
= Latch
down,
straight
–LUX
= Latch up,
crossed
(12,83)
.505
–LDX
= Latch
down,
crossed
MMSS
MMSD
–D–K–LUS
APPLICATION
SPECIFIC OPTION
• Other color coded cables.
• With or without Plug
Polarization (omit pin 1).
Call Samtec.
TYPE
POSITIONS
PER ROW
ROW
OPTION
K
TYPE
WIRE
GAUGE
01
PLATING
OPTION
APPLICATION
–24C CABLE
COLOR CODING
PIN
1
2
3
4
5
6
7
8
9
10
ETC
IPD1
= Body,
Loose
–02, –05,
–10, –15,
–20, –25
(–D only)
–S
= Single
Row
–K
= Keyed
Polarization
–S
CC79L
= Contact,
Loose
–2630
= 30 to 26 AWG
COLOR
BROWN
RED
ORANGE
YELLOW
GREEN
BLUE
VIOLET
GRAY
WHITE
BLACK
REPEAT
–D
= Double
Row
–02, –05,
–10
(–S only)
(Call Samtec for
other sizes)
CC79R
= Contact,
Full Reel
(15,000
Parts
per Reel)
–2024
= 24 to 20 AWG
= 30µ"
(0,76µm)
Gold on
contact,
Tin on tail
(1,52)
.060
(17,93)
.706
(1,57)
.062
(1,91) DIA
.075
(3,81)
.150
(3,17)
.1250
HAND TOOLS
(12,83)
.505
(7,24)
.285
–D
Note:
Some lengths, styles
and options are non-standard,
non-returnable.
–S
20 to 24 AWG:
CAT-HT-179-2024-11
26 to 30 AWG:
CAT-HT-179-2630-11
WWW.SAMTEC.COM
WWW.SAMTEC.COM
